Schematic and parts book for Electrolux EL8400A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HOOD ASSEMBLY - PACKAGED | 16128-22 | Not Available |
| 2 | Not Available | HEIGHT ADJUST KNOB&GRAPHI | 87457 | Not Available |
| 3 | Not Available | HEIGHT ACTUATOR | 83873A-119N | Not Available |
| 4 | Not Available | BASE ASSEMBLY | 87102-1 | Not Available |
| 5 | Not Available | BRUSHROLL ASSEMBLY CARTON | 16156-8 | Not Available |
| 6 | Not Available | WIPER BLADE | 84579 | Not Available |
| 7 | Not Available | FELT | 83975 | Not Available |
| 8 | Not Available | AXLE - FRONT WHEEL | 83875 | Not Available |
| 9 | Not Available | WHEEL - FRONT WITH OVERMO | 86757-355N | Not Available |
| 10 | Not Available | WHEEL CARRIAGE | 83874-625N | Not Available |
| 11 | Not Available | SPRING PACKAGE | 54943-7 | Not Available |
| 12 | Not Available | BELT | 86389 | Not Available |
| 13 | Not Available | WHEEL COVER | 86711-625M | Not Available |
| 14 | No Image | REAR AXLE, AS5203A Part Number: 83973 for Eureka | 83973 | $4.84Read more |
| 15 | Not Available | WHEEL - REAR WITH OVERMOL | 86759-313N | Not Available |
| 16 | Not Available | CLIP RETAINER | 83974 | Not Available |
| 17 | Not Available | BRUSH ON/OFF ASSEMBLY | 87025-3 | Not Available |
| 18 | No Image | Base Hose Assy, AirSpeed AS5203A/AS5210A Part Number: 16153-1 for Eureka | 161531 | $12.83Read more |
| 20 | Not Available | PEDAL-HANDLE RELEASE W/OV | 86713-625N | Not Available |
| 21 | Not Available | SPRING - HANDLE RELEASE | 84040 | Not Available |
| 22 | Not Available | MOTOR CLAMP | 83944 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | DUST CUP & FILTER ASSEMBL | 86829-1 | Not Available |
| 2 | Not Available | DUST CUP FILTER FRAME & G | 85380-1 | Not Available |
| 3 | Not Available | FOAM FILTER | 83889 | Not Available |
| 4 | Not Available | FILTER SCREEN (ABS) | 8389-572T | Not Available |
| 5 | Not Available | CONICAL AIR SPOILER | 83896-469M | Not Available |
| 7 | Not Available | GASKET - BOTTOM DOOR | 83902-313N | Not Available |
| # | Part image | Description | SKU | Price |
| XX | Not Available | ALLEN WRENCH & SCREW PACK | 87459 | Not Available |
| XX | Not Available | OWNERS GUIDE | 86704 | Not Available |
| 1 | Not Available | HOSE AND WAND ASSY | 83869-3 | Not Available |
| 2 | Not Available | HOOK - CORD | 84051-625N | Not Available |
| 3 | Not Available | UPPER HANDLE ASSEMBLY | 86828-1 | Not Available |
| 4 | Not Available | TOOL - CREVICE | 78519-625N | Not Available |
| 5 | Not Available | COMBINATION BRUSH (SOURCE | AA1017 | Not Available |
| 7 |  | Belt, Geared EL8025/EL8505 Part Number: 79270 for Eureka | 79270 | $23.57Read more |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HEPA COVER & GRAPHICS ASS | 86723-1 | Not Available |
| 2 | Not Available | HEPA FILTER ASSEMBLY | 83936-7 | Not Available |
| 3 | Not Available | SHIELD | 86729-469P | Not Available |
| 4 | Not Available | GASKET-MOTOR CAN | 83906-119N | Not Available |
| 5 | Not Available | SEAL MOTOR INTAKE | 83907-119N | Not Available |
| 6 | Not Available | COVER LOWER MOTOR | 86726-469P | Not Available |
| 7 | No Image | MOTOR, AS5203A Part Number: 62431-5 for Eureka | 624315 | $89.52Read more |
| 8 | Not Available | COVER - SWITCH | 84049-119N | Not Available |
| 9 | Not Available | WASHER-FIBER | 74178 | Not Available |
| 10 | Not Available | SWITCH ASSEMBLY | 81142-1 | Not Available |
| 11 | Not Available | CORD STRAIN RELIEF | 84050-119N | Not Available |
| 12 | Not Available | BUSHING - MOTOR | 84816-119N | Not Available |
| 13 | Not Available | SUPPLY CORD & TERMINAL AS | 39585-51 | Not Available |
| 14 | Not Available | VALVE BODY CVR & GRPHCS A | 84319-3 | Not Available |
| 15 | Not Available | KNOB-VALVE | 86730-572M | Not Available |
| 16 | Not Available | COVER UPPER MOTOR | 86728-469P | Not Available |
| 17 | Not Available | CLIP - BACKBONE | 83979-119N | Not Available |
| 18 | Not Available | LOWER CORD WRAP | 83868-625N | Not Available |
| 19 | Not Available | GASKET-CUP INLET | 83920-355N | Not Available |
