Schematic and parts book for Miele SEB234 SEB 234. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | No Image | --Screw 35X30 | 5981580 | $2.50Read more |
| XX |  | Genuine Miele Countersunk screw KA35X16 EJOT-PT | 4863600 | $3.60Read more |
| XX |  | Genuine Miele Screw KA35X16 EJOT-PT | 4863580 | $3.60Read more |
| XX | | Genuine Miele Screw KA35X16 EJOT-PT | 4863580 | $3.60Read more |
| 10-30 | Not Available | Lower section | 5872660 | Not Available |
| 10-30 | | Genuine Miele Lower section | 6588850 | $176.20Read more |
| 20 |  | Genuine Miele Locating peg | 5812090 | $4.90Read more |
| 30 | | Genuine Miele Support roller 2 Pcs. | 5872610 | $52.20Add to cart Special order: ships in 2 to 4 weeks |
| 40+50 | | Genuine Miele Angle lever | 5872630 | $131.10Read more |
| 40 |  | Genuine Miele Support roller 2 Pcs. | 5872620 | $33.80Read more |
| 60 | | Genuine Miele Cover strip | 5812220 | $24.70Read more |
| 70 | | Genuine Miele Regulator wheel | 5812030 | $20.00Add to cart Special order: ships in 2 to 4 weeks |
| 80 | | Genuine Miele Carrier | 5812040 | $9.70Read more |
| 90 | | Genuine Miele Coil spring | 5812080 | $2.30Read more |
| 100 | | Genuine Miele Disc | 5812060 | $4.90Read more |
| 110 | | Genuine Miele Switch lever | 5812070 | $9.70Read more |
| 120 | | Genuine Miele Spring Foot switch SEB | 6644260 | $11.00Add to cart Special order: ships in 2 to 4 weeks |
| 130 | No Image | Interlock | 5812160 | $12.00Add to cart Special order: ships in 2 to 4 weeks |
| 140 | | Genuine Miele Brush roller | 5812012 | $96.72Add to cart Special order: ships in 2 to 4 weeks |
| 150 |  | Genuine Miele Spherical bearing 2 Pcs. | 5872640 | $56.00Add to cart |
| 160 |  | Genuine Miele Tooth belt | 5812180 | $30.00Add to cart Special order: ships in 2 to 4 weeks |
| 170 |  | Genuine Miele AC motor 120V | 5812170 | $141.70Add to cart |
| 180 | | Genuine Miele Bracket AC motor | 5812210 | $18.80Read more |
| 190 | | Genuine Miele Motor bracket | 5812200 | $7.00Add to cart Special order: ships in 2 to 4 weeks |
| 200 | | Genuine Miele Wedge | 5863080 | $11.00Add to cart Special order: ships in 2 to 4 weeks |
| 210 |  | Genuine Miele Spring | 5981600 | $2.50Add to cart Special order: ships in 2 to 4 weeks |
| 220 | | Genuine Miele Buffer | 5812140 | $43.60Read more |
| 230 | | Genuine Miele Limit switch | 5884930 | $63.00Read more |
| 240 | Not Available | Cover | 5812250 | Not Available |
| 241 | No Image | Cover | 6588870 | $100.00Read more |
| 242+244 | | Genuine Miele Conv.kit cover 120V | 7495990 | $193.40Read more |
| 244 | | Genuine Miele printed circ. board LED 120V | 7448320 | $159.00Read more |
| 246+247 | | Genuine Miele conv.kit casing | 6646700 | $282.60Read more |
| 246+247 | | Genuine Miele conv.kit casing | 6646700 | $282.60Read more |
| 246 | | Genuine Miele Cover Switch | 6589390 | $15.00Read more |
| 250 | | Genuine Miele Lamp-holder Starter | 5863160 | $10.70Read more |
| 260 | | Genuine Miele Starter | 5862880 | $27.90Read more |
| 270 | | Genuine Miele Lamp-holder 2 Pcs. | 5872650 | $15.00Read more |
| 290 | Not Available | Neon tube | 5862870 | Not Available |
| 300 | | Genuine Miele Choke 120V | 5862930 | $85.50Read more |
| 310 |  | Genuine Miele Push button switch | 5862950 | $36.00Add to cart |
| 310 |  | Available ReconditionedReconditioned Genuine Miele Push button switch More Product Details | 5862950R | $32.00Add to cart |
| 320 | | Genuine Miele printed circ. board 120V | 5863060 | $189.00Add to cart Special order: ships in 2 to 4 weeks |
| 330 | | Genuine Miele Spring | 5981600 | $2.50Add to cart Special order: ships in 2 to 4 weeks |
| 340 |  | Genuine Miele Foot switch links | 5811960 | $27.00Add to cart |
| 350 |  | Genuine Miele Foot switch right | 5811970 | $63.00Add to cart |
| 360+370 | | Genuine Miele Top | 5811900 | $98.00Read more |
| 370 | | Genuine Miele Push button | 5811940 | $9.70Read more |
| 380+390 |  | Genuine Miele Connection socket | 5811990 | $87.69Add to cart Special order: ships in 2 to 4 weeks |
| 380+390 |  | Available Pre OwnedPre owned Miele Connection Socket Knuckle for SEB234 and SEB236 Power Nozzles PN: 5811990 More Product Details | 5811990R | $69.99Add to cart |
| 390 |  | Miele Foot Switch | 5872570 | $36.00Add to cart Special order: ships in 2 to 4 weeks |
| 400+410 |  | Genuine Miele Supply cable 1180mm 120V | 5811440 | $107.70Add to cart |
| 410 | | Genuine Miele Cable holder anthracite | 2245161 | $9.70Read more |
