Schematic and parts book for Tornado 68674 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 |  | SWITCH PUSH BUTTON 20AMP S.P.N.O. | 06685 | $95.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Closed End Crimp Terminal | 06824 | $0.00Read more |
| # | Part image | Description | SKU | Price |
| 1 | No Image | SCREW PHIL. FLAT HD MACH No 8 32 X 7/16 (ZP) | 02495 | $24.99Read more |
| 2 | No Image | Keps Nut | 02956 | $0.00Read more |
| 3 |  | Ring Retaining Ext E 1/2 Heavy Duty | 03470 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Washer | 10373 | $0.00Read more |
| 5 |  | WASHER Part Number 12554 for Simplicity Models SCE,SCE | 12554 | $2.19Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 |  | Washer 1/2 ID ZP | 12957 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | | Washer-plain .265 Id Part Number 14142 for Cleanmax Models CM-WAV | 14142 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | No Image | Spacer | 15313 | $0.00Read more |
| 9 | No Image | Screw 5/16-18 X 1-1/2" | 16031 | $0.00Read more |
| 10 | No Image | Nyloc Nut | 19337 | $0.00Read more |
| 13 |  | WHEEL BLUE 5X1.25 5/16 BORE | 19447 | $25.99Read more |
| 15 | No Image | Bracket Groove Handle WAV Extractor Black Plastic | 19798P | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | No Image | Axle 13-3/8" | 31616 | $0.00Read more |
| # | Part image | Description | SKU | Price |
| 1 |  | NUT, 1/4 20 ACORN NICKEL | 00685 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | NUT, No 10 24 FINISHED HEX ZP | 01477 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Lock Washer | 01574 | $0.00Read more |
| 4 | No Image | Hog Ring | 01608 | $0.00Read more |
| 5 | Not Available | Lock Washer | 01713 | Not Available |
| 6 | No Image | Screw #8-32 X 3/8" | 01896 | $0.00Read more |
| 7 | No Image | Screw #10-32 X 3/8" | 03261 | $0.00Read more |
| 8 | No Image | Screw #10-24 X 7/16" | 03660 | $0.00Read more |
| 9 | No Image | Screw 1/4-20 X 3/4" | 07532 | $0.00Read more |
| 9 | | SWITCH PUSH BUTTON 20AMP S.P.N.O. | 06685 | $95.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | Screw 1/4-20 X 3/4" | 07532 | $0.00Read more |
| 11 | No Image | Nut Hex Lock P/T 1/4 20 | 07533 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | No Image | Screw Socket HD Shoulder 5/16D x 1-1/2 ZP | 08079 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | Cable Hook Assembly | 10407 | $0.00Read more |
| 14 | No Image | Nut Hex Jam 1/4 20 ZP | 10694 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 |  | Nut 10-24 Nylon Insert Lock Zn | 10894 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Strain Relief Bushing 7W 2 | 12047 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | No Image | Strain Relief Washer | 15226 | $0.00Read more |
| 18 | No Image | Lock Lever Return Spring | 17157 | $0.00Read more |
| 21 | No Image | Washer | 17245 | $0.00Read more |
| 23 | No Image | Switch Activation Lever | 18969 | $0.00Read more |
| 24 | No Image | Screw 1/4" X 1" | 18991 | $0.00Read more |
| 25 | No Image | Washer | 19211 | $0.00Read more |
| 28 | No Image | Lever Lock (Start Guard) | 19651 | $0.00Read more |
| 29 | No Image | Bracket Groove Handle WAV Extractor Black Plastic | 19798P | $16.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | No Image | Handle Tube Cord 14/3 X 46" | 14545 | $0.00Read more |
| 36 | No Image | Closed End Crimp Terminal | 06824 | $0.00Read more |
