Schematic and parts book for Smart 360 s9 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Front cover | N/A | Not Available |
| 2 | Not Available | Lidar assembly | F30500105 | Not Available |
| 3 | No Image | Brush, Cleaning Brush S9 Ea Part Number: F30500124 for Smart 360 | F30500124 | $2.75Read more |
| 4 | No Image | Dust Box, Assembly S9 Part Number: F30500115 for Smart 360 | F30500115 | $20.88Read more |
| 5 |  | Tank, Water Tank S9 500116 Ea Part Number: F30500116 for Smart 360 | F30500116 | $13.95Read more |
| 6 | Not Available | Base cover | N/A | Not Available |
| 7 | No Image | Motor, Side Brush Assembly S9 YX0-X90S-025 Ea Part Number: F30100126 for Smart 360 | F30100126 | $12.23Read more |
| 8 |  | Brush, Side Sweeping S9 Part Number: F30500111 for Smart 360 | F30500111 | $2.75Read more |
| 9 | No Image | Wheel, Front Assembly S9 Part Number: F30500110 for Smart 360 | F30500110 | $3.50Read more |
| 10 | Not Available | Decorative plate | N/A | Not Available |
| 11 | Not Available | Mop bracket assembly | F30500117 | Not Available |
| 12 | Not Available | Wet mop cloth | F30500121 | Not Available |
| 13 | Not Available | Filter bracket | F30500123 | Not Available |
| 14 |  | Filter, Assembly S9 Includes Bracket & Filter Part Number: F30100325 for Smart 360 | F30100325 | $11.81Read more |
| 15 | No Image | Fan, Assembly S9 Part Number: F3010835 for Smart 360 | F3010835 | $46.66Read more |
| 16 | Not Available | Mop bracket Hall small board | F3010834 | Not Available |
| 17 | No Image | Dust Box, Hall Small Board S9 Part Number: F3010832 for Smart 360 | F3010832 | $0.06Read more |
| 18 | Not Available | Water tank Hall small board | F3010833 | Not Available |
| 19 | Not Available | Main_PCBA | F30500106 | Not Available |
| 20 | Not Available | Anti-collision sensor assembly (including wire and sensor) | F30100371 | Not Available |
| 21 | Not Available | Front collision assembly | N/A | Not Available |
| 22 | Not Available | Ground inspection sensor assembly (including wire and sensor) | F30100348 | Not Available |
| 23 | No Image | Kit, Pump Assembly S9 (Pump, Pipe, Sink & Shower) Part Number: F3010882 for Smart 360 | F3010882 | $32.92Read more |
| 24 | No Image | Battery, :( S9 LiON Ea Part Number: F30500107 for Smart 360 | F30500107 | $100.83Read more |
| 25 | No Image | Wheel, Left Assembly S9 Part Number: F30500108 for Smart 360 | F30500108 | $31.89Read more |
| 26 | No Image | Wheel, Right Assembly S9 Part Number: F30500109 for Smart 360 | F30500109 | $31.89Read more |
| 27 | Not Available | Charging dock | F30500118 | Not Available |
| 28 | Not Available | Middle sweeping assembly | F30500112 | Not Available |
| 29 |  | Brush, Middle Sweeping Assembly S9 Part Number: F30500113 for Smart 360 | F30500113 | $9.55Read more |
| 30 | Not Available | Middle sweeping bracket assembly | F30500114 | Not Available |
| 31 | Not Available | Robot Vaccum Overseas S9 Overseas version remote control + button battery | F30100287 | Not Available |
| 32 | Not Available | Robot Vaccum Overseas S9 Overseas version adapter | F30500125 | Not Available |
| 33 | Not Available | Robot Vaccum Overseas S9 Moisture-proof pad | F30500103 | Not Available |
