Schematic and parts book for Panasonic MC-4850 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | 1 | Caster | Not Available |
| 2 | Not Available | 1 | Lower Body | Not Available |
| 3 | Not Available | 1 | Front Cover | Not Available |
| 4 | Not Available | 1 | Air Intake Packing | Not Available |
| 5 | Not Available | 1 | Bag Clamper | Not Available |
| 5a | Not Available | 1 | Bag Clamper Spring | Not Available |
| 6 | Not Available | 1 | Secondary Filter | Not Available |
| 7 | Not Available | 1 | Exhaust Filter | Not Available |
| 8 | Not Available | 1 | Blower Outlet | Not Available |
| 9 | Not Available | 1 | Blower Cover Spring | Not Available |
| 11 | Not Available | 1 | Body Partition | Not Available |
| 12 | Not Available | 1 | Power Cord Unrt/ Railbase Unit (A-2) | Not Available |
| 13 | Not Available | 1 | Cord Reel Unit | Not Available |
| 14 | Not Available | 1 | Carbon Brush | Not Available |
| 15 | Not Available | 1 | Motor Unit | Not Available |
| 16 | Not Available | 1 | Noise Su pressor | Not Available |
| 17 | Not Available | 1 | Thermal Protector | Not Available |
| 18 | Not Available | 1 | Motor Support Cover | Not Available |
| 19 | Not Available | 1 | Main Switch | Not Available |
| 20 | Not Available | 1 | Paper Dust Bag (C-4) | Not Available |
| 20 | Not Available | 1 | Full Bag Indicator | Not Available |
| 20 | Not Available | 1 | indicator Plate | Not Available |
| 20 | Not Available | 1 | Dust Cover | Not Available |
| 20 | Not Available | 1 | Upper Body | Not Available |
| 25 | Not Available | 1 | Brake Lever | Not Available |
| 26 | Not Available | 1 | Brake Lever Spring | Not Available |
| 27 | Not Available | 1 | Brake Pedal | Not Available |
| 28 | Not Available | 1 | Body Cover | Not Available |
| 29 | Not Available | 1 | Switch Pedal | Not Available |
| 30 | Not Available | 1 | Switch Pedal Spring | Not Available |
| 31 | Not Available | 1 | Tool Storage Cover | Not Available |
| 33 |  | FUSE FOR 32-4805-04 & 32-4803-01 POWER NOZZLES Part Number: FUSE_ for Fitall | FUSE_ | $27.41Read more |
| 34 | Not Available | 1 | Dust Cover Packing | Not Available |
| 35 | Not Available | 1 | Front Motor Supporter | Not Available |
| 36 | Not Available | 1 | Rear Motor Supporter | Not Available |
| 37 | Not Available | 1 | Air Outlet Cover | Not Available |
| 38 | Not Available | 1 | Pan Tap Screw | Not Available |
| 39 | Not Available | 1 | Pan Tap Screw | Not Available |
