Schematic and parts book for Electrolux SP7025A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | BOTTOM PART CPL | E-2191797-04 | Not Available |
| 2 | Not Available | DUST CONTAINER | E-1130901-02 | Not Available |
| 3 | Not Available | MOTOR HOUSING | E-1130902-01 | Not Available |
| 4 | Not Available | SEALING - MOTOR | E-1130903-02 | Not Available |
| 5 | Not Available | MOTOR COVER - HOUSING | E-1130904-01 | Not Available |
| 6 | Not Available | SUSPENSION - REAR DOM | E-1130909-01 | Not Available |
| 7 | Not Available | ABSORBENT -MOTORHOUSE | E-1130910-01 | Not Available |
| 8 | Not Available | HOLDER - FILTER | E-1130911-01 | Not Available |
| 9 | Not Available | NO FILTER SAFETY DEV | E-1130912-01 | Not Available |
| 10 | Not Available | NO BAG SAFETY DEVICE | E-1130914-01 | Not Available |
| 11 | Not Available | BRACKET - NOZZLE PARK | E-1130916-01 | Not Available |
| 12 | Not Available | REAR WHEEL | E-1130608-03 | Not Available |
| 13 | Not Available | COVER - HOSE CONNECT | E-1130919-01 | Not Available |
| 14 | Not Available | RING - HOSE CONNECTION | E-1130920-01 | Not Available |
| 15 | Not Available | GROMMET | E-1130923-01 | Not Available |
| 17 | Not Available | SLEEVE - HOSE CONNECTION | E-1130927-01 | Not Available |
| 18 | Not Available | GROMMET- FRONT COVER | E-1130928-01 | Not Available |
| 19 | Not Available | FILTER - PERMANENT F2 | E-1130929-01 | Not Available |
| 20 | Not Available | HOLDER - BAG | E-1130930-01 | Not Available |
| 21 | Not Available | COVER - REAR SATINE CAYEN | E-1130934-09 | Not Available |
| 22 | Not Available | DIFFUSOR - COMPLETE OUTLE | E-1130935-02 | Not Available |
| 24 | Not Available | DIFFUSOR - COMPLETE OUTLE | E-1130937-02 | Not Available |
| 25 | Not Available | DISPLAY - PRINTED LEVEL 4 | E-1130938-02 | Not Available |
| 26 | Not Available | FILTER - O2 NON WASH | E-1130939-01 | Not Available |
| 27 | Not Available | HANDLE | E-1130940-01 | Not Available |
| 28 | Not Available | GRIP - HANDLE | E-1130941-01 | Not Available |
| 29 | Not Available | PIN - HANDLE AL SILVER (P | E-1130942-02 | Not Available |
| 33 | Not Available | PEDAL - CORDWINDER | E-1130946-01 | Not Available |
| 34 | Not Available | LIGHT CONDUCTOR | E-1130949-02 | Not Available |
| 35 | Not Available | REFLECTOR | E-1130950-02 | Not Available |
| 36 | Not Available | CABLE - MOTOR TERMO UL | E-1130969-01 | Not Available |
| 38 | Not Available | CABLE - POWER OUTLET | E-1130958-01 | Not Available |
| 40 | Not Available | CVR & GRPHCS ASSY (DRLLD | E-1130967-50 | Not Available |
| 41 | Not Available | SUMO BOARD | E-1180136-53 | Not Available |
| 42 | Not Available | MODULE - AUT SUMO UL | E-1180113-52 | Not Available |
| 43 | Not Available | MODULE - MAIN UL | E-1180110-02 | Not Available |
| 44 |  | EnviroCare Replacement Filters Designed to Fit Filter Queen Vacuums 12 Pack | FQR1450 | $8.04Add to cart |
| 45 | Not Available | MOTOR ASSY - PACKAGED | E-63160 | Not Available |
| 46 | Not Available | SEALING | E-115857-05 | Not Available |
| 47 | Not Available | HOSE - COOLING 100 MM EPD | E-117990-15 | Not Available |
| 48 | Not Available | HOSE - COOLING 115 MM EPD | E-117990-12 | Not Available |
| 49 | Not Available | HOSE - COOLING 135 MM EPD | E-117990-16 | Not Available |
| 50 | Not Available | HOSE - COOLING 80 MM EPDM | E-117990-14 | Not Available |
| 51 | Not Available | HOSE - COOLING 65 MM EPDM | E-117990-13 | Not Available |
