Schematic and parts book for sanyo U129, u127, u128 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| XX | Not Available | Carbon Brush Ass'y (Not Shown) | 63000 | Not Available |
| XX | No Image | Squeegee, Front, 30 Inch | 75017 | $78.99Add to cart Special order: ships in 2 to 4 weeks |
| XX | No Image | Handle Rod, for SOFTCASE | 75033 | $24.00Read more |
| XX | Not Available | Rocker Switch U127 (Not Shown) 67 SA-74001 Caution Label | 34010 | Not Available |
| XX | Not Available | Handle Grip Switch Plug U127 75 SA-18000 Electrostatic Final Filter U128 U129 | 70752 | Not Available |
| 1 | Not Available | Slide Knob U129 | 34515 | Not Available |
| 2 | No Image | Pulley, Motor, Drive | 75205 | $120.99Read more |
| 2 | Not Available | Case Cover U128 | 75207 | Not Available |
| 2 | No Image | Bracket, Retaining, Trans | 75025 | $39.99Add to cart Special order: ships in 2 to 4 weeks |
| 3 | Not Available | Power Adjustment Cam U129 | 34520 | Not Available |
| 4 | Not Available | Dust Box Packing | 76005 | Not Available |
| 5 | Not Available | Screw 4x20 Pan | 77245 | Not Available |
| 6 | Not Available | Screw 4x16 | 77120 | Not Available |
| 7 | No Image | Retainer, Squeegee Rear, 40 Inch | 75210 | $138.99Read more |
| 7 | Not Available | Clamp Knob U128 | NLA | Not Available |
| 7 | No Image | Fitting, Modified 1.5 Inch Squeegee hose | 75054 | $69.99Add to cart Special order: ships in 2 to 4 weeks |
| 8 | Not Available | Spring | 77130 | Not Available |
| 9 | No Image | Ring, Retaining, Int, 1.12 Dia | 75215 | $8.99Add to cart Special order: ships in 2 to 4 weeks |
| 9 | No Image | Spacer, Idler, Plain | 75220 | $27.99Add to cart Special order: ships in 2 to 4 weeks |
| 9 | No Image | Spacer Lift Arm | 75225 | $49.99Read more |
| 10 | Not Available | Wire Connector | SS-3270 | Not Available |
| 11 | No Image | WAND TELESCOPIC CK 14 1 PRO 98147 | 36000 | $47.99Add to cart Special order: ships in 2 to 4 weeks |
| 12 | Not Available | Bag Door Gasket | 76006 | Not Available |
| 13 | No Image | Foam Barrier Noise | 75055 | $22.99Add to cart Special order: ships in 2 to 4 weeks |
| 14 | Not Available | Lead Wire (White) U128 U129 | 36002 | Not Available |
| 15 | Not Available | Paper Bag 3 Pk | 1401 | Not Available |
| 16 | Not Available | Indicator Ass'y U128 U129 | 75010 | Not Available |
| 17 | No Image | Squeegee, Front, 30 Inch, Ureth (Optl) | 75019 | $147.99Add to cart Special order: ships in 2 to 4 weeks |
| 18 | Not Available | Control Circuit Ass'y U129 | 34000 | Not Available |
| 19 | Not Available | Bleeder Valve Ass'y U128 U129 | 75014 | Not Available |
| 20 | No Image | Axle, Wheel, Squeegee | 75016 | $160.99Add to cart Special order: ships in 2 to 4 weeks |
| 21 | Not Available | Lead Wire (Black) U127 | 36020 | Not Available |
| 21 | Not Available | Lead Wire (Black) U128 U129 | 36005 | Not Available |
| 22 | Not Available | Screw U128 U129 3X20 Pan | 77040 | Not Available |
| 23 | No Image | Squeegee, Rear, 30 Inch | 75018 | $121.99Add to cart Special order: ships in 2 to 4 weeks |
| 24 | Not Available | Micro Switch U128 U129 | 34005 | Not Available |
| 25 | Not Available | Screw 4x16 | 77024 | Not Available |
| 26 | No Image | Dual Downpressure Lever | 75078 | $0.00Read more |
| 26 | No Image | Gasket, Motor Mounting SC3683D Part Number: 75079 for Eureka | 75079 | $10.28Read more |
| 27 | Not Available | Lower Cord Hook | 70350 | Not Available |
| 28 | Not Available | Handle Tube | 70002 | Not Available |
| 29 | Not Available | Hose Hook | NLA | Not Available |
