Schematic and parts book for sanitaire S782AT-1 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | UPPER PIVOTING HANDLE ASS | 61200-1 | Not Available |
| 2 | No Image | SQUEEGEE, DOUBLE BARRED Part Number: 61166. for Cen-Tec | 61166 | $6.40Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 |  | SCREW, BOTTOM PLATE SC785 PACKAGE Part Number: 611651 for Eureka | 611651 | $5.23Read more |
| 4 | Not Available | BRACKET - CORD RELEASE | 61213 | Not Available |
| 5 | Not Available | HOOK - CORD SWIVEL | 61212-1 | Not Available |
| 6 | Not Available | STOP - RUBBER | 61211 | Not Available |
| 7 | Not Available | NEON LIGHT COVER | 61210 | Not Available |
| 9 | Not Available | FIX SPRING | 61209 | Not Available |
| 10 | Not Available | FIX SWITCH | 61208 | Not Available |
| 11 | No Image | GUIDE, RIGHT SIDE Part Number: 61207-1 for Eureka | 612071 | $1.27Read more |
| 12 | No Image | SCREW, BASE S782 Part Number: 61165-5 for Eureka | 611655 | $4.57Read more |
| 13 | Not Available | FIXED PLATE | 61189-2 | Not Available |
| 14 | Not Available | PAPER BAG PKG STYLE SL | 61125 | Not Available |
| 15 | Not Available | DUST CABINET COVER | 61202-3 | Not Available |
| 16 | Not Available | GASKET | 61203 | Not Available |
| 17 |  | Nut, For S782/SC785/790A 10Pk Part Number: 611982 for Eureka | 611982 | $6.49Read more |
| 18 |  | WASHER, HANDLE 782 10PK Part Number: 611993 for Eureka | 611993 | $5.34Read more |
| 19 |  | Filter, Exhaust Final S782/SC785 Sanitaire Part Number: 61124 for Eureka | 61124 | $7.76Read more |
| 20 | Not Available | COVER - EXHAUST AIR | 61201-1 | Not Available |
| 21 | No Image | SCREW, FILTER & DUST COVER SC785 PACKAGE Part Number: 61165-3 for Eureka | 611653 | $4.54Read more |
| 22 | No Image | PLATE, FIX SC785 Part Number: 61174 for Eureka | 61174 | $17.50Read more |
| 23 | Not Available | MACHINE COVER (RH) | 61205-3 | Not Available |
| 24 | Not Available | GASKET ("L" PAD) | 61206 | Not Available |
| 25 | No Image | OWNERS MANUAL, S782 Part Number: 70734 for Eureka | 70734 | $7.48Read more |
| 26 | Not Available | EXTENTION HOSE ASSEMBLY | 61307 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | DUSTING BRUSH/S782-785AT | 61126 | Not Available |
| 2 | Not Available | SLEEVE - BUSHING | 61159 | Not Available |
| 3 | Not Available | WAND SUPPORT (UPPER) | 61160 | Not Available |
| 4 | | SCREW, BOTTOM PLATE SC785 PACKAGE Part Number: 611651 for Eureka | 611651 | $5.23Read more |
| 5 | No Image | HOUSING, BAG RIGHT SIDE S782 Part Number: 612043 for Eureka | 612043 | $32.84Read more |
| 6 |  | NO LONGER AVAILABLE Hose, Black Assy Sanitaire Part Number: 611291 for Eureka | 611291 | $40.78Read more |
| 7 |  | Wand, Gray Nesting Crevice/Extension 2-Pc Part Number: 61127 for Eureka | 61127 | $17.58Read more |
| 8 | Not Available | TORQUE SPRING (LH) - PKGD | 61680 | Not Available |
| 9 | Not Available | WAND SUPPORT (LOWER) | 61163 | Not Available |
| 11 | Not Available | BRUSHROLL ASSEMBLY -PKGD | 61128-1 | Not Available |
| 12 | No Image | SCREW, MAIN BODY HOOD SC785 PACKAGE Part Number: 61165-2 for Eureka | 611652 | $4.62Read more |
| 13 | Not Available | COVER - SQUEEGEE | 61469-1 | Not Available |
| 15 | No Image | SPRING PACKAGE, S780 Part Number: 61180 for Eureka | 61180 | $4.73Read more |
