Schematic and parts book for Tornado 97560T . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | Washer | 00851 | $0.00Read more |
| 2 | No Image | Lock Washer | 01574 | $0.00Read more |
| 3 | No Image | Screw 1/4-20 X 1" | 02046 | $0.00Read more |
| 4 | No Image | Nut Hex Jam Lock Nylock 1/4 20 ZP | 02217 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 5 |  | Washer 5/16 Plain ID ZP | 02568 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 6 | Not Available | Lock Washer | 03536 | Not Available |
| 7 | Not Available | Washer | 03736 | Not Available |
| 8 | No Image | Lock Washer | 07870 | $0.00Read more |
| 9 |  | SCREW, No 10 12 X 1/2 TFT (A) P.H. | 10677 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 10 | No Image | Nut Hex Jam 1/4 20 ZP | 10694 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 11 |  | Washer-plain .265 Id Part Number 14142 for Cleanmax Models CM-WAV | 14142 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 12 | Not Available | Nozzle Bar Clamp | 15061 | Not Available |
| 13 | No Image | Screw #10-24 X 1-3/4" | 15378 | $0.00Read more |
| 14 | No Image | Pad Retainer | 15887 | $0.00Read more |
| 15 | No Image | SCREW, 5/16 18 X 1 1/4 FLAT HD.SOCKET CAP SS BLACK | 16069 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 16 | No Image | Screw 3/8"-16 X 2" | 16479 | $0.00Read more |
| 17 |  | NUT 1/4 20 ACORN LOCK PT | 17130 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 18 | No Image | Shoulder Bolt ¼-20 x 1-3/4 | 18641 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 19 | No Image | WASHER, .500 PLAIN ID ZP | 18666 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 20 | | NUT-HEX LOCK (NYLON INSERT) #10-24 Part Number 19145 for Simplicity Models SCE | 19145 | |
| 21 |  | SCREW HEX FLANGE HEAD 5/16 18 X 3/4 (ZP) | 19196 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 22 |  | Screw Hex HD Cap 1/4 20x1/2 SS | 19240 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 23 | No Image | When Changing Pad This Side Up Label | 19652 | $0.00Read more |
| 24 | Not Available | Elbow Fitting 1/4" | 23517 | Not Available |
| 25 | No Image | Pad Driver 20" Propane | 30304 | $0.00Read more |
| 26 |  | Wheel, 6 Grey (Propane) | 30314 | $37.99Add to cart Special order: ships in 2 to 4 weeks |
| 27 |  | PIN CLEVIS (WHEEL) 5/16D X 2.6 LG (ZP) | 30315 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 28 |  | SPACER WHEEL 3/8 (NYLON) | 30316 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 29 |  | HAIRPIN COTTER .12 X 2.37 ZP | 30319 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 30 | No Image | Floor Pad Combo Burnishing 21in 5/case | CB0521 | $69.99Add to cart Special order: ships in 2 to 4 weeks |
| 31 | No Image | Pulley | 30330 | $0.00Read more |
| 32 | Not Available | Pulley Bushing | 30332 | Not Available |
| 33 |  | WASHER PLAIN 7/16 ID (ZP) | 30335 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 34 | No Image | WASHER SPRING LOCK 7/16 | 30340 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 35 | No Image | SCREW HEX HD CAP 1/4 20 X 5/8 (ZP) | 30354 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 36 | No Image | Caster Wheel | 30355 | $0.00Read more |
| 37 | No Image | Felt Back Battery Tray Propane | 30368 | $5.99Add to cart Special order: ships in 2 to 4 weeks |
| 38 | No Image | FELT TANK RET. BACK (PROPANE) | 30377 | $6.99Add to cart Special order: ships in 2 to 4 weeks |
| 39 |  | Control, Throttle (Propane) | 30394 | $104.99Add to cart Special order: ships in 2 to 4 weeks |
| 40 | No Image | Steel Propane Tank | 30396 | $0.00Read more |
| 41 | No Image | SCREW, HEX HD CAP 7/16 20 X 1.75 ZP | 30557 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 42 | No Image | Digital Hour Meter | 30561 | $0.00Read more |
| 43 |  | Key Shaft ZP Propane | 30609 | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 44 | No Image | Square Key 1/4" X 1" | 30614 | $0.00Read more |
| 45 | No Image | Belt Tension Adjustment Assembly | 30662 | $0.00Read more |
