Schematic and parts book for Tornado 98170 PFX . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | LABEL, BRUSH WARNING SCE PFX900S | X9134 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Cable Tie 11 50 lb Black Tie | X8150 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Lid, Solution Tank SCE | X9081 | $22.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Label | X9206TOR | $0.00Read more |
| 5 | No Image | Housing Solution Black SCE | X9042REPRO1 | $135.39Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | Label | X9416 | $0.00Read more |
| 7 | Not Available | Defoamer Warning Label | X9003 | Not Available |
| 8 | No Image | Knob, Large Dome LID SCE | X9110 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | SCE DOME COVER WITH GASKET LARGE | X9034C | $62.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | Gasket, Large Dome Spacer | X91202 | $35.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | No Image | SCREW No 6 X 1/2 SS PAN HEAD PHIL | X8261SS | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | Dome, Small SCE | X9033 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | Gasket, Small Dome SCE 1/8 EPDM Med Density Foam W/PSA 1 Side | X9071 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | Standpipe Sub Assembly, Vacuum SCE | X9129SUB | $95.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Washer,Plain 2.00 ID SS | 18886 | $18.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Gasket Dump Valve .125 Thick 1.81 ID X 2.37 OD | PX14A | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | No Image | Housing Recovery Black SCE | X9041REPRO1 | $256.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | No Image | Bracket, Tank Mount 90 Dgre SCE | X9086 | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 |  | SCREW 1/4-20X1/2 SERRATED HEX SELF LKG FLANGE | X8209S | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | Hose, Vac 1.5X21 W/Cuffs SCE | X9092 | $59.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | No Image | Motor,Extractor,120,VAC,Ametek,3 STG,ETL | X1038 | $195.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | No Image | SET SCREW 1/4-20X3/16 SOC SET FLAT PT W/LOC-TITE | X8222 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 |  | Elbow Fitting Plastic 90 White 1.5 FPT | PX11A | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 |  | Bulkhead Plastic 1.5 NPT X 1.5 Hose Barb | PX25 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 |  | Expander, 1-1/4 To 1-1/2 Gray Cuff | K1123 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | SCREW, 1/4-20 X 4 HEX HEAD CAP ZP | 17645 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | No Image | Screw TFT B PanHd Zn No.10 16x1/2 | 19565 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | No Image | Spacer, Vac Motor (98190) | 30070 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | No Image | Gasket 3/8 Donut Tank Seal V1510 PVC | X9079 | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | No Image | Bracket, Tank Mount SCE | X9085 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 | No Image | LABEL OPERATING INSTRUCTION SCE PFX900S | X9057 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | No Image | LABEL TANK CAPACITY SCE NEW | X91251 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | Float Cage, W/1 1/2 NPT Neck Heavy Ball | X9053 | $39.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 |  | Nut, Lock Die Cast 1.5 | PX46 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | No Image | Bushing, 1-1/2 X 1-1/4 Pvc Sch 40 Threaded | X9075 | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | Gasket, Cover SCE | X9084 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | Cover, Recovery Tank Float SCE | X9080 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 | No Image | Tether, 18-8 SS Lanyard, Loop-to-Eye, 12In Long, 1/16In Rope Dia, PVC Coated | X2330 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 |  | SCREW, 10-24X1/2 PHIL PAN MS 18-8 SS | 7BS001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 |  | Filter,Pumps,SLS 1/2 FNPT 30X30 SST | X9294 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 |  | Gasket Fiber 1.125 OD X .75 ID X .156 Thick | PX48G | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 |  | Bulkhead, Fitting Brass .75 | PX48 | $28.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 | No Image | Washer 3/4 Neoprene-Bond Galvanized | 72274A | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 |  | Barb, 1/2 Hose 1/4 NPT Male | 7AT004 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 45 | No Image | Hose 1/2 Wire Reinforced | 70079C | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 | No Image | Clamp 1/2 Worm Gear SS Hex Slot Phil SAE Size 6 | 7DL008 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 | No Image | Clamp 1-1/2 Worm Gear SS Hex Slot Hd SAE Size 20 | 7DL005 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | Clip Spring, Black | 72173A | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 49 | No Image | Screw A Point PH No. 10x1 Blk Zinc | X9098 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 50 | No Image | Cord, Extension 14/3 X 50FT 300V Yellow | 32217 | $148.