Schematic and parts book for Sanyo SC-507T . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | BRAKE ROLLER ASSEMBLY BB | 6630000236 | Not Available |
| XX | Not Available | BRAKE SPRING | 6630001035 | Not Available |
| 1 | Not Available | DUST BOX (B-665T) | 6630100417 | Not Available |
| 2 | Not Available | DUST BOX COVER (B-666) | 6630100424 | Not Available |
| 3 | No Image | SCREW, (4X16) X2100P Part Number: 6630000847 for Sanyo | 6630000847 | $0.47Read more |
| 4 | Not Available | CRAMP HOOK (B-666) | 6630100431 | Not Available |
| 5 | Not Available | CRAMP SPRING (DUST) | 6630060940 | Not Available |
| 6 | Not Available | CASTER (NN-B) | 6630000823 | Not Available |
| 7 | Not Available | AIR INLET PACKING (NN-B) | 6630000052 | Not Available |
| 8 | Not Available | AIR INLET COVER FITTING | 6630000069 | Not Available |
| 9 | Not Available | DUST FILTER COMP KEYNO10-13 | 6630099193 | Not Available |
| 10 | Not Available | PRE FILTER | 6630099209 | Not Available |
| 11 | Not Available | FILTER ASSEMBLY | 6630099216 | Not Available |
| 12 | Not Available | DUST FILTER PACKING | 6630099223 | Not Available |
| 13 | Not Available | DUSTER ARM (N1-233) | 6630000892 | Not Available |
| 14 | Not Available | HANDLE (B-666) | 6630100448 | Not Available |
| 15 | Not Available | SWITCH (BLACK) | 6630050934 | Not Available |
| 16 | Not Available | CONNECTOR HOUSING ASSEMBLY | 6630099230 | Not Available |
| 17 | Not Available | SCREW (4X16) | 6630000939 | Not Available |
| 18 | Not Available | INDICATOR ORNAMENT | 6630100455 | Not Available |
| 19 | Not Available | INDICATOR FILTER | 6630000953 | Not Available |
| 20 | Not Available | INDICATOR ASSEMBLY | 6630091203 | Not Available |
| 21 | Not Available | TRANSMISSIONTUBE | 6630000977 | Not Available |
| 22 | Not Available | CASE COVER (B-666) | 6630100462 | Not Available |
| 23 | Not Available | REEL BUTTON (B-666) | 6630100479 | Not Available |
| 24 | Not Available | HELICAL SPRING | 6630001011 | Not Available |
| 25 | Not Available | BRAKE ARM (N1-233) | 6630087961 | Not Available |
| 28 | Not Available | CASE UPPER (B-665T) | 6630100486 | Not Available |
| 29 | Not Available | PORYURETHANE FORM | 6630001059 | Not Available |
| 30 | Not Available | OUTLET FILTER C | 6630091210 | Not Available |
| 31 | Not Available | OUTLET FILTER D | 6630091227 | Not Available |
| 32 | Not Available | POLYURETHANE FORM C | 6630001103 | Not Available |
| 33 | Not Available | MOTOR CUSHION FRONT | 6630001110 | Not Available |
| 34 | No Image | MOTOR, 800P CAN Part Number: 6630001127 for Sanyo | 6630001127 | $182.78Read more |
| 35 | Not Available | CONNECTOR HOUSING ASSEMBLY | 6630099254 | Not Available |
| 36 | Not Available | MOTOR CUSHION SLEEVE | 6630001141 | Not Available |
| 37 | Not Available | SCREW (4X20) | 6630001158 | Not Available |
| 38 | Not Available | MOTOR CUSHION REAR | 6630001165 | Not Available |
| 39 | Not Available | SILENCER PIPE | 6630051627 | Not Available |
| 40 | Not Available | AIR INLET FILTER | 6630088012 | Not Available |
| 41 | Not Available | FUSE ASSEMBLY (125V 15A) | 6630096796 | Not Available |
| 42 | Not Available | SCREW (TORX SCREW)(4X20) | 6630050378 | Not Available |
| 43 | Not Available | MOTOR SUPPORTER ASSEMBLY | 6630075753 | Not Available |
| 44 | Not Available | CORD REEL COMP INCL/P.CORD | 6630096802 | Not Available |
| 45 | Not Available | POWER CORD (U2) | 6630096819 | Not Available |
| 46 | Not Available | CASE LOWER (B-665T) | 6630100493 | Not Available |
| 47 | Not Available | WHEEL SMALL (NN-B) | 6630004296 | Not Available |
| 48 | Not Available | WHEEL SHAFT | 6630056554 | Not Available |
| 49 | Not Available | WHEEL REAR (B-666) | 6630100509 | Not Available |
| 50 | Not Available | CORD INLET COVER LARGE | 6630100516 | Not Available |
| 51 | Not Available | SCREW (4X20) | 6630000243 | Not Available |
| 52 | Not Available | NAME PLATE | 6630100523 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SUCTION HOSE COMP KEYNO2_12 | 6630001264 | Not Available |
| 1 | Not Available | INSTRUCTION MANUAL | 6630100547 | Not Available |
| 2 | Not Available | AIR SLIDE RING (NN_B) | 6630001271 | Not Available |
| 3 | Not Available | ROTARY BEND (NN-B) | 6630007297 | Not Available |
| 4 | Not Available | JOINT PIPE PACKING | 6630050668 | Not Available |
| 5 | Not Available | ROTARY BEND SET RING | 6630000458 | Not Available |
| 6 | Not Available | HOSE GRIP PIPE (NN-B) | 6630000489 | Not Available |
| 7 | Not Available | SUCTION HOSE COVER (NN_B) | 6630000465 | Not Available |
| 8 | Not Available | SUCTION HOSE (NN-B) | 6630001295 | Not Available |
| 9 | No Image | COVER, HOSE LOCK 240/270 CANS Part Number: 6630000496 for Sanyo | 6630000496 | $2.08Read more |
| 10 | Not Available | HOSE HOOK | 6630000502 | Not Available |
| 11 | No Image | SPRING, HOSE LOCK 240/270 CANS Part Number: 6630000519 for Sanyo | 6630000519 | $1.60Read more |
| 12 | Not Available | HOSE JOINT PIPE A (NN_B) | 6630000526 | Not Available |
| 13 | Not Available | TURBO BRUSH COMP. | 6630100530 | Not Available |
| 14 | No Image | WAND SET, TELESCOPIC 505T/506T CANISTERS Part Number: 6630001554 for Sanyo | 6630001554 | $46.84Read more |
| 15 | Not Available | PIPE RETAINER | 6630075814 | Not Available |
| 16 | Not Available | SCREW (4X16) | 6630000335 | Not Available |
| 17 | No Image | SANYO CREVICE TOOL SC240/270 Part Number: 663-000-0588 for Sanyo | 6630000588 | $7.04Read more |
| 18 | Not Available | UPHOLSTERY BRUSH ASSEMBLY | 6630000595 | Not Available |