| 30 | Not Available | Screw 4x20 Pan | 77115 | Not Available |
| 31 | Not Available | Handle Grip Right | 70250 | Not Available |
| 32 | Not Available | Switch Rod U128 U129 | NLA | Not Available |
| 33 | Not Available | Switch Knob U128 U129 | 35525 | Not Available |
| 34 | Not Available | Leaf Spring U128 U129 | 34506 | Not Available |
| 35 |  | Handle, Lower Hose EXL/MG Series Part Number: 70252 for Compact | 70252 | $37.71Read more |
| 36 | Not Available | Upper Cord Hook | 70510 | Not Available |
| 37 | Not Available | Spring | 70505 | Not Available |
| 38 | Not Available | Washer | 77005 | Not Available |
| 39 | Not Available | Screw 4x25 Pan | 77015 | Not Available |
| 40 | Not Available | Caution Label | 74000 | Not Available |
| 41 | Not Available | Hose Inlet | 75405 | Not Available |
| 42 | Not Available | Nozzle To Bag Housing Hose | NLA | Not Available |
| 43 |  | Screw-thumb With Shoulder #10- 32 X 1/2 Part Number 30018 for Cleanmax Models CM-WAV | 30018 | $1.99Add to cart Special order: ships in 2 to 4 weeks |
| 43 | Not Available | Power Cord 30' U128 | 30007 | Not Available |
| 43 | Not Available | Power Cord 35' U129 | 30001 | Not Available |
| 43 |  | Cord Gray W/ Polorized Plug fit all fit-all | FA3035 | $32.99Read more |
| 44 | Not Available | Handle Screw | 77150 | Not Available |
| 45 | Not Available | Wire Connector | SS-3270 | Not Available |
| 46 | No Image | Charger 24V 25A Universal Flooded/Agm/Gel | 75045 | $849.99Add to cart Special order: ships in 2 to 4 weeks |
| 47 |  | Guide, Lever | 75057 | $37.99Add to cart Special order: ships in 2 to 4 weeks |
| 48 | Not Available | Attachment Support | NLA | Not Available |
| 49 | Not Available | Caution Label | 74045 | Not Available |
| 50 | Not Available | Name Plate U127 | 74036 | Not Available |
| 50 | Not Available | Name Plate U128 | 74039 | Not Available |
| 50 | Not Available | Name Plate U129 | 74043 | Not Available |
| 51 | Not Available | Lead Wire U129 Only | 36004 | Not Available |
| 52 | Not Available | Wand Holder Upper | NLA | Not Available |
| 53 | Not Available | Wand Holder Lower | NLA | Not Available |
| 54 | Not Available | Axle Rear | 71010 | Not Available |
| 55 | Not Available | Washer | 77100 | Not Available |
| 56 | Not Available | Wheel Rear | 71003 | Not Available |
| 57 | Not Available | E Ring | 77215 | Not Available |
| 58 | No Image | Bracket, Support, Head | 75026 | $147.99Read more |
| 59 | No Image | Bracket, Link, Squeegee | 75030 | $210.99Read more |
| 59 | No Image | Wheel Only, Caster 4in | 75241 | $80.99Add to cart Special order: ships in 2 to 4 weeks |
| 60 | No Image | Panel, Electronics | 75242 | $137.99Read more |
| 61 | No Image | Bearing, .5 Id, 1.1875 Od | 75243 | $95.99Add to cart Special order: ships in 2 to 4 weeks |
| 62 | Not Available | Secondary Filter | 18005 | Not Available |
| 63 | No Image | Cable Sleeve 4,0Qmm | 34415 | $2.10Read more |
| 64 | Not Available | Screw 4x12 Pan | NLA | Not Available |
| 65 | Not Available | Spring | 77130 | Not Available |
| 66 | No Image | Knob, Oval, .31-18 | 75070 | $16.99Add to cart Special order: ships in 2 to 4 weeks |
| 67 | Not Available | Caution Label | 74001 | Not Available |
| 68 | Not Available | Motor Cushion Front | 76002 | Not Available |
| 69 | Not Available | Motor Ass'y | 60002 | Not Available |
| 70 | Not Available | Lead Wire (Black) | 36008 | Not Available |
| 71 | Not Available | Motor Cushion Rear | 62012 | Not Available |
