Schematic and parts book for Evolution 6508C Motor. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Lamb Motor 119467-00 | V700990300 | Not Available |
| 2 | Not Available | Carbon Brush (Metal Cover) | V700992300 | Not Available |
| 3 | Not Available | Motor Mount (Rear) | V700233301 | Not Available |
| 4 |  | HOUSING, MOTOR SUPPORT 6500 Part Number: V700269303 for Evolution | V700269303 | $6.66Read more |
| 5 | Not Available | Suction Inlet Packing | V500020301 | Not Available |
| 6 | Not Available | Motor Mount (Front) | V700232301 | Not Available |
| 7 | Not Available | Motor Pivot Sleeve | V700234301 | Not Available |
| 8 | Not Available | Noise Suppressor | V700231300 | Not Available |
| 9 | Not Available | Set Screw (M4*15) | VM400191 | Not Available |
| 10 | Not Available | Vacuum Sensor Cord (16# Black) | V700966300 | Not Available |
| 11 |  | Switch, Reset Evolution Part Number: V700944300 for Evolution | V700944300 | $20.02Read more |
| 12 | Not Available | Washer (4.2*14*1) | VWA00194 | Not Available |
| 13 | Not Available | Set Screw (M3*12) | VM301695 | Not Available |
| 14 | Not Available | Wire Connector (HW-C4) | V700939300 | Not Available |
| 15 | Not Available | Cord Clip (TSL-100-M) | V700938300 | Not Available |
| 16 | Not Available | Wire Cord (SPT-2 18# White) | V700968300 | Not Available |
| 17 | Not Available | Motor Cord (SPT-2 16# Black) | V700969300 | Not Available |
| 18 | Not Available | Ground Cord (18# Green) | V700923300 | Not Available |
| 19 | Not Available | Reflector | V500016391 | Not Available |
| 20 | Not Available | Set Screw (M4*15) | VM400191 | Not Available |
| 21 | Not Available | Bulb Socket (75W 125V) | V700949500 | Not Available |
| 22 | Not Available | Light Bulb (15W 130V) | V700947300 | Not Available |
| 23 | Not Available | Spring Washer (3.1*5.9*0.7) | VWA00691 | Not Available |
| 24 | Not Available | Set Screw (M3*6) | VM300391 | Not Available |
| 25 | Not Available | Wire Bushing (4W-2) | V700937300 | Not Available |