| 16 | No Image | SCREW, FILTER & DUST COVER SC785 PACKAGE Part Number: 61165-3 for Eureka | 611653 | $4.54Read more |
| 17 | No Image | PLATE, FIX SC785 Part Number: 61174 for Eureka | 61174 | $17.50Read more |
| 18 | Not Available | BUTTON - METAL LOCKING | 61173 | Not Available |
| 20 | Not Available | BEND PIPE | 61172-1 | Not Available |
| 21 | Not Available | SEAL RING | 61171 | Not Available |
| 22 | Not Available | SEAL RING | 61169 | Not Available |
| 24 | Not Available | LEFT SIDE GUIDE | 61168-1 | Not Available |
| 25 | Not Available | MOTOR FILTER | 61123 | Not Available |
| 26 | No Image | HOOD ASS'Y, S782AT Part Number: 611751 for Eureka | 611751 | $21.11Read more |
| 28 | Not Available | FOOT PEDAL ASSEMBLY | 61463 | Not Available |
| 29 | Not Available | TORQUE SPRING (RH) - PKGD | 61681 | Not Available |
| 30 | Not Available | REAR WHEEL ASSEMBLY | 61214 | Not Available |
| 31 |  | BASE, SC782 BLUE Part Number: 61170-1 for Eureka | 611701 | $40.44Read more |
| 33 |  | Wheel, Front 790/410/411/SC785/SC782 Part Number: 61164 for Eureka | 61164 | $6.58Read more |
| 34 | Not Available | FURNTURE GUARD | 61167 | Not Available |
| 35 | Not Available | SQUEEGEE | 61465 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | POWER CORD/S782AT | 61177-1 | Not Available |
| 2 | Not Available | WIRE - CONNECTING | 61183-1 | Not Available |
| 3 | Not Available | ELECTRICAL CONTACT PACKAG | 61195 | Not Available |
| 4 | Not Available | WIRE - CONNECTING | 61183-2 | Not Available |
| 5 |  | WIRE, TERMINATED Part Number: 611841 for Eureka | 611841 | $6.74Read more |
| 6 | Not Available | WIRE - TERMINATED | 61184-3 | Not Available |
| 7 | No Image | MOUNT, MOTOR POWER NOZZL S782 Part Number: 61187 for Eureka | 61187 | $5.32Read more |
| 8 | Not Available | JOINT - NOZZLE PIVOT | 61186-1 | Not Available |
| 10 | Not Available | CIRCUIT BOARD | 61178 | Not Available |
| 11 | Not Available | MOUNT - FRONT MOTOR | 61179-1 | Not Available |
| 12 |  | Motor, SC782/SC785 Sanitaire Light Upright Part Number: 611851 for Eureka | 611851 | $101.18Read more |
| 13 | Not Available | WIRE - TERMINATED | 61184-2 | Not Available |
| 14 | No Image | MOTOR MOUNT, REAR SC785 Part Number: 61182-1 for Eureka | 611821 | $7.54Read more |
| 15 | Not Available | SCREW PACKAGE | 61165-6 | Not Available |
| 16 | Not Available | BUTTON - RESET PUSH | 61190 | Not Available |
| 17 | Not Available | SPRING - COMPRESSION | 61191 | Not Available |
| 18 | Not Available | CIRCUIT BREAKER ASSEMBLY | 61192 | Not Available |
| 19 | Not Available | WIRE - CONNECTING | 61183-3 | Not Available |
| 20 | Not Available | SCREW PACKAGE | 61165-4 | Not Available |
| 21 | No Image | NUT, NOZZLE BODY S782 10PK Part Number: 611981 for Eureka | 611981 | $5.23Read more |
| 22 | Not Available | SPRING WASHER PACKAGE | 61199-4 | Not Available |
| 23 | Not Available | SPRING WASHER PACKAGE | 61199-1 | Not Available |
| 24 | Not Available | GEAR | 61194 | Not Available |
| 25 | Not Available | FIXED PLATE | 61189-1 | Not Available |
| 26 | Not Available | MOTOR(BRUSH)SC782AT | 61188-1 | Not Available |
| 27 | Not Available | WIRE - TERMINATED | 61184-4 | Not Available |
| 28 | Not Available | BELT - COG | 61121 | Not Available |
