Schematic and parts book for Bissell 8350, 7350 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Helpful Repair Videos
| # | Part image | Description | SKU | Price |
| XX | Not Available | Power Cord - 25 ft | 203-7237 | Not Available |
| XX | Not Available | Cord Clip | 203-7235 | Not Available |
| XX | Not Available | User's Guide - Bilingual | 120-4033 | Not Available |
| XX | Not Available | Screw Pack | 203-7222 | Not Available |
| 1 | Not Available | Hose Assembly | 203-7230 | Not Available |
| 2 | Not Available | Upper Handle Assembly | 203-7233 | Not Available |
| 3 | Not Available | Trigger Handle | 203-7234 | Not Available |
| 4 | Not Available | Cord Wrap | 203-7236 | Not Available |
| 5 |  | On/Off Switch for Bissell Carpet Cleaner Models 2x 66Q4 73A5 1370 1622 8920 9200 9300 9400 8930 9... | 2036719 | $8.68Add to cart |
| 6 | Not Available | Sliding Crevice Tool | 203-7239 | Not Available |
| 7 | Not Available | 3" Upholstery Tool | 203-7238 | Not Available |
| 8 | Not Available | Hose Wrap Upper | 203-7232 | Not Available |
| 9 | Not Available | Cap Oxygen II Power Tool | 203-7241 | Not Available |
| 10 | Not Available | Oxygen II Power Tool | 203-7240 | Not Available |
| 11 | Not Available | Dirty Tank Assembly w/Cap - Blue | 203-7204 | Not Available |
| 11 | Not Available | Dirty Tank Assembly w/Cap - Purple | 203-7205 | Not Available |
| 12 | Not Available | Dirty Tank Cap | 203-7206 | Not Available |
| 13 |  | TANK, CLEAN WATER BLUE Part Number: 203-7207 for Bissell | 2037207 | $39.34Read more |
| 13 |  | TANK, CLEAN WATER PURPLE Part Number: 203-7208 for Bissell | 2037208 | $37.23Read more |
| 14 |  | NO LONGER AVAILABLE Bissell Shampoo Formula 2X 8920 8930 9200 Cap and Insert | 2036677 | $9.90Read more |
| 14 |  | Compatible alternateTANK CAP STRAW Bissell repair part number: 2032287 can sub for 2036677 which has a shorter bleed ... More Product Details | 2032287 | $4.48Add to cart Special order — allow 2-4 weeks. |
| 14 |  | Available ReconditionedCertified Reconditioned Bissell Shampoo Formula 2X 8920 8930 9200 Cap and Insert More Product Details | 2036677R | $19.99Add to cart |
| 15 | Not Available | Transfer Case w/Gaskets | 203-7212 | Not Available |
| 16 | Not Available | Motor Duct Filter Gasket | 203-7214 | Not Available |
| 17 | No Image | MOTOR, 7350 Part Number: 203-7217 for Bissell | 2037217 | $58.14Read more |
| 18 | Not Available | Spray Tip Cover | 203-7210 | Not Available |
| 19 | Not Available | Spray Tip | 203-7211 | Not Available |
| 20 | Not Available | Cover - Main | 203-7213 | Not Available |
| 21 | Not Available | Sole Plate | 203-7221 | Not Available |
| 22 |  | Pump W/Connector - Bissell Extractor For: bissell | 2037220 | $20.42Read more |
| 23 | Not Available | Elevator Arms Assembly L&R | 203-7228 | Not Available |
| 24 | Not Available | Pivot Arms L&R | 203-7224 | Not Available |
| 25 | Not Available | Roller Axle | 203-7225 | Not Available |
| 26 | Not Available | Roller Assembly w/Axle | 203-7223 | Not Available |
| 27 |  | BELT, GEARED 7350 1/2" WIDE Part Number: 2037226 for Bissell | 2037226 | $6.26Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | Not Available | Wheels w/Axles L&R | 203-7229 | Not Available |
| 29 |  | Receiver, Autoload W/O Umbrella Valve ProDry 7350 Part Number: 203-7215 for Bissell | 2037215 | $6.55Read more |
| 30 | Not Available | Detent Lever Assembly | 203-7216 | Not Available |
| 31 | Not Available | Circuit Board | 203-7218 | Not Available |
| 32 | Not Available | Brush Pulley & E-Clip | 203-7227 | Not Available |
| 33 | Not Available | Hose Wrap Lower | 203-7231 | Not Available |
| 34 | Not Available | Brush Motor | 203-7219 | Not Available |
