Schematic and parts book for Sanitaire SCBP1 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Cover | 54.111 | Not Available |
| 2 |  | Hose inlet Part Number 54.107 for Cleanmax Models CMBP-6 | 54107 | |
| 3 |  | Inlet seal Part Number B352-4800 for Cleanmax Models CMBP-6 | B3524800 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 |  | Phillps pan head screw 8.625 Part Number A732-8300 for Cleanmax Models CMBP-6,CMBP-6,CMBP-6 | A7328300 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 7 | Not Available | Front plate | 54.108 | Not Available |
| 8 |  | Bag compartment seal Part Number B352-6100 for Cleanmax Models CMBP-6 | B3526100 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 9 | Not Available | o.s. Back rest assembly items 32 33 34 39 40 | 54.100 | Not Available |
| 10 | | Phillips pan head screw 10.750 Part Number A352-8100 for Cleanmax Models CMBP-6 | A3528100 | $0.00Read more |
| 11 | | Latch Part Number 54.112 for Cleanmax Models CMBP-6 | 54112 | |
| 12 | | Phillps pan head screw 8.625 Part Number A732-8300 for Cleanmax Models CMBP-6,CMBP-6,CMBP-6 | A7328300 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 | | Washer Part Number A732-9700 for Cleanmax and Simplicity Models CMBP-6,PRISTINE, CHARISMA, STARBR... | A7329700 | $2.19Read more |
| 14 | | Back plate Part Number 54.109 for Cleanmax Models CMBP-6 | 54109 | |
| 15 |  | Shoulder harness right padded nylon Part Number B352-7000 for Cleanmax Models CMBP-6 | B3527000 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 |  | Shoulder harness left padded nylon Part Number B352-7100 for Cleanmax Models CMBP-6 | B3527100 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 17 | | Waist belt Part Number B352-6600 for Cleanmax Models CMBP-6 | B3526600 | $0.00Read more |
| 18 | | Hose assembly Part Number 19.452 for Cleanmax Models CMBP-6 | 19452 | |
| 19 | | Dust brush assembly Part Number 10.308 for Cleanmax Models CMBP-6 | 10308 | |
| 22 | | Bare floor tool Part Number 10.309 for Cleanmax Models CMBP-6 | 10309 | |
| 28 | | Telescopic wand assembly Part Number 26.125 for Cleanmax Models CMBP-6 | 26125 | |
| 29 | Not Available | Carpet tool | 10.310 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | | Motor compartment Part Number 54.101 for Cleanmax Models CMBP-6 | 54101 | |
| 2 | No Image | Bumper | B3520200 | $0.00Read more |
| 3 | | Phillps pan head screw 8.625 Part Number A732-8300 for Cleanmax Models CMBP-6,CMBP-6,CMBP-6 | A7328300 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 |  | Post filter cover Part Number 54.104 for Cleanmax Models CMBP-6 | 54104 | $7.69Read more |
| 6 |  | Bottom motor mount Part Number B352-1900 for Cleanmax Models CMBP-6 | B3521900 | $5.99Read more |
| 7 |  | Motor shroud cover – bottom Part Number B352-5300 for Cleanmax Models CMBP-6 | B3525300 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | | Bottom motor mount Part Number B352-1900 for Cleanmax Models CMBP-6 | B3521900 | $5.99Read more |
| 9 |  | Motor Shroud Part Number B113-0915 for Simplicity and Cleanmax and Riccar Models 7400, 7450, 7900... | B1130915 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | Not Available | Motor assembly | 20.011 | Not Available |
| 11 |  | MOTOR SEAL .125 POLYURETHANE BPV | B3525500 | $5.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 |  | Motor shroud cover - top Part Number B352-5400 for Cleanmax Models CMBP-6 | B3525400 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 13 |  | Top motor mount Part Number B352-1800 for Cleanmax Models CMBP-6,CMBP-6 | B3521800 | $12.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 |  | Motor cover Part Number B352-0700 for Cleanmax Models CMBP-6 | B3520700 | $8.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 15 | Not Available | Body seal | 54.103 | Not Available |
| 16 | Not Available | Secondary filter plate | 54.106 | Not Available |
| 17 |  | CleanMax 8-16 x 2.500 Phillips Pan Head Screw | A4300205 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | | Secondary filter cap Part Number 54.105 for Cleanmax Models CMBP-6 | 54105 | |
| 20 |  | Strain relief Part Number B352-6800 for Cleanmax Models CMBP-6 | B3526800 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 21 | | Switch & harness assembly Part Number 54.114 for Cleanmax Models CMBP-6 | 54114 | $0.00Read more |
| 28 | | Power harness cord Part Number 54.113 for Cleanmax Models CMBP-6 | 54113 | |
| 29 | | Extension cord yellow 50’ Part Number 14.206 for Cleanmax Models CMBP-6 | 14206 | $103.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 34 | Not Available | Thermal protector switch | 54.110 | Not Available |
