Schematic and parts book for Filter Queen MA961 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 2A | Not Available | Cfamp AssyDirt Container | 5781000313 | Not Available |
| 2B | No Image | GASKET, INLET 96/99 1/16 THICK 10PK Part Number: 2430000200 for Filter Queen | 2430000200 | $29.05Read more |
| 2C | Not Available | Inlet Assy. | 2406000100 | Not Available |
| 2D | Not Available | Washer FQ 100 Pk | 8883000200 | Not Available |
| 2E | Not Available | Deflector Stainiess | 2451000100 | Not Available |
| 2G | Not Available | Spring. Clamp 100 pack | 2231000100 | Not Available |
| 2H | Not Available | Bracket>CiampDirt Container | 2781000500 | Not Available |
| 2A2 | Not Available | Rivet.tubular45/84" Ig 100 Pk | 8B88000300 | Not Available |
| 3 | Not Available | Gasket Dirt Container Black | 2430000101 | Not Available |
| 4 | Not Available | Caster Assy Complete Black | 5062000101 | Not Available |
| 4A | Not Available | Shield Caster 10 Pk | 2062000200 | Not Available |
| 4B | Not Available | Bumper Unit Stack | 2783000101 | Not Available |
| 4C | Not Available | Caster & Plate Assembly black | 2062000101 | Not Available |
| # | Part image | Description | SKU | Price |
| XX | Not Available | Label Nozzle 10 Pk | 2419200000 | Not Available |
| 1 | Not Available | Power Nozzle CompleteFQ96 | 5020000101 | Not Available |
| 2 | Not Available | Cover Assy w/Heat Trans Blk 88 | 5229000901 | Not Available |
| 2B | Not Available | Label WarningPower Nozzle 25 Pk | 2419100000 | Not Available |
| 2C | Not Available | Lens. Model 88 | 2229000100 | Not Available |
| 2E | Not Available | Label Reflector Model 88 10 Pk | 2419000400 | Not Available |
| 3 | No Image | SCREW, MOTOR MOUNTING 88/96 PN 100 PACK Part Number: 8888002700 for Filter Queen | 8888002700 | $18.91Read more |
| 4 | Not Available | Washer # 10 Locking 100 Pk | 8888001100 | Not Available |
| 5 | Not Available | Bracket Motor Nozzle | 2888002600 | Not Available |
| 6 | Not Available | Fastener On-sert 100 Pk | 2888001200 | Not Available |
| 7 | Not Available | Screw #8x1/2" PH 100Pk | 8888000900 | Not Available |
| 8 | Not Available | Motor Nozzle 110V Model 88 | 2008000500 | Not Available |
| 9 |  | Belt, Flat All Pn Optima & Uprights Part Number: 2260000100 for Filter Queen | 2260000100 | $6.00Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 | Not Available | Connector Wire 50 Pk | 2888003100 | Not Available |
| 13 | Not Available | Wire Nut # 30 50 Pk | 2888006000 | Not Available |
| 14 | Not Available | Circuit Breaker Assy. | 5304000100 | Not Available |
| 15 |  | Cord, PN W/ Strain Relief Triple Corwn Part Number: 2301000201 for Filter Queen | 2301000201 | $20.52Read more |
| 16 | Not Available | Insulator.NozzleModel 88 10 Pk | 2999000100 | Not Available |
| 17 | Not Available | Lamp Socket Assy | 2835000200 | Not Available |
| 17A | Not Available | LampNozzle 10 Pk | 2835000300 | Not Available |
| 18 | Not Available | Screw # 6 x 1/2"PH Pan 100Pk | 8888002400 | Not Available |
| 19 | Not Available | Retainer.AdaDtor. Black. Model 88 | 2211000101 | Not Available |
| 19A | Not Available | Screw # 8 x 3/4" PH Pan 100Pk | 8888002500 | Not Available |
| 20 | Not Available | Base W/ Onserts . labels | 5229000201 | Not Available |
| 20A | Not Available | Fastener On-sert. Inverted 100 Pk | 8888002000 | Not Available |
| 20B | Not Available | Label Height Adiustment 10 Pk | 2419000300 | Not Available |
| 21 | Not Available | Adaptor Assy Nozzle Locking BL | 5210000101 | Not Available |
| 21A | Not Available | Pin. Retainer 100 Pk | 8888002300 | Not Available |
| 22 |  | Cam, All Power Nozzles Part Number: 2225000100 for Filter Queen | 2225000100 | $4.40Read more |
| 23 |  | Shaft, Rear Wheel 88 Pn Part Number: 2888002100 for Filter Queen | 2888002100 | $1.92Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 24 | Not Available | Knob. Nozzle FQ Black 2 pack | 2888002200 | Not Available |
| 26 | Not Available | BumperNozzleModel 88 Black | 2783000201 | Not Available |
| 27 | Not Available | Washer. Steel. Nozzle 100 pack | 8888004000 | Not Available |
| 28 | Not Available | Brush RevolvingNaturalMod.88 2 Pk | 2291000100 | Not Available |
| 29 | Not Available | Sorina Roller Arm. Model 88 10 Pk | 2231000300 | Not Available |
| 30 | Not Available | BearingBrushRoller Model 52/88 2 Pk | 2023000100 | Not Available |
