Schematic and parts book for Electrolux U129B, U136B, U139A, SC6600A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| XX | Not Available | Lead Assy (Blue) On/Off Switch | EX-47898 | Not Available |
| XX | Not Available | Secondary Motor Filter Without TOOIS | EXR-1825 | Not Available |
| XX | Not Available | Wand Guide - Right U139A 37 NLA Handle U136B | EX-47840 | Not Available |
| XX | Not Available | Filter & Pv-104306 Wheels) 39 NLA Rivet | EXR-1802 | Not Available |
| XX | Not Available | ELECTROLUX BRUSHROLL DOWEL WILL | NON-GENUINE | Not Available |
| 1 | Not Available | Duct Assembly U129B | EX-46942 | Not Available |
| 1 | Not Available | Duct Assembly U136B | NLA | Not Available |
| 2 | Not Available | Exhaust Deflector | EX-47874 | Not Available |
| 3 | Not Available | Motor Body Housing | NLA | Not Available |
| 3 | Not Available | Motor Body Housing SC6600A Red | NLA | Not Available |
| 3 | Not Available | Motor Body Housing SC6600A Gray | PVR-7500 | Not Available |
| 4 | Not Available | Wheel Bearing | NLA | Not Available |
| 5 | Not Available | Rear Wheel 2 PK | PV-104306 | Not Available |
| 6 | Not Available | Duct Hose | NLA | Not Available |
| 6 | Not Available | Duct Hose | EXR-4500 | Not Available |
| 7 | Not Available | Wire Harness | NLA | Not Available |
| 7 | Not Available | Wire Harness U139A Only | NLA | Not Available |
| 8 | Not Available | Lower Motor Mount | EX-47611 | Not Available |
| 9 | Not Available | Suction Motor | E-62078-1 | Not Available |
| 10 | Not Available | Upper Motor Mount | EX-43232 | Not Available |
| 11 | Not Available | Detent Spring | E-07518-0011 | Not Available |
| 12 | Not Available | Nozzle Cover U129B Only | EX-47197 | Not Available |
| 12 | Not Available | Nozzle Cover SC6600A (Color May Vary) | E-07510-0153 | Not Available |
| 13 | Not Available | :S crew | E-00253-0018 | Not Available |
| 14 | Not Available | Insulator Grommet | NLA | Not Available |
| 15 | Not Available | Brushroll Motor | NLA | Not Available |
| 15 | Not Available | Brushroll Motor | EXR-6060 | Not Available |
| 16 | Not Available | Belt Retainer (Order C0-42820) | NLA | Not Available |
| 17 | Not Available | Pulley & Bearing Assembly | EX-45121 | Not Available |
| 17 | Not Available | Pulley & Bearing Assembly Lockout Switch) U129B U139A | EXR-6225 | Not Available |
| 18 | Not Available | Geared Belt 3/8" Wide | CO-48359 | Not Available |
| 18 |  | Electrolux Belt PN4 PN5 and New Style Tristar Heads | EXR1080 | $6.00Add to cart |
| 19 | Not Available | :S crew | E-00253-0018 | Not Available |
| 20 | Not Available | Duct Hose Retainer U129B U139A SC6600A To Wand Lockout Switch | NLA | Not Available |
| 20 | Not Available | Duct Hose Retainer U136B U139A SC6600A | EX-45137 | Not Available |
| 21 | Not Available | Duct Hose Sleeve | NLA | Not Available |
| 21 | Not Available | Duct Hose Sleeve U136B | NLA | Not Available |
| 22 | Not Available | Nozzle Base Seal - Left NLA Wand Lockout Switch | NLA | Not Available |
| 22A | Not Available | Nozzle Base Seal - Right U139A SC6600A | NLA | Not Available |
| 23 | Not Available | Nozzle Base SC6600A Only | NLA | Not Available |
| 24 | Not Available | Front Roller Shaft 2 Pk U129B U139A SC6600A | E-07543-0025 | Not Available |
| 25 | Not Available | Front Roller | NLA | Not Available |
| 26 | Not Available | Bumper U129B U139A (Order E-05139-0140) | NLA | Not Available |
| 26 | Not Available | Bumper SC6600A Gray U129B U139A SC6600A | NLA | Not Available |
| 27 | Not Available | :S crew | E-00263-0019 | Not Available |
