Schematic and parts book for Evolution 67909Z . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Brush Roll Assembly (Clutch) 3-Row | EV-01341202 | Not Available |
| 2 | Not Available | Brush Roll Core (Metal) 3-Row | V700315392 | Not Available |
| 3 | Not Available | Rubber End Cover | V700227301 | Not Available |
| 4 | Not Available | End Cap | V700172300 | Not Available |
| 5 | Not Available | Brush Roll Felt Washer | V700174300 | Not Available |
| 6 | Not Available | Washer (6.0*12*0.5) | VWA00991 | Not Available |
| 7 | Not Available | Brush Roll Bearing (626DD) | V700287300 | Not Available |
| 8 | Not Available | Brush Roll Bearing Holder (3-Row) | V700317300 | Not Available |
| 9 | Not Available | Brush Roll Brush | V700175500 | Not Available |
| 10 | Not Available | Clutch Pulley (Large) Complete 3-Row | V700316401 | Not Available |
| 11 | Not Available | Clutch Pulley (Large) 3-Row | V700316301 | Not Available |
| 12 | Not Available | E-Clip (ETW-5) | VE594 | Not Available |
| 13 | Not Available | Brush Roll Washer | VWA01893 | Not Available |
| 14 |  | Clutch Pulley Bernina 6700 (Small) For: evolution-bernina | V700270400 | $26.80Read more |
| 15 | Not Available | Clutch Pulley (Small) Cover | V700271391 | Not Available |
| 16 | Not Available | Clutch Pulley (Small) | V700270301 | Not Available |
| 17 | Not Available | Brush Roll Shaft | V700285300 | Not Available |
| 18 |  | HOLDER ONLY, BEARING FOR 3 ROW BRUSHROLL EVOLUTION Part Number: V700317400 for Evolution | V700317400 | $28.23Read more |
