Schematic and parts book for Tornado 98482b . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 |  | Floor Pad Microfiber Burnishing 20in Sgl Sided 2pk | MF20 | $348.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 |  | Floor Pad Porko Plus Burnishing 20in 5/case | PP0520 | $72.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | 20" Combo Floor Pad (Case Of 5) | CB520 | $0.00Read more |
| 4 | No Image | 20" Beige Burnishing Pad Case Of 5 | IB520 | $0.00Read more |
| 5 | No Image | 20" Luster Lite Floor Pad (Case Of 5) | LL520 | $0.00Read more |
| 6 | No Image | 20" Porko Floor Pad (Case Of 5) | PK520 | $0.00Read more |
| 7 | No Image | 20" Scuff Remover Floor Pad | RP020 | $0.00Read more |
| 8 |  | Pad Driver, Flexible | X8862 | $268.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | No Image | HANDLE ASMB COMPLETE ORB1420 | X8911K | $635.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.1 | Not Available | Handle Base | X8905B | Not Available |
| 1.2 | Not Available | Trigger Handle | X8917 | Not Available |
| 1.3 | No Image | ROLL PIN ALL METAL HANDLE | X8918 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.4 | No Image | SPRING TRIGGER METAL HANDLE | X8916 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.5 | No Image | SET SCREW 1/4-20X3/16 SOC SET FLAT PT W/LOC-TITE | X8222 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1.6 |  | GROMMET, 1/16 GR - 7/16 DIA 72713A | 7BG004 | $27.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Insulation Sheet All Metal Handle Assy 2.5x2x0.15 | X8923 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 |  | Switch, Momentary On/Off Part Number X1039 for Cleanmax Models CM-WAV | X1039 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Switch Box Cover, Front Yellow | X1462 | $28.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | No Image | Plug, Plastic Blk 7/16 Hole | X8151B | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 |  | LABEL ROUND GRILL F5 WRD TORNADO AXIAL FAN | X9189TOR | $2.99Read more |
| 7 | No Image | Screw 10-24x1/2 Phil Pan St Type F Zinc | X8207 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 |  | WASHER, No 10 INT TOOTH LOCK SS | 7CY001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | LABEL GROUND SYMBOL | X9214 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | SCREW 8-32 X 1/2 TRUSS/PHIL BLK ZINC | X8272 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | No Image | 8-32x1 PH Pan M/S Blk Zinc | PX73 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | Motor Cover, P Series, Yellow Burnisher | X1458 | $24.99Add to cart |
| 13 | No Image | LABEL DISCONNECT POWER CORD BEFORE SERVICING | X8413 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | Insert Post Mold Comfort Pro Type D 8/32 Threaded | X1075 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Motor,Burnisher,120,VAC,Tianan,Carbon Brush,Light,No plug | X8037TI | $966.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Pulley, M2000 O-Groove 4.063 OD | X9298 | $37.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | No Image | WASHER, 5/16 1OD .075 THICK | X9374 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 |  | Washer Lock Split 5/16 Zn Regular | 01577 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | No Image | SCREW, 5/16 X 3/4 HEX CAP GRADE 8 | X9327 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | Housing, Black M Style Burnishr | X8050AP | $372.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | No Image | BOLT, 8-32 X 3/4 PHIL TRUSS MS BLK ZINC | X8821 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | No Image | SPACER BLK NYL NO 8 .17ID X .25OD X .25L | X8822 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | No Image | Bumper, Black/Black In Inches | X8030K | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | No Image | MAIN PULLEY ASSEMBLY | X8096A | $165.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24.1 | No Image | Weldment, Shaft And Plate | X8091 | $47.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24.2 | No Image | Pulley, Main Burnisher | X8096 | $109.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24.3 | No Image | Bearing, Ball Rubber Sealed On Both Sides | X8098 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | No Image | WASHER, 3/8 USS FLAT ZINC | X8230 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | SCREW, 3/8-16 X 3/4 HEX CAP GRADE 5 | X8223 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | | Pad Driver, Flexible | X8862 | $268.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27.1 | No Image | Pad Driver RH Thread Center-Lok Blue X8862 | F44P | $26.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | No Image | SCREW 5/16-18X 1 1/2 PHIL FLAT M/S ZINC | X8216 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | No Image | Belt,Burnisher,V-Belt,40.5, Pulley | X80995 | $30.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | No Image | Nut 5/16-18 Hex Finish Zinc | X8231 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 |  | SCREW HEX HD CAP 5/16 18 X 1.00 (ZP) | 03361 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | No Image | Screw Hex Head Cap 1/4-20x1-1/4 ZP Gr5 | X8226 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | WASHER, 1/4 SPLIT LOCK ZP | X8212 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 | No Image | Washer 5/16 SAE Flat Zinc | X8218 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | No Image | WASHER 3/8 SAE FLAT ZINC | X8219 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | Shaft, Pivot Handle 1/2X10-1/2 M Style Burnisher | X8811 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | Axle, 1/2X14-1/2 M Burnisher | X8816 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 | No Image | Spring Washer, 1 OD X 1/2 ID X .0190-.022 | X8101 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | Wheel, Black 5 X 1-1/4 | X8024 | $18.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 | No Image | Washer, Countersunk | X8020 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | No Image | SCREW 1/4-20 X 3/4 FLAT PHIL MS ZINC | X8265 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 | No Image | Wheel, Black 4X1-1/2 | X8935 | $35.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 |  | Axle, 13 3/4 For 1 1/2 Wheel M-Series Burnisher | X8936 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 | No Image | Shaft, Pivot Brace 1/2 X 10 M Style Burnisher | X8813 | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 45 | No Image | BUMPER RECESSED POLYETHY 1-1/8 BASE 3/4 HGT 13/64 HOLE | X8258A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 | No Image | SCREW, No 8 X 1 PHPH TYPE A | X8258AS | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 | No Image | Cord, Inline,Floor Machine/Burnisher,49 Inch,Black,14/3 SJTWA,W/Out Strain Relief | X8022 | $23.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | Cord Hook,Floor Machine,Plated | X8013 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 49 | No Image | Cord,Burnisher,75ft,Gray,12/3 SJTW | M1407G | $199.99Add to cart |
| 50 | No Image | Strain Relief, Metal Small | SR37 | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 51 | No Image | Washer, Strain Relief | SR36 | $4.99Add to cart |
| 52 |  | Nut Conduit 1/2 Part Number X8008N for Cleanmax Models CM-WAV | X8008N | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 53 | No Image | Actuator, Thumb Switch All Metal Handle Assembly | X8914 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 54 | No Image | Spring, Thumb Actuator Metal Handle Assembly | X8915 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 55 | No Image | Handle Brace, Weldment | X1464 | $49.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 56 | No Image | Cam Lever, Assembled Sell X8012A | X1184 | $23.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 57 | No Image | Washer, Cam W/Slot | X8028 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 58 | No Image | Clamp, Handle Lock, Diecast | X1456 | $25.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 59 | No Image | Handle Clamp Knob, Plastic | X8016 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 60 | Not Available | Warning Label | X1044 | Not Available |
| 61 | No Image | Label Qualified Made In The USA 1.618 X 1.618 | X1003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 62 | No Image | Label Serial Number 2X2 Plain | X8459 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 63 | No Image | Screw 9-15 x 1 HWH | X1476 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 64 | No Image | Switch Box Cover, Rear Yellow | X1463 | $28.99Add to cart |
| 65 |  | Ring Retaining Ext E 1/2 Heavy Duty | 03470 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