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 51 | No Image | Harness, SCE 120V Rev05 | X9841 | $462.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 52 | No Image | Hose Drain PFX900S Cascade PFX1350 | PAS37 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 53 |  | Nut Conduit 1/2 Part Number X8008N for Cleanmax Models CM-WAV | X8008N | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 54 | No Image | Circuit Breaker,Extractor,2.5Amp,125V-250VAC | X1192 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 55 | No Image | SCREW, 10-32X7/8 SOC SET CUP PT 18-8 STAINLESS | X9135 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 56 |  | WASHER, No 10 FLAT S/S MS-15795 No. 841 | 7CM003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 57 | No Image | Housing, Control Panel Black SCE | X9043REPRO | $50.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 58 | No Image | Label, 3 Hole Switch Panel SCE | X9093 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 59 | No Image | Switch, Rocker SCE | X9007 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 60 | No Image | Drain Hose Plug Compatable With PAS37 Hose | PAS36 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 61 | No Image | SCREW, 10-32X3/4 PHIL PAN MS 18-8 SS | 7BR005 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 62 | No Image | NUT, CAP 10-32 SS | 7DN004 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 63 | No Image | Switch,Rocker W/ Paddle 15A 115V | X9200 | $33.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 64 | No Image | CORD CLAMP SCE PFX900S | X9111 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Elbow, Street .125 90 Degree Brass | SW139 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 |  | Valve Kit, 120 VAC Solenoid, 290 Psi | SW290KIT | $169.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 |  | Terminal, Female .250 Blue .032 Amp | F25 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Wire, 14 Gauge Green with Yellow Stripe | M1361YG | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | No Image | NIPPLE HEX 1/8X1/8 | 7CX001 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | BUSHING 1/4 - 1/8 NPT | 7AG002 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | No Image | Tee Union 1/4 NPT | 7AV001 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | Nipple Hex 1/4 MPT | 7CX002 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | Reducer 3/8 Mpt X 1/4 Fpt Nylon | X2198 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | Pump,Extractor,110,VAC,120psi,Aquatec | AQ120 | $302.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | No Image | Elbow 3/8 Mpt X 1/2 H Nylon | X2196 | $23.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 |  | WASHER, RUBBER .29ID .688OD 1/8 80 DURO | 72667A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | Hose, 1/4 Braided, 250 PSI | 71817A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | SCREW, 10-24X3/8 PHIL PAN MS 18-8 SS | 72091A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | LABEL GROUND SYMBOL | X9214 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 |  | SCREW, 10-32X1/2 PHIL PAN MS 18-8 SS | 71651A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 |  | WASHER, No 10 INT TOOTH LOCK SS | 7CY001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | No Image | Wheel 12x1-3/4 Blk with Gray Tire | X9066 | $57.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | No Image | Washer, Countersunk | X8020 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | WASHER, 1/4 SPLIT LOCK ZP | X8212 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | No Image | SCREW 1/4-20 X 3/4 FLAT PHIL MS ZINC | X8265 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | No Image | Nut 1/4-20 Lock Nylon Insert | X8237 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | No Image | NUT, 1/4-20 HEX SS | 7CN001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | No Image | WASHER 1/4 SPLIT LOCK SS | 7CL002 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | No Image | BOLT, 1/4-20 X 1 HEX SS | X8282 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | Tank Hinge PFX900S PFX1350 | X9014 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | No Image | SCREW, 1/4-20 X 1/2 HEX CAP | X8209 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 |  | Washer 1/4ID Tooth Part Number 7CY002 for Cleanmax Models CM-WAV,CM-WAV | 7CY002 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | No Image | Clamp 1/4 Worm Gear SS Hex Slot Phil SAE Size 4 | 7DL003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 |  | Barb, Hose 1/4 H - 1/4 M NPT | 7AT003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 |  | Washer-plain Part Number 19616 for Cleanmax Models CM-WAV | 19616 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 |  | Quick Disconnect .25 Female | PX6 | $33.