| 72 | Not Available | Lead Wire (Black) U128 U129 | 36010 | Not Available |
| 73 | Not Available | Lead Wire (White) U127 U128 | 36012 | Not Available |
| 73 | Not Available | Lead Wire U129 | NLA | Not Available |
| 74 | Not Available | Lower Housing Gasket | 76014 | Not Available |
| 75 |  | Belt-Bissell - Style 8 - 14 Lift Off Upright For: bissell | 18002 | $6.00Add to cart Special order: ships in 2 to 4 weeks |
| 75 | Not Available | Electrostatic Final Filter U128 U129 | 18000 | Not Available |
| 76 | No Image | Spring Compr .62L X .66Dia | 75228 | $9.99Read more |
| 76 | Not Available | Filter Cover U128 | 73401 | Not Available |
| 76 | Not Available | Filter Cover U129 | 75009 | Not Available |
| 77 | Not Available | Exhaust Filter | 18015 | Not Available |
| 78 | No Image | Strap, Grounding, Static | 75230 | $41.99Read more |
| 78 | Not Available | Motor Cover U128 | 75232 | Not Available |
| 78 | No Image | Controller, I-Drive, Mid | 75234 | $840.99Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| XX | Not Available | Bottom Plate Ass'y | 76010 | Not Available |
| XX | Not Available | Agitator Ass'y U129 | 20000 | Not Available |
| XX | Not Available | Belt Guide U127 U128 (Not Shown) | 73476 | Not Available |
| XX | Not Available | Belt Guide U127 U128 (Not Shown) | 73408 | Not Available |
| 1 | Not Available | Bearing Holder Cap | 62090 | Not Available |
| 2 | Not Available | Special Nut | 77170 | Not Available |
| 3 | Not Available | Lock Washer | 77163 | Not Available |
| 4 | Not Available | Bearing Holder Pulley End | 20507 | Not Available |
| 5A | Not Available | Washer | 77165 | Not Available |
| 6 | Not Available | Screw 3x25 Pan | 77155 | Not Available |
| 7 | Not Available | Edge Cleaner Pulley End U127 U128 | 20508 | Not Available |
| 7 | Not Available | Edge Cleaner Pulley End U129 | 20500 | Not Available |
| 8 | Not Available | Holder Plate U129 | 20501 | Not Available |
| 9 | Not Available | Idler Pulley U129 | 20502 | Not Available |
| 10 | Not Available | Drive Pulley | 20509 | Not Available |
| 11 | Not Available | Agitator Shaft | 20510 | Not Available |
| 12 | Not Available | Pin Spring | 20511 | Not Available |
| 13 | Not Available | Brush Strip 4 PK | 22000 | Not Available |
| 14 | Not Available | Agitator Core | 20505 | Not Available |
| 15 | Not Available | Edge Cleaner Non-Pulley End | 20506 | Not Available |
| 16 | Not Available | Bearing Holder | 20529 | Not Available |
| 17 | Not Available | Washer | 77163 | Not Available |
| 18 | Not Available | Hex Nut | 77145 | Not Available |
| 79 |  | Nozzle, Housing CPU1/CPU2 Part Number: 54.005 for Carpet Pro | 54005 | $4.02Read more |
| 80 | Not Available | Dust Brush | 53000 | Not Available |
| 81 | Not Available | Upholstery Tool | 52000 | Not Available |
| 82 | Not Available | Upper Wand | 50005 | Not Available |
| 83 | Not Available | Lower Wand | 50006 | Not Available |
| 84 | Not Available | Connection Pipe | 50007 | Not Available |
| 85 | Not Available | Lens Cover U127 | 73414 | Not Available |
| 85 | Not Available | Lens U128 U129 (Incl. 118 - 129) | NLA | Not Available |
| 86 | Not Available | Screw 3x10 PAN | 77030 | Not Available |
| 87 | Not Available | Nozzle Housing U127 | 73027 | Not Available |
| 87 | Not Available | Nozzle Housing U128 | 73028 | Not Available |
| 87 | Not Available | Nozzle Housing U129 | 73029 | Not Available |
| 88 | Not Available | Bumper | 74040 | Not Available |
| 89 | Not Available | Belt Cover Wire | 73410 | Not Available |
| 90 | Not Available | Seal | 73405 | Not Available |
