Schematic and parts book for Tornado 66224 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | Washer | 00851 | $0.00Read more |
| 2 | No Image | SCREW PHIL. PAN HD MACH No 8 32 X 5/8 (ZP) | 01451 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Nut | 01497 | $0.00Read more |
| 4 | Not Available | Screw 1/4-20 x 1-1/2" | 01978 | Not Available |
| 5 | No Image | Gasket | 02941 | $0.00Read more |
| 6 | No Image | Keps Nut | 02956 | $0.00Read more |
| 7 | No Image | Screw 1/4-20 X 1/2" | 04442 | $0.00Read more |
| 8 | No Image | Push Nut | 07539 | $0.00Read more |
| 9 | No Image | Washer Sealing 1/4 | 07741 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | No Image | Cotter Pin | 09087 | $0.00Read more |
| 11 | No Image | Washer | 10260 | $0.00Read more |
| 12 | No Image | Swivel Caster | 10669 | $0.00Read more |
| 13 |  | Nut Hex.Lock #10, 24 Part Number 10892 for Cleanmax Models CM-WAV | 10892 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 |  | Washer-sealing Part Number 11385 for Cleanmax Models CM-WAV | 11385 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | | WASHER Part Number 12554 for Simplicity Models SCE,SCE | 12554 | $2.19Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 | No Image | Screw #10-12 X 3/8" | 13330 | $0.00Read more |
| 17 | Not Available | Screw 1/4-20 x 2-1/2' | 07868 | Not Available |
| 18 | No Image | Wheel 4" X 1-1/4" | 14817 | $0.00Read more |
| 19 |  | Plug, Retained Plug Drain Hose | 16089 | $47.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 20 | | CLAMP Part Number 16091 for Simplicity Models SCE,SCE | 16091 | $7.69Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | No Image | Keps Nut | 16129 | $0.00Read more |
| 22 | No Image | SCREW PHIL. TRUSS HD 1/4 20 X 3/4 (ZP) | 16619 | $1.99Read more |
| 23 | No Image | Drain Hose Retaining Bracket | 17273 | $0.00Read more |
| 24 | No Image | Screw Ph Truss HD No.10 24x1/2 SS | 17848 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 |  | Nozzle Drain Hose HM 4000 and F/KS | 18563 | $17.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 27 |  | Washer Plain 1/4 ID SS | 18885 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 |  | Washer-plain Part Number 19616 for Cleanmax Models CM-WAV | 19616 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 29 | No Image | FLOAT (BLK) ORDER W/ 30631 | 30234 | $70.99Read more |
| 30 | No Image | Gasket | 30239 | $0.00Read more |
| 31 | No Image | Gasket | 30240 | $0.00Read more |
| 32 | No Image | SWITCH ROCKER ON/OFF(DP) (WETDRY) 10A/250,15/125 | 30241 | $62.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | Not Available | Filter | 30244 | Not Available |
| 34 | No Image | Plastic Latch | 30245 | $0.00Read more |
| 35 | No Image | PIN CLEVIS 1/2D X 4 3/4 LONG (ZP) | 30248 | $9.99Read more |
| 36 |  | Motor Extractor 115 VAC Bypass SS 2stg 50 60hz | 14800 | $245.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 37 | No Image | Bellows Hose 1-1/2" X 10-3/8" | 30253 | $0.00Read more |
| 38 | No Image | GASKET MAIN COVER .375 CLSD CELL 94220 PE FOAM W/PSA | 30255 | $9.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 39 | No Image | HOSE POLYETHYLENE (BLK) 1 1/2 X 96 W/CUFF | 30257 | $48.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 40 | No Image | Wand Friction Fit 1-1/2" X 54" (2 Pc Set) | 30258 | $0.00Read more |
| 41 | No Image | Squeegee Assembly | 30486 | $0.00Read more |
| 42 | No Image | COVER VAC (BLK) ORDER W/ 30234 | 30631 | $143.99Read more |
| 70 | No Image | 1-1/2" Upholstery Tool | 90711 | $0.00Read more |
| 71 | Not Available | 1-1/2" Round Dust Brush | 90712 | Not Available |
| 72 | No Image | 1-1/2" Bare Floor Tool | 90714 | $0.00Read more |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Washer | 00696 | $0.00Read more |
| 2 | No Image | Washer | 00851 | $0.00Read more |
| 3 | No Image | Washer Spring 3/8 3 Wave | 07132 | $0.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | | Washer-plain .265 Id Part Number 14142 for Cleanmax Models CM-WAV | 14142 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 |  | NUT 1/4 20 ACORN LOCK PT | 17130 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | | NUT, THUMB 5/16-18 Part Number 18119 for Simplicity Models SCE | 18119 | $8.79Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 |  | Channel, Outer 28 Rev01 Squeegee | 18136 | $247.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 |  | Wheel 1-5/8dia Blk Rubber | 18400 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | No Image | Squeegee Blade Retainer | 18663 | $0.00Read more |
| 10 | No Image | SCREW, 1/4 20 X 2 1/4 FLAT HEAD CAP SS | 18680 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 11 |  | Screw Flat Head Cap 5/16 18x1-3/4 SS | 18681 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 |  | Squeegee,Auto Scrubber,Blade,set,QTY 2 | 18709 | $145.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | No Image | Wheel Bumper 3 x 7/8 Grey | 30044 | $15.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 |  | Pin Clevis .320dia 1-1/4in | 30226 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 |  | Pin Cotter 5/64x1/2 STL ZP Ext Prong | 30227 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