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | Door, Flip Hinge and Spring SCE | X9096 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 | No Image | GASKET FLIP DOOR SCE 3/32EPDM PFX900S | X9097 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | No Image | Vac Shoe Tube SCE | X9009A | $276.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | SET SCREW 1/4-20X3/16 SOC SET FLAT PT W/LOC-TITE | X8222 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | Hose 300PSI Solution 3/8 ID X 1/8 Wall | PX3H | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 | No Image | Clamp Single Ear 18.5 mm | PX61A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | Barb 1/4 X 3/8 Male/Male | PX85 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 |  | Quick Disconnect, .25 Male/Male 2 Way Shut Off | PX5 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | No Image | NUT, 10-32 KEP ZINC | 7BF008 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 | No Image | 1/2 GROMMET FOR X8911 HANDLE | X9100 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 | No Image | Main Chassis, Weldment Assy SCE | X9012 | $205.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 | No Image | Label Qualified Made In The USA 1.618 X 1.618 | X1003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 45 | No Image | Label Serial Number 2X2 Plain | X8459 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 |  | Warning Label Dryer and Spotter | X8976 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 | | SCREW 1/4-20X1/2 SERRATED HEX SELF LKG FLANGE | X8209S | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | NUT, 10-24 HEX SS | X8241 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 49 | No Image | 28 CHAIN SCE ZINC PLATED ROLLED STEEL | X9144 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 50 | No Image | GROMMET LONG 70A DUROMETER | X9502 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 51 | No Image | Barb Elbow 90 1/4-1/8 | 7AT006 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 52 | No Image | Terminal Ring No 10 14-16 AWG | F21 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 53 |  | Upholstery Cleaning Kit for 98170 | 98170KNS | $469.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | No Image | LABEL, BRUSH WARNING SCE PFX900S | X9134 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Cable Tie 11 50 lb Black Tie | X8150 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Lid, Solution Tank SCE | X9081 | $22.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Label | X9206TOR | $0.00Read more |
| 5 | No Image | Housing Solution Black SCE | X9042REPRO1 | $135.39Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | Label | X9416 | $0.00Read more |
| 7 | Not Available | Defoamer Warning Label | X9003 | Not Available |
| 8 | No Image | Knob, Large Dome LID SCE | X9110 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | SCE DOME COVER WITH GASKET LARGE | X9034C | $62.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | Gasket, Large Dome Spacer | X91202 | $35.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | No Image | SCREW No 6 X 1/2 SS PAN HEAD PHIL | X8261SS | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | Dome, Small SCE | X9033 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | Gasket, Small Dome SCE 1/8 EPDM Med Density Foam W/PSA 1 Side | X9071 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | Standpipe Sub Assembly, Vacuum SCE | X9129SUB | $95.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Washer,Plain 2.00 ID SS | 18886 | $18.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Gasket Dump Valve .125 Thick 1.81 ID X 2.37 OD | PX14A | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | Not Available | Recovery Tank Kit | X1770 | Not Available |
| 18 | No Image | Bracket, Tank Mount 90 Dgre SCE | X9086 | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | | SCREW 1/4-20X1/2 SERRATED HEX SELF LKG FLANGE | X8209S | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | Hose, Vac 1.5X21 W/Cuffs SCE | X9092 | $59.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | No Image | Kit, Motor X1038 for 9 Gallon Extractor | X1038KIT9 | $217.99Read more |
