Schematic and parts book for Panasonic V5320, V5340 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Nozzle Housing V5320 | 73051 | Not Available |
| 1 | Not Available | Nozzle Housing V5340 | 73053 | Not Available |
| 1 | Not Available | Brushroll | 20025 | Not Available |
| 2 | Not Available | Window | 21H-V20 | Not Available |
| 2 | Not Available | End Cap “A” | 20525 | Not Available |
| 3 | Not Available | Plastic Shaft | 73900 | Not Available |
| 3 | Not Available | Washer | 681-424 | Not Available |
| 4 | Not Available | Furniture Guard | 74023 | Not Available |
| 5 | Not Available | Packing Tight | 76425 | Not Available |
| 6 | Not Available | Spring Pedal | 77205 | Not Available |
| 7 | Not Available | Screw Spring | 77020 | Not Available |
| 8 | Not Available | Screw Reflector Supporter | 77020 | Not Available |
| 9 | Not Available | Belt | MC210B | Not Available |
| 9 | Not Available | Belt | PR-1015 | Not Available |
| 10 | Not Available | Bottom Plate Assembly | 76022 | Not Available |
| 11 | Not Available | Bottom Plate Only | 27AAGMZV06 | Not Available |
| 12 | Not Available | Packing Bottom Plate | 76740 | Not Available |
| 13 | Not Available | Belt Cover | 76315 | Not Available |
| 14 | Not Available | Screw Bottom Plate | 77012 | Not Available |
| 15 | Not Available | Nozzle Hose Short | 72403 | Not Available |
| 16 | Not Available | Reflector Supporter | 86H2F1B0A | Not Available |
| 17 | Not Available | Reflector | 22HAGMZW00 | Not Available |
| 18 | Not Available | Socket Light | 93HUSZ00 | Not Available |
| 19 |  | Bulb, Double Pole 505-1CR Part Number: 1650 S for Kirby | 1650S | $18.06Read more |
| # | Part image | Description | SKU | Price |
| XX | Not Available | Hose Hook (Not Shown) | 75921 | Not Available |
| 1 | No Image | Harness, Power, Traction, S-20 | 75253 | $694.99Read more |
| 2 | Not Available | On/Off Switch P-02D-V300U Brush Retainer Bracket (Not Shown) | 34100 | Not Available |
| 3 | Not Available | Cord Stopper P-40D-V300U Screw Retainer Bracket (Not Shown) | 62E-J20 | Not Available |
| 4 | Not Available | Screw Cord Stopper | 77020 | Not Available |
| 5 | Not Available | Power Cord | FA-3030-3 | Not Available |
| 6 | Not Available | Wire Connector | SS-3270 | Not Available |
| 7 | Not Available | Packing Dust Compartment | 66KV01V06 | Not Available |
| 8 | Not Available | Cover Switch | 03EV06V06 | Not Available |
| 9 | Not Available | Packing Switch Cover | 73KV0ZV06 | Not Available |
| 10 | Not Available | Screw Switch Cover | 77020 | Not Available |
| 11 | Not Available | Screw Handle | 77043 | Not Available |
| 12 | Not Available | Nut Handle Screw | 21B-170 | Not Available |
| 13 | Not Available | Filter Supporter | 18420 | Not Available |
| 14 |  | Wheel 1-5/8dia Blk Rubber | 18400 | $7.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | Not Available | Secondary Filter | MC181E | Not Available |
| 15 | Not Available | Wheel | 71125 | Not Available |
| 16 | Not Available | Shaft Wheel | 71375 | Not Available |
| 17 | Not Available | Stopper Wheel | 71500 | Not Available |
| 18 | No Image | Washer-(10 Pak)-Panasnic For: panasonic | AXWG6E115FY | $34.16Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 19 | Not Available | Paper Bag 3 Pk | MC115P | Not Available |
| 19 | Not Available | Paper Bag 3 Pk | PR-14005 | Not Available |
| 20 | Not Available | Suction Inlet | 60HJPZV06 | Not Available |
| 21 | Not Available | Cover Suction Inlet | 75690 | Not Available |
| 22 | Not Available | Screw Suction Inlet | 77020 | Not Available |
| 23 | No Image | Block, Weight, Balance | 75036 | $86.99Read more |
| 23 | No Image | Frame, Scrubber, 20 Traction Drive | 75048 | $494.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | Not Available | Packing Rear Cover | 76850 | Not Available |
| 25 | Not Available | Packing Motor Cover | 19FJPZV06 | Not Available |
| 26 | Not Available | Screw Motor Case | 77020 | Not Available |
| 27 | Not Available | Protector | 50522 | Not Available |
| 28 | Not Available | Spring Protector | 77220 | Not Available |
| 29 | Not Available | Protector Case | 75682 | Not Available |
| 30 | Not Available | Protector Supporter | 50525 | Not Available |
| 31 | Not Available | Motor | 60130 | Not Available |
| 32 | Not Available | Carbon Brush | 63052 | Not Available |
| 35 | No Image | Wire Tie 15 Blk | 18706 | $2.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 36 | Not Available | Motor Support Rubber (Front) | 76768 | Not Available |
| 37 | Not Available | Motor Support Rubber (Rear) | 76769 | Not Available |
| 38 | Not Available | Wire Cord | 37G-V020U | Not Available |
| 39 | Not Available | Wire Connector | SS-3270 | Not Available |
| 40 | Not Available | Handle | 64B-V2VZ00 | Not Available |
| 41 | Not Available | Upper Cord Storage Hook | 70818 | Not Available |
| 42 | Not Available | Hose Holder | 70500 | Not Available |
| 43 | Not Available | Spring Cord Hook | 76N-F70 | Not Available |
| 44 | Not Available | Washer Cord Storage Hook | 77120 | Not Available |
| 45 | Not Available | Lower Cord Storage Hook | 70867 | Not Available |
| 46 | Not Available | Screw Cord Storage Hook | 77040 | Not Available |
| 47 | Not Available | Dust Cover V5320 | 60KAGMZBUA | Not Available |
| 47 | Not Available | Dust Cover V5340 | 60KAGMZRUK | Not Available |
| 48 | Not Available | Hose V5320 | 73651 | Not Available |
| 48 | Not Available | Hose V5340 | 73656 | Not Available |
| 49 | Not Available | Dust Brush | 53020 | Not Available |
| 50 | Not Available | Crevice Tool | 54017 | Not Available |
| 51 | Not Available | Wand Extension | 50030 | Not Available |
| 52 | Not Available | Hose Adaptor | 58PZF1V06 | Not Available |
| 53 | Not Available | Wire Tie | 596-702 | Not Available |
| 54 | Not Available | Packing Nut (Handle Screw) | 61LAGMZ00 | Not Available |
| 55 | Not Available | Packing Right | 39AYUZV00 | Not Available |
| 56 | Not Available | Packing Left | 40AYUZV00 | Not Available |
| 57 | Not Available | Plastic Holder | 75930 | Not Available |
| 58 | Not Available | Ornamental Plate V5320 | 21TAGMZ00 | Not Available |
| 58 | Not Available | Ornamental Plate V5340 | 21TAGPZ00 | Not Available |