| 46 | No Image | BOLT, 3/8 16 X 2 3/4 HEX TAP FULL THREAD ZP | 31127 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 47 | No Image | Propane Fuel Lock Valve | 31157 | $0.00Read more |
| 48 |  | Coupling Tank 97430 | 31158 | $40.99Add to cart Special order: ships in 2 to 4 weeks |
| 49 | No Image | Hose, 20 Male/Female (Fuel) | X9593 | $62.99Add to cart Special order: ships in 2 to 4 weeks |
| 50 | No Image | FITTING BARB 90 DEG. 1/8NPT TP 1/4 HOSE | 31161 | $14.99Add to cart Special order: ships in 2 to 4 weeks |
| 51 | No Image | Vacuum Hose | 31162 | $0.00Read more |
| 52 |  | RELAY 12V DC 4 TERMINAL TROMBETTA CONTACTOR | 31453 | $48.99Add to cart Special order: ships in 2 to 4 weeks |
| 53 | No Image | Bushing Engine Propane | 32119 | $28.99Add to cart Special order: ships in 2 to 4 weeks |
| 54 | No Image | Oil Plug (Kawasaki Propane) | 32149 | $0.00Read more |
| 55 | No Image | Plastic Washer | 32163 | $0.00Read more |
| 56 | No Image | Plastic Front End Assembly (Propanes) | 32208 | $0.00Read more |
| 57 | No Image | Neoprene Hose 3/8" I.D. X 9/16" O.D. X 7" (Oil Drain Hose) | 32248 | $0.00Read more |
| 58 |  | Regulator, Vapor Kawasaki Engine (CandT) | 32270 | $563.99Add to cart Special order: ships in 2 to 4 weeks |
| 59 | No Image | Drive Belt B44 | 32279 | $0.00Read more |
| 60 | No Image | Engine Pulley (Propane) | 32376 | $0.00Read more |
| 61 | No Image | ELBOW 90 DEG 5/8 18 MALE X 1/4 NPT (BRASS) | 32398 | $7.99Add to cart Special order: ships in 2 to 4 weeks |
| 62 |  | BATTERY,Burnisher,12,AGM,18A | 32401 | $191.99Add to cart Special order: ships in 2 to 4 weeks |
| 63 | No Image | Spacer | 32405 | $0.00Read more |
| 64 | No Image | SCREW HEX HD CAP 7/16 14 X 1 1/2 (ZP) | 32482 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 65 | No Image | Deck 21" Propane | 33456 | $0.00Read more |
| 66 | No Image | SCREW, 5/16-18X1/2 L BTTN | 33457 | $2.99Add to cart Special order: ships in 2 to 4 weeks |
| 67 | No Image | Handle, Assembly Propane | 33458 | $74.99Add to cart Special order: ships in 2 to 4 weeks |
| 68 | Not Available | Screw 1/4-20 x 1-1/4" | 33461 | Not Available |
| 69 | No Image | Propane Tank Holder Assembly | 33464 | $0.00Read more |
| 70 |  | Carbon Brush - Ametek 240 Motor For: ametek | 33465 | $17.79Add to cart Special order: ships in 2 to 4 weeks |
| 71 | No Image | Tank Strap | 33466 | $0.00Read more |
| 72 | No Image | Plug 1/2" | 33469 | $0.00Read more |
| 73 | No Image | Propane Battery Box | 33482 | $0.00Read more |
| 74 | No Image | Propane Battery Box Cover | 33483 | $0.00Read more |
| 75 | No Image | Wiring Harness | 33485 | $0.00Read more |
| 76 |  | SWITCH AND KEY PROPANE D473 W/805 | 33486 | $30.99Add to cart Special order: ships in 2 to 4 weeks |
| 77 | No Image | SCREW, 1/4-20X3/4L | 33489 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 78 |  | WASHER, 0.313, LOCK | 33490 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 79 |  | Filter,Burnisher,Bonnet,9 Inch Wide by 3 Inch High | 33887 | $8.99Add to cart Special order: ships in 2 to 4 weeks |
| 80 |  | FUEL HOSE | 33922 | $24.99Add to cart Special order: ships in 2 to 4 weeks |
| 81 | No Image | Wheel Bracket | 33924 | $0.00Read more |
| 82 | No Image | Kawasaki Propane Engine Fs481V 603Cc | 322688 | $0.00Read more |
| 83 | No Image | Clamp 1-1/2 Worm Gear SS Hex Slot Hd SAE Size 20 | 7DL005 | $8.99Add to cart Special order: ships in 2 to 4 weeks |
| 84 | No Image | Clamp 1/2 Worm Gear SS Hex Slot Phil SAE Size 6 | 7DL008 | $4.99Add to cart Special order: ships in 2 to 4 weeks |
| 85 | No Image | Catalytic Converter, Fs481V | X9625 | $0.00Read more |
| 86 | No Image | Exhaust Manifold Fs481V | X9626 | $0.00Read more |
| 87 | No Image | ELBOW 90 DEG. BRASS 3/8 NPT X 1/2 BARB | X9632 | $11.99Add to cart Special order: ships in 2 to 4 weeks |
| 88 | No Image | HOSE, FUEL 1/2 ID X 25 L | X9633 | $15.99Add to cart Special order: ships in 2 to 4 weeks |
| 89 | No Image | Filter Cage | X9636 | $0.00Read more |
