Schematic and parts book for sanitaire S639A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE ASSEMBLY(UPPER) | 25989A-5 | Not Available |
| 3 | Not Available | CORD - LOW LEAD (18 GA) | 27382-10 | Not Available |
| 4 | Not Available | HANDLE ASSEMBLY - LOWER | 36984-3 | Not Available |
| 5 | Not Available | PIN - SNAP PACKAGE (5) | 53080-4 | Not Available |
| 6 |  | Bolt, Handle Bracket Eur/Sanitaire Uprights Part Number: 53145 for Eureka | 53145 | $8.87Read more |
| 7 | Not Available | HANDLE SCREW ASSY PACKAGE | 53198-1 | Not Available |
| 8 |  | Nut-Eureka - 10Pk - Bravo Handle For: eureka,sanitaire | 532135 | $4.45Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | Screw, Rear Axle Retainer Clip Sanitaire/2000 Ser Part Number: 53238-13 for Eureka | 5323813 | $6.56Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | SWITCH ASSEMBLY | 13738-5 | Not Available |
| 2 |  | Switch, Button 1934/1967/1968/SC678/SC679/SC684 Part Number: 146601 for Eureka | 146601 | $4.74Add to cart Special order: ships in 2 to 4 weeks |
| 3 | Not Available | PEDAL - FOOT | 24834A-3 | Not Available |
| 4 | Not Available | CAM (RIGHT) | 24964A-1 | Not Available |
| 5 | Not Available | CAM (LEFT) | 24965A-1 | Not Available |
| 6 | Not Available | GASKET - MOTOR SEAL | 30517 | Not Available |
| 7 |  | Cover, Gray Wheel C2000/1400/1900/C4000 Series Part Number: 36263 for Eureka | 36263 | $4.33Add to cart Special order: ships in 2 to 4 weeks |
| 8 | Not Available | SEPARATOR ASSEMBLY | 37676ASV | Not Available |
| 9 |  | Clip, Switch 1400/1900/2000/C2000/C4000 Part Number: 37989 for Eureka | 37989 | $5.73Add to cart Special order: ships in 2 to 4 weeks |
| 10 | Not Available | KNOB ASSEMBLY | 38053-1 | Not Available |
| 11 |  | BUSHING, HOOD 5134 UPRIGHT Part Number: 530891 for Eureka | 530891 | $8.02Add to cart Special order: ships in 2 to 4 weeks |
| 12 |  | Spring, Metal Foot Pedal For Most Uprights Part Number: 53097 for Eureka | 53097 | $5.24Add to cart |
| 13 |  | Eureka,Sanitaire Hood Attaching Spring-sanitaire 886 (10pk) | 53117 | $14.44Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | Compatible alternateEureka and Sanitaire Hood Spring More Product Details | 20750005 | $1.65Add to cart |
| 14 | Not Available | RIVET - SHOULDER PACKAGE | 53118 | Not Available |
| 15 |  | Washer, Metal Upper Cord Hook Part Number: 53133 for Eureka | 53133 | $3.17Read more |
| 16 |  | Frnt Axle Clmp Assy
6 Pack For: eureka,sanitaire | 53140 | $5.97Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | Screw, Shoulder Adjustment Knob Part Number: 53143 for Eureka | 53143 | $20.33Add to cart Special order: ships in 2 to 4 weeks |
| 18 | No Image | Clamp, 3/10 UPT Cable 5Pk Part Number: 53160 for Eureka | 53160 | $3.48Add to cart Special order: ships in 2 to 4 weeks |
| 19 | | Nut-Eureka - 10Pk - Bravo Handle For: eureka,sanitaire | 532135 | $4.45Add to cart Special order: ships in 2 to 4 weeks |
| 20 |  | Screw, Upper Bearing Plate Sanitaire 10Pk Part Number: 532282 for Eureka | 532282 | $3.65Add to cart Special order: ships in 2 to 4 weeks |
| 21 | Not Available | SCREWS - PACKAGE | 53228-3 | Not Available |
| 22 | | Screw, Rear Axle Retainer Clip Sanitaire/2000 Ser Part Number: 53238-13 for Eureka | 5323813 | $6.56Add to cart Special order: ships in 2 to 4 weeks |
| 23 |  | Screw, Motor Mount Eureka/Sanitaire 10Pk Part Number: 5323814 for Eureka | 5323814 | $4.92Add to cart Special order: ships in 2 to 4 weeks |
| 24 | Not Available | MOTOR ASSEMBLY - CARTONED | 53349-7 | Not Available |
| 25 | Not Available | BASE ASSEMBLY - CARTONED | 54004-4 | Not Available |
| 26 | Not Available | HOOD & GRAPHICS ASSY - PK | 54314-7 | Not Available |
| 27 | No Image | WIRE and TERMINAL ASSEMBLY | 55296 | $17.99Read more |
