Schematic and parts book for Tornado 98692 Quad . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX |  | Jet, 7/32 | 04983 | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| XX |  | Jet, 3/16 Orif. | 04982 | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1 | No Image | Gauge, Air Pressure | 05732 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | Not Available | Galvanized Bushing 3/4" MPT x 1/8" FPT | 11327 | Not Available |
| 3 | Not Available | Pipe Tee 3/4" FPT | 11323 | Not Available |
| 4 | Not Available | Galvanized Fitting 3/4" MPT x Plain | 11325 | Not Available |
| 5 | No Image | Symphony | 11326 | $253.40Read more |
| 6 | No Image | FITTING IRON ELBOW 3/4 FPT X 3/4 F | 11324 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | Not Available | Male Adapter 3/4" MPT | 11365 | Not Available |
| 8 | No Image | HOSE GP BLACK 5.5 | 32524 | $17.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | Hose Clamp | 05727 | $0.00Read more |
| 10 | Not Available | Galvanized Bushing 3/4" MPT x 1/2" FPT | 11322 | Not Available |
| 11 | No Image | HOSE GP BLACK 4.5 | 32523 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | Not Available | Screw 1/4-20 x 1" | 02038 | Not Available |
| 13 | No Image | Lock Washer | 01574 | $0.00Read more |
| 14 | No Image | Elbow, Connection | 05734 | $137.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Muffler, Cover Paint Black | 05735B | $37.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Muffler, Shell(Air Vacs.) Paint Black | 05736B | $63.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | No Image | Air Jumbo Vacuum Nozzle | 05723 | $0.00Read more |
| 18 | No Image | SCREW HEX HD CAP 5/16 18 X 1 3/4 (ZP) | 12812 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 |  | NUT FINISHED HEX W/ LOCTITE 5/16 18 (ZP) | 01589 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | Muffler Base | 04927 | $0.00Read more |
| 21 | No Image | GASKET | 05724 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 |  | Jet, 1/4 | 04984 | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 |  | RING O 3/8 | 02481 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | Not Available | Screw 1/4-20 x 1" | 02038 | Not Available |
| 25 | No Image | Nipple 1/2" Mpt | 05730 | $0.00Read more |
| 26 | Not Available | Base | 11317 | Not Available |
| 27 | No Image | Plate, Mounting | 14331 | $151.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | No Image | GASKET | 11329 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | Not Available | Screw 1/4-20 x 1-1/2" | 01978 | Not Available |
| 30 | Not Available | Strap | 11328 | Not Available |
| 31 | Not Available | Support | 14330 | Not Available |
| 32 | No Image | Nut | 01497 | $0.00Read more |
| 35 |  | Spacer 1/2 Replaces 03144 | 19259 | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | Thumb Screw | 08057 | $0.00Read more |
| 37 | No Image | Cover, Quad Tank | 14329 | $424.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 | No Image | Gasket, Tank Cover 25.75 OD X 21.00ID X .375 | 17131 | $86.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | DEBRIS DEFLECTOR JUMBO COVER INTAKE | 90442 | $61.99Read more |
| 40 | No Image | GASKET FLANGE | 04908 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | No Image | Flange, Jumbo Vac | 11331 | $108.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 | No Image | RIVET BLIND 5/32 DIA X .254 | 05043 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 | No Image | MOUNTING PLATE | 14407 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 | Not Available | Gasket | 02706 | Not Available |
| 45 | No Image | Ball, Float 3Dia.SS | 15517 | $63.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 | No Image | Float, Cage Jumbo Vac | 06428 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 | No Image | TIE WIRE | 06430 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | Screw 1/4-20 X 5/8" | 02047 | $0.00Read more |
| 49 | No Image | Stand, Head Jumbo vac | 04997 | $43.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 50 | No Image | Nut Hex Lock P/T 1/4 20 | 07533 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 51 |  | Hose to Jumbo Cover Adapter, 2In to 3In | 90332 | $98.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 52 |  | Hand Tool 2in Wet/Dry Aluminum Round Nozzle 18in | 90444 | $101.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 53 | Not Available | Wing Nut 1/4-20 | 01019 | Not Available |
| 54 |  | Washer Lock No. 10 Countersunk | 01905 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 55 | Not Available | Screw 1/4-20 x 1-1/4" | 02028 | Not Available |
| 56 | Not Available | Clamp | 02100 | Not Available |
| 57 | Not Available | Jumbo Filter Clamp | 02101 | Not Available |
| 58 | No Image | Nozzle, Jumbo vac | 02643 | $160.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 59 | No Image | SHOE | 02644 | $131.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 60 | No Image | Nozzle, 22 Jumbo Vac | 02742 | $123.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 61 | Not Available | Strap | 02743 | Not Available |
| 62 | No Image | GASKET | 05737 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 63 | No Image | Gasket 2.6 OD 1.875 ID 0.1875 Thick Rev01 | 05781 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 64 | No Image | Rod, Filter Support Rod(Lrg.) | 05995 | $46.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 65 | No Image | Nut, Hex 3/4 Hex 5/8 18 Ext | 08015 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 66 |  | Pin, Hose holder Jumbo Vac | 08016 | $23.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 67 | No Image | INTAKE LOCK SPRING | 08017B | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 68 | No Image | Ring Retaining Ext 5/16 | 08018 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 69 | Not Available | Screw | 08031 | Not Available |
| 70 | No Image | RING SNAP 2 31/32 FREE OD | 08043 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 71 | No Image | Collar, Jumbo Vac | 08046 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 72 | No Image | Sleeve, Jumbo Vac | 08047 | $19.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 73 | No Image | TIE WIRE FILTER 12 | 08052 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 74 | No Image | SCREW PHIL. FLAT HD MACH No 10 24 X 5/8 (SS) | 11492 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 75 | No Image | Bag, Filter Cloth (Poly) (98451,692) | 11552 | $250.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 78 | No Image | Hose, Urethane Clear 2 X 180 W/Cuffs | 14713 | $249.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 79 | No Image | Blade, Squeegee Outer (90317) Gum Rubber | 17814 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 80 | No Image | Blade, Squeegee Inner (90317) Gum Rubber | 17815 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 81 | No Image | Wire Tie 15 Blk | 18706 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 82 | No Image | Wand, 2 Pc.Chrome 2 Dia Stl W/Stl Couple | 18749 | $252.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 83 | No Image | Pipe Nipple | 32475 | $0.00Read more |
