Schematic and parts book for Sanyo 240, 270 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | Inner Cord Inlet Cover 240 | 6630000731 | Not Available |
| XX | Not Available | Carbon Brush Ass'y | 63020 | Not Available |
| XX | Not Available | Wire Connector 240 | SS-3270 | Not Available |
| 1 | No Image | DIRT CUP, 240 CAN BLUE Part Number: 6630000625 for Sanyo | 6630000625 | $31.02Read more |
| 1 | No Image | Spring, Extension | 75114 | $49.99Read more |
| 2 | Not Available | Dust Box Label | 6630000021 | Not Available |
| 3 | No Image | BROCHURE, EUREKA CENTRAL VAC Part Number: 071020 for Electrolux | 71020 | $0.00Read more |
| 4 | Not Available | Clamp Hook 240 | 6630000632 | Not Available |
| 4 | Not Available | Clamp Hook | 6630000045 | Not Available |
| 5 | No Image | Spacer, Link, Squeegee | 75110 | $17.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 6 | No Image | -Lever Bracket Black/Brown | 75112 | $36.00Read more |
| 7 | Not Available | Screw (4X16) | 77230 | Not Available |
| 8 | Not Available | Pre-Filter | 18025 | Not Available |
| 9 | Not Available | Dust Filter | 18030 | Not Available |
| 10 | Not Available | Dust Filter Packing | 18040 | Not Available |
| 11 | No Image | Bracket, Mounting, Head, Orbital | 75144 | $460.99Read more |
| 12 | Not Available | Switch | 6630000120 | Not Available |
| 13 | Not Available | Switch Ornament 240 Blue | 6630000649 | Not Available |
| 13 | Not Available | Switch Ornament 270 Yellow | 6630000137 | Not Available |
| 14 | Not Available | Handle | 70055 | Not Available |
| 15 | Not Available | Case Ornament 240 Blue | 6630000670 | Not Available |
| 15 | Not Available | Case Ornament 270 Yellow | 6630000151 | Not Available |
| 16 | Not Available | Caution Label | 6630000656 | Not Available |
| 17 | Not Available | Switch Holder | 6630000175 | Not Available |
| 18 | Not Available | Lead Wire Black 240 | 6630000663 | Not Available |
| 18 | Not Available | Lead Wire Black 270 | 6630000182 | Not Available |
| 19 | No Image | Cover Recovery 22g | 75161 | $860.99Read more |
| 20 | No Image | Support Lever, for SOFTCASE | 75122 | $8.00Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | Not Available | Brake Spring 270 | NLA | Not Available |
| 22 | Not Available | Brake Arm 270 | 6630000229 | Not Available |
| 23 | Not Available | Brake Roller 270 | NLA | Not Available |
| 24 | Not Available | Screw (4X20) | 77245 | Not Available |
| 25 | Not Available | Upper Case 240 Blue | 6630000687 | Not Available |
| 25 | Not Available | Upper Case 270 Yellow | 6630000250 | Not Available |
| 26 | Not Available | Foam Gasket | NLA | Not Available |
| 27 | Not Available | Front Motor Cushion | NLA | Not Available |
| 28 | Not Available | Motor Complete | 60015 | Not Available |
| 29 | Not Available | Lead Wire Black | 6630000298 | Not Available |
| 30 | Not Available | Lead Wire Yellow 240 | 6630000694 | Not Available |
| 30 | Not Available | Lead Wire Yellow 270 | 6630000311 | Not Available |
| 31 | Not Available | Rear Motor Cushion | NLA | Not Available |
| 32 | Not Available | Screw (4X16) 270 | 77265 | Not Available |
| 33 | Not Available | Cord Reel Support 270 | NLA | Not Available |
| 34 | No Image | Squeegee, Rear, 35Inch (Urethane) | 75132 | $324.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 35 | Not Available | Power Cord 16' 270 (Order SA-75132) | NLA | Not Available |
| 36 | Not Available | Lower Case 240 Blue | 6630000717 | Not Available |
| 36 | Not Available | Lower Case 270 Yellow | 6630000373 | Not Available |
| 37 | No Image | Bracket, Swing, Squeegee | 75138 | $103.99Read more |
| 38 | Not Available | Outlet Filter | 18045 | Not Available |
| 39 | Not Available | Rear Wheel | 71025 | Not Available |
| 40 | Not Available | Outer Cord Inlet Cover 240 Blue | 6630000748 | Not Available |
| 40 | Not Available | Cord Inlet Cover 270 Yellow | 6630000410 | Not Available |
| 41 | Not Available | Screw (3X20) | NLA | Not Available |
| 42 | Not Available | Name Plate 240 | 6630000755 | Not Available |
| 42 | Not Available | Name Plate 270 | 6630000779 | Not Available |
| 43 | No Image | Screw | 40000 | $0.00Read more |
| 44 | Not Available | Lock Ring | 45070 | Not Available |
| 45 | Not Available | Suction Hose Cover | 45005 | Not Available |
| 46 | Not Available | Suction Hose | 41000 | Not Available |
| 47 | Not Available | Hose Grip Pipe | 45075 | Not Available |
| 48 | No Image | COVER, HOSE LOCK 240/270 CANS Part Number: 6630000496 for Sanyo | 6630000496 | $2.08Read more |
| 49 | Not Available | Hose Hook | 6630000502 | Not Available |
| 50 | No Image | SPRING, HOSE LOCK 240/270 CANS Part Number: 6630000519 for Sanyo | 6630000519 | $1.60Read more |
| 51 | Not Available | Hose Joint Pipe | 6630000526 | Not Available |
| 52 | Not Available | Elbow | 45080 | Not Available |
| 53 | Not Available | Wand | 50010 | Not Available |
| 54 | Not Available | Wand Retainer A 270 | 50530 | Not Available |
| 55 | Not Available | Wand Retainer B 270 | 50535 | Not Available |
| 56 | Not Available | Floor Tool Complete | 55016 | Not Available |
| 57 | No Image | DUST COMPARMENT, CPU1 Part Number: 54.010 for Carpet Pro | 54010 | $49.22Read more |
| 58 | Not Available | Upholstery Brush Complete | 52007 | Not Available |
| 59 | Not Available | Tool Caddy 270 | 70260 | Not Available |
| 270 | Not Available | Power Cord 15' 240 | 30770 | Not Available |