| 28 |  | Wire Nuts, 5Pk Part Number: 60192-1 for Eureka | 601921 | $5.38Add to cart Special order: ships in 2 to 4 weeks |
| # | Part image | Description | SKU | Price |
| 1 |  | Bottom Plate, Double Slot/Front Tabs 1400 Series Part Number: 259221 for Eureka | 259221 | $26.36Add to cart Special order: ships in 2 to 4 weeks |
| 1 |  | Compatible alternateBase Plate 259221 for Sanitaire, Bissell Big Green Commercial, and Old Eureka Commercial Types More Product Details | ER-7601 | $26.36Add to cart Special order: ships in 2 to 4 weeks |
| 2 |  | Cover, Black Pliable Rubber End Cap Part Number: 26059A for Eureka | 26059A | $1.77Add to cart |
| 2 |  | Compatible alternateCover, Black Pliable Rubber End Cap Brushroll More Product Details | ER-2050 | $1.38Add to cart Special order: ships in 2 to 4 weeks |
| 3 | Not Available | WHEEL - REAR | 35858-2 | Not Available |
| 4 |  | Wheel, Blk Front C2000/6400/1400 & Most Sanitaires Part Number: 35859A1 for Eureka | 35859A1 | $3.24Add to cart Special order: ships in 2 to 4 weeks |
| 5 |  | Axle, Metal Front C2000/6400/1400 & Most Sanitaire Part Number: 35947A for Eureka | 35947A | $8.67Add to cart Special order: ships in 2 to 4 weeks |
| 6 | Not Available | GUARD - FURNITURE | 36342-13 | Not Available |
| 7 |  | Bushing Bracket Eureka 2034 For: eureka,sanitaire | 375901 | $5.34Add to cart Special order: ships in 2 to 4 weeks |
| 8 |  | End Cap, W/Bearing For Wood Brushroll Part Number: 38138 for Eureka | 38138 | $10.54Add to cart Special order: ships in 2 to 4 weeks |
| 9 |  | Axle, Metal Rear Standard Uprights Part Number: 47562 for Eureka | 47562 | $6.56Add to cart Special order: ships in 2 to 4 weeks |
| 10 | Not Available | BELT PKG ASSY (UPRIGHT) | 52100A | Not Available |
| 11 |  | Spring, Handle Release Bravo Models Ea Part Number: 530762 for Eureka | 530762 | $7.04Add to cart |
| 12 |  | Push Nut, Metal Rear Wheel C2094/C2132/C4046 Ser Part Number: 53121 for Eureka | 53121 | $5.18Add to cart Special order: ships in 2 to 4 weeks |
| 13 |  | AXLE CLAMP - PACKAGED | 53201 | $18.99Add to cart |
| 14 |  | SCREW, REAR AXLE QUICK KLEEN EUREKA | 5323811 | $10.99Add to cart Special order: ships in 2 to 4 weeks |
| 15 | Not Available | DISTURBULATOR REPLACEMENT | 54104-1 | Not Available |
| 16 | Not Available | CLIP - WIRE | 55015 | Not Available |
| # | Part image | Description | SKU | Price |
| 3 |  | Spring, Chrome Bag From Slide to Handle Part Number: 47722 for Eureka | 47722 | $6.58Read more |
| 4 | Not Available | PAPER BAG PKG ASSY STYLE | 52320A | Not Available |
| 5 | Not Available | BAG ASSEMBLY - PACKAGED | 53977-1 | Not Available |
| 6 | Not Available | GASKET - BAG ADAPTER | 55106 | Not Available |
| 7 | Not Available | HARDWARE PACKAGE | 57062B | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | FAN BLOWER - MOTOR | 12988-1 | Not Available |
| 3 | Not Available | FAN | 26136 | Not Available |
| 5 | Not Available | PULLEY - MOTOR DRIVE | 49507-1 | Not Available |
| 6 | Not Available | BALL BEARING - PACKAGE | 53088-4 | Not Available |
| 7 | No Image | SCREW, TOP MOTOR/BEARING COVER 10/PK Part Number: 53131-1 for Eureka | 531311 | $9.48Read more |
| 8 | Not Available | WASHER - FAN PACKAGE (10) | 53148 | Not Available |
| 9 | Not Available | RIVET PACKAGE | 53187-1 | Not Available |
| 10 | Not Available | MOTOR ASSEMBLY - CARTONED | 53349-7 | Not Available |
| 11 | Not Available | ARMATURE - CARTONED | 53470-3 | Not Available |
| 12 | Not Available | MOTOR BASE ASSEMBLY | 54171-1 | Not Available |
| 13 | Not Available | MOTOR FAN END HOUSING ASS | 54172 | Not Available |
| 14 | Not Available | BEARING RETAINER ASSY-W/L | 54412-1 | Not Available |
| 15 |  | Washer, Between Fan/Lower Bearing Bravo/World Vac Part Number: 54811 for Eureka | 54811 | $3.89Add to cart |
