Schematic and parts book for Windsor BV11;VP10;VP6;BV1 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| XX | Not Available | Motor Ground Connection | PV-100379 | Not Available |
| XX | Not Available | Motor Crimp Set: 5 Female 3 Male | PV-100380 | Not Available |
| XX | Not Available | High Filtration Disc (Optional) | PV-101220 | Not Available |
| XX | Not Available | Nut For Aluminum Wand | PV-100099 | Not Available |
| XX | Not Available | Ring For Aluminum Wand | PV-100100 | Not Available |
| XX | Not Available | Switch Cord With Crimps Only | PV-101714 | Not Available |
| XX | Not Available | Compression Ring Connection Screws: | PV-100378 | Not Available |
| 1 | Not Available | Twist Cap (Teal) | PV-101935 | Not Available |
| 2 | Not Available | Paper Bag 6 Qt. Micro Filter 10 Pk | PV-100431 | Not Available |
| 2 | Not Available | Paper Bag 10 Qt. Micro Filter 10 Pk And Wire Clamp Set: | PV-100331 | Not Available |
| 3 | Not Available | Micro Cloth Filter Bag 6 Qt. Models | PV-100564 | Not Available |
| 3 | Not Available | Micro Cloth Filter Bag 10 Qt. Models With Connection Screws (Not Shown) | PV-100565 | Not Available |
| 4 | Not Available | Carry Handle With Rivet And Washer Set | PV-101737 | Not Available |
| 5 | Not Available | Shoulder Strap Assembly: | PV-103005 | Not Available |
| 6 | Not Available | Backplate Assembly (2 Pieces) | PV-103257 | Not Available |
| 7 | Not Available | Barrel Nut Connection Set | PV-100375 | Not Available |
| 8 | Not Available | Backplate (Black) Connection Set: | PV-100716 | Not Available |
| 9 | Not Available | Waist Belt Keeper | PV-100363 | Not Available |
| 10 | Not Available | Waist Belt | PV-100359 | Not Available |
| 11 | Not Available | Power Cord 18" 16/3 Complete | PV-100641 | Not Available |
| 12 | Not Available | Switch Cord Complete With Switch And Box | PV-101610 | Not Available |
| 13 | Not Available | Switch Box With Velcro® And Screws | PV-101472 | Not Available |
| 14 | Not Available | Double Pole On/Off Switch | PV-100743 | Not Available |
| 15 | Not Available | Sound Muffler | PV-100698 | Not Available |
| 16 | Not Available | Plastic Air Diffuser | PV-100352 | Not Available |
| 17 | Not Available | Motor Compression Ring | PV-100335 | Not Available |
| 18 | Not Available | Tetraseal | PV-100014 | Not Available |
| 19 | Not Available | Carbon Brush Replacement Set | PV-100424 | Not Available |
| 19 | Not Available | Carbon Brush Replacement Set | PV-105697 | Not Available |
| 20 | Not Available | Domel Motor With Crimps | PV-100422 | Not Available |
| 20 | Not Available | Ametek Motor | L-116311-01 | Not Available |
| 20 | Not Available | Motor | GS-05202 | Not Available |
| 21 | Not Available | Bottom Bumper | PV-100586 | Not Available |
| 22 |  | Backpack Vacuum Paper Bags 6qt Circle Opening - 10pk | PVR1400 | $18.06Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | Not Available | Paper Bag 10 Qt. Micro Filtration ENV 10 Pk Wire Clamp And Ground Crimp | PVR-1410 | Not Available |
| 22 | Not Available | Motor Mounting System Set: | PV-100368 | Not Available |
| 23 | Not Available | Dome Filter With Foam Media | PV-100030 | Not Available |
| 23 | Not Available | Dome Filter With Foam Media | COR-1800 | Not Available |
| 24 | Not Available | Foam Filter Media For Dome Filter | PV-100343 | Not Available |
| 25 | Not Available | 1 1/2" Static-Dissipating Hose | PV-100505 | Not Available |
| 26 | Not Available | 1 1/2" Replacement Swivel Cuff (Black) | PV-100694 | Not Available |
| 27 | Not Available | Main Body | PV-104581 | Not Available |
| 28 | Not Available | 56" Two-Piece Aluminum Wand | PV-101338 | Not Available |
| 29 | Not Available | 14" Carpet Tool With Scallops | PV-100147 | Not Available |
| 29 | Not Available | 14" Carpet Tool With Scallops | CM-5620 | Not Available |
| 30 | Not Available | 3" Dust Brush | PV-100110 | Not Available |
| 31 | Not Available | 5" Upholstery Tool | PV-100115 | Not Available |
| 32 | Not Available | 11" Crevice Tool | PV-100107 | Not Available |
| 33 | Not Available | 14" Hard Floor Tool With Nylon Brush | PV-100623 | Not Available |
