Schematic and parts book for Electrolux EL7055A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | CYCLONE OUTLET ASSEMBLY | 63606 | Not Available |
| 2 | Not Available | DIRT CUP ASSEMBLY | 63607 | Not Available |
| 3 | Not Available | FILTER CASSETTE ASSEMBLY | 63608 | Not Available |
| 5 | Not Available | SEALING CYCLONE IN/OUT | 1180027-02 | Not Available |
| 6 | Not Available | SEALING FILTER LOWER | 1180086-01 | Not Available |
| 7 | Not Available | CHAMBER FILTER | 1180011-01 | Not Available |
| 8 | Not Available | MOTOR PROTECTION GRID | 1180037-01 | Not Available |
| 9 | Not Available | COOLING HOSE | 1180056-01 | Not Available |
| 10 | Not Available | FLAP ASSEMBLY | 63609 | Not Available |
| 11 | Not Available | CHANNEL & WIRING ASSEMBLY | 63610 | Not Available |
| 12 | Not Available | LEVER MICROSWITCH | 1180080-02 | Not Available |
| 14 | No Image | SWITCH, BOARD ASSEMBLY EL7055,EL7057 Part Number: 1180155-51 for Eureka | 118015551 | $34.39Read more |
| 15 | Not Available | CHAMBER CLEANER | 1180010-01 | Not Available |
| 16 | Not Available | FRONT WHEEL | 6680981-61 | Not Available |
| 17 | Not Available | WHEEL SUPPORT | 1096042-04 | Not Available |
| 18 | Not Available | CABLE | 1180132-51 | Not Available |
| 19 | Not Available | Sumo Board | 1180136-53 | Not Available |
| 20 | Not Available | MODULA PCB | 1180110-53 | Not Available |
| 21 | Not Available | OUTER HOSE CONNECTION | 1180051-01 | Not Available |
| 22 | Not Available | LOWER SHELL | 1180000-06 | Not Available |
| 23 | Not Available | REAR WHEEL ASSEMBLY | 63611 | Not Available |
| 24 | Not Available | COVER PLUG RECESS | 1180084-02 | Not Available |
| 25 | Not Available | COOLING HOSE | 1180038-01 | Not Available |
| 26 | Not Available | COOLING HOSE | 1180056-02 | Not Available |
| 27 | Not Available | COOLING HOSE 10 Each | 1180045-01 | Not Available |
| 28 | Not Available | WIRE TO CORD WINDER | 1180162-01 | Not Available |
| 29 | Not Available | CORD WINDER | 1180073-58 | Not Available |
| 30 | Not Available | SEALING MOTOR | 1180003 | Not Available |
| 31 | Not Available | CABLE - MOTOR TERMO UL | 1130969-02 | Not Available |
| 32 | Not Available | MOTOR ASSY. | 63160 | Not Available |
| 33 | Not Available | ABSORBENT INNER | 1130292-02 | Not Available |
| 34 | Not Available | SUSPENSION - REAR DOM | 1130909-01 | Not Available |
| 35 | Not Available | SPRING - PKGD | 61403-1 | Not Available |
| 36 | Not Available | RELEASE BUTTON | 1180049-01 | Not Available |
| 37 |  | Filter, Electrolux "S" HEPA EL5010/EL6988 Part Number: EL012B for Eureka | EL012B | $43.15Read more |
| 37 |  | Compatible alternateFilter H12 DVC Electrolux HEPA 1pk More Product Details | 67812AAM | $21.51Add to cart |
| 38 | Not Available | Absorbent Rear Filter Lid | 1180071-02 | Not Available |
| 39 | Not Available | FILTER LID REAR | 1180006-01 | Not Available |
| 40 | Not Available | WHEEL HOUSE COVER LEFT | 1180041-01 | Not Available |
| 41 | Not Available | WHEEL HOUSE COVER RIGHT | 1180042-01 | Not Available |
