Schematic and parts book for Sharp TU5907, TU5909, TU5910 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Main Body 5- | SH-75111 | Not Available |
| 1 | Not Available | Nut | SH-77035 | Not Available |
| 1 | Not Available | Paper Bag PU2 3 Pk 5- | SH-1405 | Not Available |
| 1 | No Image | Paper Bag, DVC Sharp PU2 Microlined 3Pk | SHR-14355 | $8.79Read more |
| 2 | Not Available | Valve Cover 5- | SH-75615 | Not Available |
| 2 | Not Available | Retaining Ring | SH-77039 | Not Available |
| 3 | Not Available | Lens 5- | SH-PLNS-A015VBFA | Not Available |
| 3 | Not Available | Screw; 3mm x 10mm | SH-77800 | Not Available |
| 4 | Not Available | Filter Cover Right 5- | SH-GC0V-A457VBFL | Not Available |
| 4 | Not Available | Screw; 4mm x 16mm | SH-77055 | Not Available |
| 5 | Not Available | Filter Cover Left TU5909 TU5910 | SH-GC0V-A458VBFL | Not Available |
| 5 | Not Available | Screw; 4mm x 20mm | SH-77070 | Not Available |
| 6 | Not Available | Dust Cover TU5907 5- | SH-GC0V-A571VBRA | Not Available |
| 6 | Not Available | Dust Cover TU5909 TU5910 5- | SH-GC0V-A572VBRA | Not Available |
| 6 | Not Available | Screw; 4mm x 12mm | SH-XZPSF40P12000 | Not Available |
| 7 | Not Available | Clamp Knob 5- | SH-JKNB-A070VBFG | Not Available |
| 7 | Not Available | Screw; 4mm x 12mm | SH-77022 | Not Available |
| 8 | Not Available | Panel Ass'y TU5907 TU5909 TU5910 | SH-FPNL-A109VBK0 | Not Available |
| 8 | Not Available | Panel TU5909 5- | SH-HPNL-A051VBFE | Not Available |
| 8 | Not Available | Special Tap. Screw | SH-XZPSD40P14000 | Not Available |
| 8 | Not Available | Panel TU5910 5- | SH-HPNL-A053VBFC | Not Available |
| 9 | Not Available | Nut (Left-Hand Thread) | SH-77110 | Not Available |
| 9 | Not Available | Slide Knob 5- | SH-JKNB-A078VBFA | Not Available |
| 10 | Not Available | Screw; 3mm x 16mm | SH-77065 | Not Available |
| 10 | Not Available | Head Cover 5- | SH-GC0V-A570VBRA | Not Available |
| 11 | Not Available | Retaining Ring | SH-77038 | Not Available |
| 11 | Not Available | Decoration Plate TU5909 5- | SH-HDECQA016VBE0 | Not Available |
| 11 | Not Available | Decoration Plate TU5910 5- | SH-HDECQA017VBE0 | Not Available |
| 12 | Not Available | Washer | SH-XWHSD50-08100 | Not Available |
| 12 | Not Available | Main Switch Knob 5- | SH-70752 | Not Available |
| 13 | Not Available | Screw; 4mm x 8mm TU5910 | SH-XZPSD40P08000 | Not Available |
| 13 | Not Available | Hose Hanger 5- | SH-70778 | Not Available |
| 14 | Not Available | Washer | SH-LX-WZA034VBE0 | Not Available |
| 14 | Not Available | Motor Cover 5- | SH-75069 | Not Available |
| 15 | Not Available | Speed Nut | SH-77050 | Not Available |
| 15 | Not Available | Nozzle Head (With Washer) TU5910 | NLA | Not Available |
| 16 | Not Available | Special Screw; | SH-LX-WZA014VBE0 | Not Available |
| 16 | Not Available | Bumper 5- | SH-RH0G-A011VBFA | Not Available |
| 17 | Not Available | Special Tap. Screw | SH-XZPSD30P08000 | Not Available |
| 17 | Not Available | Upholstery Nozzle Brush TU5909 TU5910 | SH-52530 | Not Available |
| 18 | Not Available | Upholstery Nozzle W/Brush 5- | SH-52030 | Not Available |
| 18 | Not Available | Bottom Plate Fixing Screw | SH-77005 | Not Available |
| 19 | Not Available | Metal Wand Ass'y 5- | SH-50025 | Not Available |
| 19 | Not Available | Screw; 4mm x 16mm | SH-77080 | Not Available |
| 20 | Not Available | Body Cap 5- | SH-PCAP-A037VBFA | Not Available |
| 20 | Not Available | Washer; (Agitator) | SH-LX-WZA037VBE0 | Not Available |
| 21 | Not Available | Hose Ass'y 5- | SH-73305 | Not Available |
| 21 | Not Available | Washer; (Hanger) | SH-77020 | Not Available |
| 22 | Not Available | Blow Hose 5- | SH-75064 | Not Available |
| 22 | Not Available | Handle Fixing Screw | NLA | Not Available |
| 23 | Not Available | Right Grip 5- | SH-70250 | Not Available |
| 23 | Not Available | Washer; (Wheel) | SH-77025 | Not Available |
| 24 | Not Available | Left Grip 5- | SH-70251 | Not Available |
| 24 | Not Available | Spring Pin | SH-LPIN-A019VBE0 | Not Available |
| 25 | Not Available | Handle Pipe 5- | SH-70005 | Not Available |
| 25 | Not Available | Screw; 4mm x 10mm | SH-XZPSD40P10000 | Not Available |
| 26 | Not Available | Crevice Tool 5- | SH-54015 | Not Available |
| 26 | Not Available | Screw; 3mm x 20mm | SH-77105 | Not Available |
| 27 | Not Available | Screw; 4mm x 35mm | SH-77075 | Not Available |