| 30A |  | DIRT SEAL, FIBER 48 P.N. Part Number: 2842000500 for Filter Queen | 2842000500 | $2.32Read more |
| 31 | Not Available | Seal. Dirt Nozzle. Model 88 25 Pk | 2842000100 | Not Available |
| 32 |  | Washer, Fiber All Power Nozzle Brushrolls Part Number: 8888003900 for Filter Queen | 8888003900 | $1.20Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 33 | Not Available | Arm Assv.Roller. Model 88 | 5281000100 | Not Available |
| 33B | Not Available | Washer Nvlon 100 pack | 8888004400 | Not Available |
| 33C | Not Available | Arm Roller Model 88 | 2281000100 | Not Available |
| 33D | Not Available | Pushnut 100Pk | 8888004100 | Not Available |
| 34 | Not Available | PlateRetainer Arm Roller | 2888001500 | Not Available |
| 35 | Not Available | Screw.# 6 x 3/8" PH Pan 100Pk too | 8888002800 | Not Available |
| 36 | Not Available | Plate Assy Bottom Stain Mod 88 | 5270000100 | Not Available |
| 36A | Not Available | Gasket Bottom Plate Sealing 20 Pk | 2430000501 | Not Available |
| 36B | Not Available | Gasket Bottom Plate Sealing 10 Pk | 2430000601 | Not Available |
| 36C | Not Available | Label.InstructionBottom Plate 10 Pk | 2419000100 | Not Available |
| 37 |  | SCREW, POWER NOZZLE BASE Part Number: 8888002900 for Filter Queen | 8888002900 | $0.31Read more |
| 38 |  | Screw, Bottom Plate 88 Pn Part Number: 8888003200 for Filter Queen | 8888003200 | $0.44Read more |
| 39 | Not Available | Label Circuit Breaker 10 Pk | 2419000900 | Not Available |
| 40 | Not Available | Label.Lamp.Nozzle 10 Pk | 2419000500 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Hose Assy 110V Black | 5802000601 | Not Available |
| 1B | Not Available | Stub Tube w/Seal Assy 1 JPf | 5482000201 | Not Available |
| 1A1 | Not Available | Handle. Plastic. Black 2 pes | 2724000201 | Not Available |
| 1A2 | Not Available | Switch Handle. Hose 120V | 2724000301 | Not Available |
| 1A3 | Not Available | Screws . Handle 100 pack | 8888003700 | Not Available |
| 1A4 | Not Available | Outlet Handle Hose 120 V | 2724000501 | Not Available |
| 1A5 | No Image | TUBE, HOSE PLASTIC INSIDE Part Number: 2313000101 for Filter Queen | 2313000101 | $43.24Read more |
| 1B1 | Not Available | SealJube.Short Black 1 / | 2842000201 | Not Available |
| 1C1 |  | Gasket, Hose Machine End Coupling Rubber Tube Part Number: 5430001001. for Filter Queen | 5430001001 | $6.89Read more |
| 10 |  | Pigtail, 9.5" Mxf 96 Pn Majestic Black Part Number: 2301000501 for Filter Queen | 2301000501 | $18.40Read more |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Upholstery Nozzle & Brush Complete | 5079000601 | Not Available |
| 1A | Not Available | Upholstery Nozzle Black | 2079000601 | Not Available |
| 1B | Not Available | Upholstery Brush Only Black | 2079000501 | Not Available |
| 1C | Not Available | Pin Retainer 100 Pk | 8888002300 | Not Available |
| 1D | Not Available | Spring Retainer 100 pack | 2231000200 | Not Available |
| 2 | Not Available | Dusting Brush Comp w/logo Blk | 5079000701 | Not Available |
| 2B |  | Insert, Dust Brush Horse Hair Part Number: 2079000200 for Filter Queen | 2079000200 | $16.58Read more |
| 2C | Not Available | Pin Retainer 100 Pk | 8888002300 | Not Available |
| 2D | Not Available | Spring Retainer 100 pack | 2231000200 | Not Available |
| 3 | Not Available | Wand Assy Stainless 120VBl | FQ-9630-3 | Not Available |
| 3A | Not Available | Spring Retainer 100 pack | 2231000200 | Not Available |
| 3B | Not Available | SealTubeShort Black | 2842000201 | Not Available |
| 3C |  | Cord, Pn Wand Triple Crown Mxf Black Part Number: 2301001701 for Filter Queen | 2301001701 | $23.88Read more |
| 3D | Not Available | Clip Cord.Nickie Plated 10 Pk | 2888007400 | Not Available |
| 3F | Not Available | Pin Retainer Metal 100 Pk | 8888003600 | Not Available |
| 4 | Not Available | Bare Floor Brush Black | 5079000501 | Not Available |
| 4A | Not Available | Pin Retainer Metal 100 Pk | 8888002300 | Not Available |
| 4B | Not Available | Spring Retainer 100 pack | 2231000200 | Not Available |
| 5 | Not Available | Crevice Tool Black | 5079000101 | Not Available |
| 5A | Not Available | Pin Retainer Metal 100 Pk 10Q | 8888002300 | Not Available |
| 5B | Not Available | Spring Retainer 100 pack | 2231000200 | Not Available |