| 22 | No Image | SET SCREW 1/4-20X3/16 SOC SET FLAT PT W/LOC-TITE | X8222 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | | Elbow Fitting Plastic 90 White 1.5 FPT | PX11A | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | | Bulkhead Plastic 1.5 NPT X 1.5 Hose Barb | PX25 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | | Expander, 1-1/4 To 1-1/2 Gray Cuff | K1123 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | 1/4-20 X 4-1/4 Grade 5 Hex Cap Screw Zinc | X2405 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 |  | WASHER, ID.299 OD.622 THK.055 ZINC PLATED | X8858 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | No Image | Screw TFT B PanHd Zn No.10 16x1/2 | 19565 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | No Image | Spacer, Vac Motor (98190) | 30070 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | No Image | Gasket, Flat Airwatt Motor 5/8in Neoprene Blend | X9740 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 | No Image | Bracket, Tank Mount SCE | X9085 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | No Image | LABEL OPERATING INSTRUCTION SCE PFX900S | X9057 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | LABEL TANK CAPACITY SCE NEW | X91251 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 | No Image | Float Cage, W/1 1/2 NPT Neck Heavy Ball | X9053 | $39.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | | Nut, Lock Die Cast 1.5 | PX46 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | Bushing, 1-1/2 X 1-1/4 Pvc Sch 40 Threaded | X9075 | $24.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | Gasket, Cover SCE | X9084 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 | No Image | Cover, Recovery Tank Float SCE | X9080 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | 12" Chain | X9068 | $0.00Read more |
| 40 | | SCREW, 10-24X1/2 PHIL PAN MS 18-8 SS | 7BS001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | | Filter,Pumps,SLS 1/2 FNPT 30X30 SST | X9294 | $6.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 | | Gasket Fiber 1.125 OD X .75 ID X .156 Thick | PX48G | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 | | Bulkhead, Fitting Brass .75 | PX48 | $28.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 | No Image | Washer 3/4 Neoprene-Bond Galvanized | 72274A | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 45 | | Barb, 1/2 Hose 1/4 NPT Male | 7AT004 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 | No Image | Hose 1/2 Wire Reinforced | 70079C | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 | No Image | Clamp 1/2 Worm Gear SS Hex Slot Phil SAE Size 6 | 7DL008 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | Clamp 1-1/2 Worm Gear SS Hex Slot Hd SAE Size 20 | 7DL005 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 49 | No Image | Clip Spring, Black | 72173A | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 50 | No Image | Screw A Point PH No. 10x1 Blk Zinc | X9098 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 51 | No Image | Cord, Extension 14/3 X 50FT 300V Yellow | 32217 | $148.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 52 | No Image | Harness, SCE 120V Rev05 | X9841 | $462.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 53 | No Image | Hose Drain PFX900S Cascade PFX1350 | PAS37 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 54 | | Nut Conduit 1/2 Part Number X8008N for Cleanmax Models CM-WAV | X8008N | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 55 | No Image | Circuit Breaker,Extractor,2.5Amp,125V-250VAC | X1192 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 56 | No Image | SCREW, 10-32X7/8 SOC SET CUP PT 18-8 STAINLESS | X9135 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 57 | | WASHER, No 10 FLAT S/S MS-15795 No. 841 | 7CM003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 58 | No Image | Housing, Control Panel Black SCE | X9043REPRO | $50.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 59 | No Image | Label, 3 Hole Switch Panel SCE | X9093 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 60 | No Image | Switch, Rocker SCE | X9007 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 61 | No Image | Drain Hose Plug Compatable With PAS37 Hose | PAS36 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 62 | No Image | SCREW, 10-32X3/4 PHIL PAN MS 18-8 SS | 7BR005 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 63 | No Image | NUT, CAP 10-32 SS | 7DN004 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 64 | No Image | Switch,Rocker W/ Paddle 15A 115V | X9200 | $33.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 65 | No Image | CORD CLAMP SCE PFX900S | X9111 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Elbow, Street .125 90 Degree Brass | SW139 | $10.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | | Valve Kit, 120 VAC Solenoid, 290 Psi | SW290KIT | $169.