Schematic and parts book for Evolution 6100C Brush Roll. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Agitator Assembly (Metal) 2-Row | V700162400 | Not Available |
| 2 | Not Available | Agitator Core (Metal) 2-Row | V700162392 | Not Available |
| 3 | Not Available | Rubber End Cover | V700227301 | Not Available |
| 4 | Not Available | End Cap | V700172300 | Not Available |
| 5 | Not Available | Agitator Felt Washer | V700174300 | Not Available |
| 6 | Not Available | Washer (6.0*12*0.5) | VWA00991 | Not Available |
| 7 | Not Available | Agitator Bearing (626DD) | V700287300 | Not Available |
| 8 | Not Available | Agitator Bearing Holder (2-Row) | V700170300 | Not Available |
| 9 | Not Available | Agitator Brush | V700175500 | Not Available |
| 10 | Not Available | Agitator Pulley Complete (2-Row) | V720021400 | Not Available |
| 11 | Not Available | Agitator Pulley (2-Row) | V720022301 | Not Available |
| 12 | Not Available | Agitator Pulley Bushing | V720023391 | Not Available |
| 13 | Not Available | Agitator Shaft (New) | V700285300 | Not Available |
| 14 | Not Available | Lamb Motor 119560-00 | V700988300 | Not Available |
| 15 | Not Available | Carbon Brush (Metal Cover) | V700992300 | Not Available |
| 16 | Not Available | Motor Mount (Rear) | V700233301 | Not Available |
| 17 | Not Available | Motor Support Housing (Black) | V700311301 | Not Available |
| 18 | Not Available | Suction Inlet Packing | V500020301 | Not Available |
| 19 | Not Available | Motor Mount (Front) | V700232301 | Not Available |
| 20 | Not Available | Motor Pivot Sleeve | V700234301 | Not Available |
| 21 | Not Available | Noise Suppressor | V700231300 | Not Available |
| 22 | Not Available | Set Screw (M4*15) | VM400191 | Not Available |
| 23 | Not Available | Wire Connector (HW-C4) | V700939300 | Not Available |
| 24 | Not Available | Motor Cord (SPT-2 16#) Black | V700943300 | Not Available |
| 25 | Not Available | Wire Cord (SPT-2 18#) White | V700968300 | Not Available |
| 26 | Not Available | Reflector | V500016391 | Not Available |
| 27 | Not Available | Set Screw (M4*15) | VM400191 | Not Available |
| 28 | Not Available | Bulb Socket (75W 125V) | V700949500 | Not Available |
| 29 | Not Available | Light Bulb (15W 130V) | V700947300 | Not Available |
| 30 | Not Available | Spring Washer (3.1*5.9*0.7) | VWA00691 | Not Available |