| 28 | Not Available | Brushroll Bearing Retainer | E-07538-0020 | Not Available |
| 29 | Not Available | !S crew (order EXR-1825) | E-00232-0018 | Not Available |
| 30 | Not Available | Wire Form U129B U139A SC6600A | NLA | Not Available |
| 31 |  | Circuit Breaker, Model 1500XP Part Number: 104212 for Proteam | 104212 | $44.24Read more |
| 32 | Not Available | PC Board - Performance Indicator NLA Hose & Tool Caddy U139A SC6600A | NLA | Not Available |
| 33 | Not Available | Brushroll Dowel (Order E-62077-1) U139A SC6600A | NLA | Not Available |
| 33A | Not Available | Brushroll Assembly | NLA | Not Available |
| 34 | Not Available | Bearing & Shaft Assembly | EX-45124 | Not Available |
| 35 | Not Available | Lead Assembly U129B U139A | EX-46928 | Not Available |
| 35 | Not Available | Lead Wire U136B | EX-45855 | Not Available |
| 35 | Not Available | Lead Wire Blue SC6600A NON-GENUINE ELECTROLUX COMPLETE BRUSHROLL | NLA | Not Available |
| 36 | Not Available | Lead Wire U136B | NLA | Not Available |
| 36 | Not Available | Lead Assembly ASSEMBLIES AND EUREKA SC6600 SANITAIRE | NLA | Not Available |
| 37 | Not Available | Handle Assembly Without Cord | NLA | Not Available |
| 37 | Not Available | Handle U136B | NLA | Not Available |
| 38 | Not Available | Cord 50' 18/3 Red (Order E-39857) | NLA | Not Available |
| 38 | Not Available | Cord 50' 18/3 Beige W/O Rivet | E-39857 | Not Available |
| 38 | Not Available | Cord 50' 18/3 Beige | EXR-3025-1 | Not Available |
| 38 | Not Available | Cord U136B | NLA | Not Available |
| 39 | Not Available | Rivet | NLA | Not Available |
| 40 | Not Available | Handle Bushing | E-05332-0006 | Not Available |
| 41 | Not Available | Carry Handle | NLA | Not Available |
| 41 | Not Available | Carry Handle U136B | NLA | Not Available |
| 42 | Not Available | Screw | E-00209-0007 | Not Available |
| 43 | Not Available | On/Off Switch | E-00941-0061 | Not Available |
| 44 | Not Available | Switch Insulator | EX-47378 | Not Available |
| 45 | Not Available | Screw | EX-43991 | Not Available |
| 46 | Not Available | Switch Case | NLA | Not Available |
| 47 | Not Available | Bag Housing U129B | NLA | Not Available |
| 47 | Not Available | Bag Housing U136B | NLA | Not Available |
| 47 | Not Available | Bag Housing U139A | EX-47884 | Not Available |
| 47 | Not Available | Bag Housing SC6600A | E-39852 | Not Available |
| 48 | Not Available | Screw | EX-47117 | Not Available |
| 49 | Not Available | Screw | NLA | Not Available |
| 50 | Not Available | Bag Cover Latch | NLA | Not Available |
| 51 | Not Available | Bulkhead U129B U139A | EX-47372 | Not Available |
| 51 | Not Available | Bulkhead U136B | NLA | Not Available |
| 52 | Not Available | Lead Assy (Black - On/Off Switch To | EX-47383 | Not Available |
| 53 | Not Available | Lead Assy (Red - On/Off Switch | EX-47382 | Not Available |
| 54 | Not Available | Bag Lockout Switch | EX-46943 | Not Available |
| 54 | Not Available | Bag Lockout Swi tch U136B | NLA | Not Available |
| 55 | Not Available | Switch Insulator | EX-47028 | Not Available |
| 56 | Not Available | Tubing (Pressure Switch) | NLA | Not Available |
| 57 | Not Available | Pressure Switch | EX-46939 | Not Available |
| 58 | Not Available | Access Port Plug U129B U139A | NLA | Not Available |
| 58 | Not Available | Access Port Plug U136B | EX-47929 | Not Available |
| 59 | Not Available | Secondary Motor Filter | NLA | Not Available |
| 60 | Not Available | Bag Cover U139A | NLA | Not Available |