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | NIPPLE HEX 1/8X1/8 | 7CX001 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | BUSHING 1/4 - 1/8 NPT | 7AG002 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | No Image | Tee Union 1/4 NPT | 7AV001 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 |  | NIPPLE CLOSE 1/4 BRASS | PX32 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | No Image | Reducer, 3/8 To 1/4 | PC20 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | Pump,Extractor,110,VAC,120psi,Aquatec | AQ120 | $302.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 |  | Elbow, 1/2 H - 3/8 MPT | 71507A | $34.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | | WASHER, RUBBER .29ID .688OD 1/8 80 DURO | 72667A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 | No Image | Hose, 1/4 Braided, 250 PSI | 71817A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | SCREW, 10-24X3/8 PHIL PAN MS 18-8 SS | 72091A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | LABEL GROUND SYMBOL | X9214 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | | SCREW, 10-32X1/2 PHIL PAN MS 18-8 SS | 71651A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | | WASHER, No 10 INT TOOTH LOCK SS | 7CY001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Wheel 12x1-3/4 Blk with Gray Tire | X9066 | $57.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | No Image | Washer, Countersunk | X8020 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | No Image | WASHER, 1/4 SPLIT LOCK ZP | X8212 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | No Image | SCREW 1/4-20 X 3/4 FLAT PHIL MS ZINC | X8265 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | Nut 1/4-20 Lock Nylon Insert | X8237 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | No Image | NUT, 1/4-20 HEX SS | 7CN001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | No Image | WASHER 1/4 SPLIT LOCK SS | 7CL002 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | No Image | BOLT, 1/4-20 X 1 HEX SS | X8282 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | No Image | Tank Hinge PFX900S PFX1350 | X9014 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | No Image | SCREW, 1/4-20 X 1/2 HEX CAP | X8209 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | | Washer 1/4ID Tooth Part Number 7CY002 for Cleanmax Models CM-WAV,CM-WAV | 7CY002 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | No Image | Clamp 1/4 Worm Gear SS Hex Slot Phil SAE Size 4 | 7DL003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | | Barb, Hose 1/4 H - 1/4 M NPT | 7AT003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | | Washer-plain Part Number 19616 for Cleanmax Models CM-WAV | 19616 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | | Quick Disconnect, .25 Male/Male 2 Way Shut Off | PX5 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 | No Image | Door, Flip Hinge and Spring SCE | X9096 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | No Image | GASKET FLIP DOOR SCE 3/32EPDM PFX900S | X9097 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | Vac Shoe Tube SCE | X9009A | $276.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 | No Image | SET SCREW 1/4-20X3/16 SOC SET FLAT PT W/LOC-TITE | X8222 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | No Image | Hose 300PSI Solution 3/8 ID X 1/8 Wall | PX3H | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | Clamp Single Ear 18.5 mm | PX61A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | Barb 1/4 X 3/8 Male/Male | PX85 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 | | Quick Disconnect .25 Female | PX6 | $33.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | NUT, 10-32 KEP ZINC | 7BF008 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 | No Image | 1/2 GROMMET FOR X8911 HANDLE | X9100 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | No Image | Main Chassis, Weldment Assy SCE | X9012 | $205.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 | No Image | Label Qualified Made In The USA 1.618 X 1.618 | X1003 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 | No Image | Label Serial Number 2X2 Plain | X8459 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 | | Warning Label Dryer and Spotter | X8976 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 45 | | SCREW 1/4-20X1/2 SERRATED HEX SELF LKG FLANGE | X8209S | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 | No Image | NUT, 10-24 HEX SS | X8241 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 | No Image | 28 CHAIN SCE ZINC PLATED ROLLED STEEL | X9144 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | GROMMET LONG 70A DUROMETER | X9502 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 49 | No Image | Barb Elbow 90 1/4-1/8 | 7AT006 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| # | Part image | Description | SKU | Price |
| Not Shown | Not Available | Complete Brush Assembly | X9438 | Not Available |