| 42 | Not Available | SIDE COVER LEFT | 1180039-02 | Not Available |
| 43 | Not Available | SIDE COVER RIGHT | 1180040-02 | Not Available |
| 44 | Not Available | DISPLAY BOTTOM | 1180007-02 | Not Available |
| 45 | Not Available | DISPLAY BOARD 10 in package. | 1180159-51 | Not Available |
| 46 | Not Available | REFLECTOR 10 in package. | 1180081-01 | Not Available |
| 47 | Not Available | CLEANER CONTROL & GRPHCS | 77538 | Not Available |
| 48 | Not Available | FILTER COVER & GRPHCS ASS | 77540 | Not Available |
| # | Part image | Description | SKU | Price |
| XX | Not Available | HANDLE RELEASE PEDAL -NOT SHOWN IN DIAGRAM) | 61743 | Not Available |
| 1 | Not Available | COGGED BELT | 75614 | Not Available |
| 2 | Not Available | WASHER PACKAGE | 63153 | Not Available |
| 3 | Not Available | LIGHT BULB | 61682 | Not Available |
| 4 | Not Available | LIGHT SOCKET | 61727 | Not Available |
| 5 | Not Available | 740-1 POWERHEAD MOTOR | 61 | Not Available |
| 6 | Not Available | SCREW PACKAGE | 63155 | Not Available |
| 7 | Not Available | WIRE SPLICE 5 | 58313 | Not Available |
| 8 | Not Available | WAND RELEASE ASSY | 75810A-2 | Not Available |
| 9 | Not Available | 730-4 HOOD | 61 | Not Available |
| 10 | Not Available | HEIGHT ADJUSTMENT PEDAL | 61728 | Not Available |
| 11 | Not Available | SCREW PACKAGE | 63155 | Not Available |
| 12 | Not Available | CLAMP CABLE | 58430 | Not Available |
| 13 | Not Available | SWITCH-RESET | 74594 | Not Available |
| 14 | Not Available | C-CLAMP PACKAGE | 63154 | Not Available |
| 15 | Not Available | T-JOINT ASSY | 39973-2 | Not Available |
| 16 | Not Available | BRUSH ROLL ASSY. | 61699-1 | Not Available |
| 17 | Not Available | 753-1 SOLE PLATE ASSEMBLY | 61 | Not Available |
| 18 | Not Available | INSERT - FRONT WHEEL | 76136 | Not Available |
| 19 | Not Available | FRONT WHEEL | 61750 | Not Available |
| 20 | Not Available | WASHER PACKAGE | 63153 | Not Available |
| 21 | Not Available | E-RING PACKAGE | 61752 | Not Available |
| 22 | Not Available | FRONT AXLE | 61749 | Not Available |
| 23 | Not Available | 747 CAM BEARING | 61 | Not Available |
| 24 | Not Available | 746-4 BASE ASSEMBLY - PACKAGED | 61 | Not Available |
| 25 | Not Available | Sprinq | 61748 | Not Available |
| 26 | Not Available | AIR DUCT ASSY. | 61734 | Not Available |
| 28 | Not Available | POWERHEAD ASSY (BETA-SUMO Powerhead Assy. complete. | 75922-1 | Not Available |
| # | Part image | Description | SKU | Price |
| XX | Not Available | CADDY - TOOL Not Pictured | 76161-366N | Not Available |
| 1 | Not Available | Swivel Hose Assy | 61054-3 | Not Available |
| 2 | Not Available | FLOOR BRUSH | 75973-1 | Not Available |
| 3 | Not Available | NOZZLE-FURNITURE | 75985 | Not Available |
| 4 | Not Available | NOZZLE - CREVICE | 76250 | Not Available |
| 5 | Not Available | Dustinq Brush - Packaqe | 75986 | Not Available |
| 6 | Not Available | TELESCOPIC WAND ASSY. (NLA) | 75979-1 | Not Available |
