Schematic and parts book for Tornado 98774 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 |  | Housing Left Non Motor Side PDS1 Series | X1370 | $75.99Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | Housing Right Motor Side PDS1 Series | X1371 | $75.99Add to cart Special order: ships in 2 to 4 weeks |
| 3 |  | Control Panel Assembly w/Switch and Switch Mount | X1372A | $13.99Add to cart Special order: ships in 2 to 4 weeks |
| 4 |  | Fan LC Squirrel Cage Dryer | X1373 | $29.99Add to cart Special order: ships in 2 to 4 weeks |
| 5 | No Image | Knob Switch Value Dryer | X1374 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 6 | No Image | Foot Left Dryer Kickstand Soft | X1375 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 7 | No Image | Foot Right Dryer Kickstand Soft | X1376 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 8 | No Image | Bolt .312-18x3.25 Mounting Value Dryer | X1377 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 9 | No Image | Washer 5/16 SAE Flat Zinc | X8218 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 10 |  | Nut 5/16 Lock with Nylon Insert Zinc | X8248 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 11 | No Image | Grill Dryer Injection Molded with Tabs | X1378 | $6.99Add to cart Special order: ships in 2 to 4 weeks |
| 12 | No Image | Switch, Mounting And Back Support Value Dryer | X1379 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 13 | No Image | Wire Jumper 7 Switch Value Dryer | X1431 | $5.99Add to cart Special order: ships in 2 to 4 weeks |
| 14 |  | Motor Dryer 115 VAC 0.6hp 18uf Capacitor | X14411152AL | $155.99Add to cart Special order: ships in 2 to 4 weeks |
| 14C |  | Capacitor 18uF for X1441 and PDS1 | X1441C | $8.99Add to cart Special order: ships in 2 to 4 weeks |
| 15 | No Image | Label Control Panel Tornado | X1504TOR | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 16 | No Image | Cord Dryer 20ft 18/3 SJTW | X9719 | $23.99Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | Switch, 3 Speed Dryer | X9830 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 18 |  | Screw PH Pan 6-32x3/8 MS Zn | 01734 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 19 | Not Available | Screw #8-18 x 5/8" | A732-8314 | Not Available |
| 20 | No Image | Label, Warning, Value Blower | X1550 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 21 | No Image | Label Serial Number 2X2 Plain | X8459 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 22 |  | Kickstand Dryer | X8874 | $7.99Add to cart Special order: ships in 2 to 4 weeks |
| 23 | No Image | P Clip 1/2in Heyco 350-3364 | 0242790000 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 24 | No Image | Label Qualified Made In The USA 1.618 X 1.618 | X1003 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