| 1 | No Image | Hose, 1/4 Braided, 250 PSI | 71817A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Clamp 1/4 Worm Gear SS Hex Slot Phil SAE Size 4 | 7DL003 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Barb Hose 1/4H 1/8 Male | PC66 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Elbow, Union 1/8 NPT | 7AK003 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 | No Image | NIPPLE HEX 1/8X1/8 | 7CX001 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 |  | WASHER NYLON .50 ID X .75 OD X .130 THICK BLACK | X8293 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | No Image | WASHER, 3/8 USS FLAT 18-8 SS | 7CM004 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | LABEL SUPERIOR EDGE CLEANING SCE | X9128 | $3.99Read more |
| 9 | No Image | Manifold, Spray SCE | X9021 | $56.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | Minature Nozzle, And Body 1/8 NPT No 2 95 Degree SCE | X9139 | $40.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 |  | Screw Ph Truss HD No.10 24x3/4 ZP | 04735 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | SCREW, 1/4-20X1 PHIL PAN MS 18-8 SS | 7CU003 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | 3/4 UNVENTED LOCKING PLUG | X9174 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | No Image | Shield, Brush Bearing SCE | X9019 | $11.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | No Image | Guard, Brush Thread SCE | X9020 | $13.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | | SCREW, 10-32X1/2 PHIL PAN MS 18-8 SS | 71651A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | | WASHER, No 10 INT TOOTH LOCK SS | 7CY001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | No Image | Spacer, Brush Bearing Nylon SCE | X9018 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | No Image | Bearing, Brush SCE | X9001 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | No Image | Axle, Brush SCE | X9017 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | No Image | NUT, 10-24 HEX SS | X8241 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 |  | SCREW 10-24X1 PHIL PAN MS 18-8 SS | 7CU001 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | No Image | Brushroll, 3 Dia X 18 Chevron PFX900S | X9070 | $132.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | No Image | SCREW, 10-32 X 5/8 FLAT HD SS | X9118 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | No Image | Coverplate, Brush Motor SCE | X9015A | $17.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | Coverplate, Belt Brush Mtr SCE | X9015B | $34.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 | No Image | GASKET BELT COVER SCE REV03 | X9150 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | No Image | Gasket, Brush Motor Cover SCE | X9126 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | No Image | Drive Pulley, 24 Teeth SCE | X9117 | $41.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 30 | No Image | NUT, 10-32 HEX FLANGE SS 18-8SS | X9169 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 31 | No Image | Belt,Extractors,Self-Contained,Drive | X9004 | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 32 | No Image | Drive Pulley, 12 Tooth SCE W/2 8-32 Set Screws | X9116 | $22.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | No Image | Spacer, Motor SCE | X9099 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 |  | Brush Motor Extractor 120VDC .25hp 3dia SCE SMB004 | X9002 | $301.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | No Image | Weldment Assy, Brush Housing SCE | X9015 | $550.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | No Image | .25ID X .472 OD X .059 THK FLAT WASHER NYLON | 72241A | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | Nut 1/4-20 Lock Nylon Insert | X8237 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 38 |  | NUT, 10-24 NYLON INSERT LOCK ZINC | X8271 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | Rectifier, 1000 V 35 Amp, Previously 19182 | X1193 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 | No Image | NUT, 10-32 KEP ZINC | 7BF008 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 41 | No Image | 1/2 GROMMET FOR X8911 HANDLE | X9100 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 42 |  | SCREW, 10-32X3/8 PHIL PAN MS 18-8 SS | 7BH004 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 43 | No Image | Bracket, Brush Lift SCE | X9107 | $55.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 44 | No Image | E RING 1/4 SS SCE PFX900S | X9114 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 45 | No Image | Pedal, Brush Lift SCE | X9026 | $14.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 | No Image | SAFETY WALK TAPE 1X60 BLACK SCE PFX900S | X9122 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 47 | No Image | Spacer, Brush Lift Pedal SCE | X9027 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 48 | No Image | Pin Brush Foot Pedal SCE | X9030 | $3.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
Report errors on this page HERE