| 54 | Not Available | MODULE - BAG/FILTER UL 10 in package. | E-1180111-51 | Not Available |
| 55 | Not Available | SPRING PACKAGE 10 in package. | E-63157 | Not Available |
| 57 | Not Available | SPRING PACKAGE | E-63158 | Not Available |
| 58 | Not Available | SEAL | E-1130289-01 | Not Available |
| 59 | Not Available | CORD WINDER CPL UL RIGHT | E-1128341-41 | Not Available |
| 61 | Not Available | REAR WHEEL COVER | E-1130614-01 | Not Available |
| 62 | Not Available | WHEEL SUPPORT | E-1096042-03 | Not Available |
| 63 | Not Available | FRONT WHEEL CPL. | E-1129038-01 | Not Available |
| 65 | Not Available | SPRING PACKAGE 10 in package. | E-63147 | Not Available |
| # | Part image | Description | SKU | Price |
| XX | Not Available | Sumo Adapter | E-045027-355N | Not Available |
| 1 | Not Available | SWIVEL HOSE ASSY - CARTON | E-61054-4 | Not Available |
| 2 | Not Available | FLOOR & WALL BRUSH ASSEMB | E-75973-1 | Not Available |
| 3 | Not Available | NOZZLE - FURNITURE | E-75985 | Not Available |
| 4 | Not Available | NOZZLE - CREVICE | E-76250 | Not Available |
| 5 | Not Available | NOZZLE - DUSTING BRUSH | E-75986 | Not Available |
| 6 |  | DVC Replacement HEPA Vacuum bags for Electrolux Style S & OX Harmony Canister 5pk | 836301000711 | $10.82Add to cart |
| 7 | Not Available | TELESCOPIC WAND ASSY. | E-75979-1 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 |  | Eureka Geared Belt for EL6983 Vacuum - 75614 | E75614 | $6.59Read more |
| 2 | Not Available | WASHER PACKAGE | E-63153 | Not Available |
| 3 | Not Available | LIGHT BULB | E-61682 | Not Available |
| 4 | Not Available | LIGHT SOCKET | E-61727 | Not Available |
| 5 | Not Available | MOTOR ASSEMBLY - CARTONED | E-61740-1 | Not Available |
| 6 | Not Available | SCREW PACKAGE | E-63155 | Not Available |
| 7 | Not Available | WIRE SPLICE 5 | E-58313 | Not Available |
| 8 | Not Available | WAND RELEASE ASSEMBLY | E-75810A-2 | Not Available |
| 9 | Not Available | HOOD ASSEMBLY - PACKAGED | E-61730-3 | Not Available |
| 10 | Not Available | PEDAL ASSEMBLY | E-61728 | Not Available |
| 11 | Not Available | SCREW PACKAGE | E-63155 | Not Available |
| 12 | Not Available | CLAMP CABLE | E-58430 | Not Available |
| 13 | Not Available | SWITCH - RESET | E-74594 | Not Available |
| 14 | Not Available | C-CLAMP PACKAGE | E-63154 | Not Available |
| 15 | Not Available | T-JOINT ASSEMBLY | E-39973-2 | Not Available |
| 16 | Not Available | BRUSHROLL ASSY - CARTONED | E-61699-1 | Not Available |
| 17 | Not Available | SOLE PLATE ASSEMBLY | E-61753-1 | Not Available |
| 18 | Not Available | INSERT - FRONT WHEEL | E-76136 | Not Available |
| 19 | Not Available | FRONT WHEEL | E-61750 | Not Available |
| 20 | Not Available | WASHER PACKAGE | E-63153 | Not Available |
| 21 | Not Available | E-RING PACKAGE | E-61752 | Not Available |
| 22 | Not Available | FRONT AXLE | E-61749 | Not Available |
| 23 | Not Available | CAM BEARING | E-61747 | Not Available |
| 24 | Not Available | BASE ASSEMBLY - PACKAGED | E-61746-4 | Not Available |
| 25 | Not Available | SPRING | E-61748 | Not Available |
| 26 | Not Available | AIR DUCT COVER ASSEMBLY | E-61734 | Not Available |
| 28 | Not Available | POWERHEAD ASSY (BETA-SUMO Powerhead Asspomplete. | E-75922-3 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | POWERHEAD ASSY (SP2-NO GR Sold complete. | E-76577-2 | Not Available |