| 91 | Not Available | Belt Cover | 73406 | Not Available |
| 92 | Not Available | Slide Lever Plate U129 | 73412 | Not Available |
| 93 | Not Available | Base Holder | NLA | Not Available |
| 94 | Not Available | Base Holder | 73418 | Not Available |
| 95 | Not Available | Base Holder | 73420 | Not Available |
| 96 | Not Available | Lower Hose Joint Pipe | 75412 | Not Available |
| 97 | Not Available | Nozzle Hose | 73422 | Not Available |
| 98 | Not Available | Air Inlet | 72035 | Not Available |
| 99 | Not Available | Pedal Holder | 73428 | Not Available |
| 100 | Not Available | Torsion Spring | 77180 | Not Available |
| 101 | Not Available | E Ring | 77205 | Not Available |
| 102 | Not Available | Foot Pedal | 73431 | Not Available |
| 103 | Not Available | Foot Pedal Pin Large U129 | 73432 | Not Available |
| 104 | Not Available | Caution Label U129 | 74015 | Not Available |
| 105 | Not Available | Rug & Floor Selector Pedal U129 | 73441 | Not Available |
| 106 | Not Available | Tape U129 | 76017 | Not Available |
| 107 | Not Available | Slide Lever U129 | 73442 | Not Available |
| 108 | Not Available | Foot Pedal Pin Small U129 | 73435 | Not Available |
| 109 | Not Available | Slide Lever Plate U129 | 73444 | Not Available |
| 110 | Not Available | Cushion U127 U128 | 73478 | Not Available |
| 110 | No Image | Emery Cloth Grain 220 | 73448 | $14.00Read more |
| 111 | Not Available | Pedal Holder | 77020 | Not Available |
| 112 | Not Available | Torsion Spring U129 | 77185 | Not Available |
| 113 | Not Available | Pedal Holder U129 | 73446 | Not Available |
| 114 | Not Available | Washer U129 | 77090 | Not Available |
| 115 | Not Available | Screw 4x8 Pan | 77210 | Not Available |
| 116 | Not Available | Belt Cover | 73452 | Not Available |
| 117 | Not Available | Caution Label U127 U128 | 74030 | Not Available |
| 117 | Not Available | Caution Label U129 | 74020 | Not Available |
| 118 | Not Available | Special Nut | 77110 | Not Available |
| 119 | Not Available | Front Wheel | 71016 | Not Available |
| 120 | Not Available | Front Axle | 73454 | Not Available |
| 121 | Not Available | Leaf Spring | 77190 | Not Available |
| 122 | Not Available | Air Spreader | 73456 | Not Available |
| 123 | Not Available | Air Spreader | 73458 | Not Available |
| 124 | Not Available | Air Spreader | 73460 | Not Available |
| 125 | Not Available | Air Spreader | 73462 | Not Available |
| 126 | Not Available | Bottom Plate | 76000 | Not Available |
| 127 | Not Available | Screw | 77195 | Not Available |
| 128 | Not Available | Latch | 73467 | Not Available |
| 129 | Not Available | Caution Label | 74025 | Not Available |
| 130 | Not Available | Bulb 20W U128 U129 | 35010 | Not Available |
| 131 | Not Available | Socket Ass'y U128 U129 | 36014 | Not Available |
| 132 | Not Available | Lead Wire U128 U129 | 36016 | Not Available |
| 133 | Not Available | Lamp Holder U128 U129 | 73466 | Not Available |
| 134 | Not Available | Cord Bushing U128 U129 | 73468 | Not Available |
| 135 | Not Available | Lamp Holder U128 U129 | 73470 | Not Available |
| 136 | Not Available | Lamp Holder U128 U129 | 73472 | Not Available |
| 137 | Not Available | Flat Belt 2 PK | 10000 | Not Available |
| 137 | Not Available | Flat Belt | SHR-1000 | Not Available |
| 138 | Not Available | Seal | 73473 | Not Available |
| 139 | Not Available | Pulley Cover | 73474 | Not Available |
| 140 | Not Available | Agitator Ass'y U127 U128 | NLA | Not Available |
Report errors on this page HERE
