Schematic and parts book for Electrolux EL7020B . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | BOTTOM PART | 1130900-01 | Not Available |
| 2 |  | Dirt Cup, Gray EL7020A Part Number: 1130901-02 for Eureka | 113090102 | $62.74Read more |
| 3 | Not Available | MOTOR HOUSING | 1130902-01 | Not Available |
| 4 | Not Available | SEALING - MOTOR | 1130903-02 | Not Available |
| 5 | Not Available | MOTOR COVER - HOUSING | 1130904-01 | Not Available |
| 6 | Not Available | SUSPENSION - REAR DOM | 1130909-01 | Not Available |
| 7 | Not Available | ABSORBENT - MOTORHOUSE | 1130910-01 | Not Available |
| 8 | Not Available | HOLDER - FILTER | 1130911-01 | Not Available |
| 9 | Not Available | NO FILTER SAFETY DEV | 1130912-01 | Not Available |
| 10 | Not Available | NO BAG SAFETY DEVICE | 1130914-01 | Not Available |
| 11 | Not Available | BRACKET - NOZZLE PARK | 1130916-01 | Not Available |
| 13 | Not Available | COVER - HOSE CONNECT | 1130919-01 | Not Available |
| 14 | Not Available | RING - HOSE CONNECTION | 1130920-01 | Not Available |
| 15 | Not Available | GROMMET | 1130923-01 | Not Available |
| 17 | Not Available | SLEEVE - HOSE CONNECTION | 1130927-01 | Not Available |
| 18 | Not Available | GROMMET - FRONT COVER | 1130928-01 | Not Available |
| 19 | Not Available | FILTER - PERMANENT F2 | 1130929-01 | Not Available |
| 20 | Not Available | HOLDER - BAG | 1130930-01 | Not Available |
| 21 | Not Available | COVER - REAR SATINE CAYEN | 1130934-09 | Not Available |
| 22 | Not Available | DIFFUSOR - COMPLETE OUTLE | 1130935-02 | Not Available |
| 24 | Not Available | DIFFUSOR - COMPLETE OUTLE | 1130937-02 | Not Available |
| 25 | Not Available | DISPLAY - PRINTED LEVEL 4 | 1130938-02 | Not Available |
| 26 | Not Available | FILTER - O2 NON WASH | 1130939-01 | Not Available |
| 27 | No Image | HANDLE, EL7020 Part Number: 1130940-01 for Eureka | 113094001 | $87.89Read more |
| 28 | Not Available | GRIP - HANDLE | 1130941-01 | Not Available |
| 29 | Not Available | HANDLE PIN PACKAGE | 1130942-02 | Not Available |
| 33 | No Image | PEDAL, CORD RELEASE EL7020 Part Number: 1130946-01 for Eureka | 113094601 | $4.73Read more |
| 34 | Not Available | LIGHT CONDUCTOR | 1130949-02 | Not Available |
| 35 | Not Available | REFLECTOR | 1130950-02 | Not Available |
| 36 | Not Available | CABLE - MOTOR TERMO UL | 1130969-01 | Not Available |
| 38 | Not Available | CABLE - POWER OUTLET | 1130958-01 | Not Available |
| 40 | Not Available | COVER & GRAPHICS CPL | 1130967-16 | Not Available |
| 41 | Not Available | SUMO BOARD | 1180136-56 | Not Available |
| 42 |  | Electrolux EL7000A Canister sumo PCB board pn 1180113-01 Sumo Module UL | 1180113-01 | $60.50Read more |
| 43 | Not Available | MODULE - MAIN UL | 1180110-01 | Not Available |
| 44 | Not Available | S BAG CLASSIC | EL200B | Not Available |
| 45 | Not Available | MOTOR ASSY - PACKAGED | 63160 | Not Available |
| 46 | Not Available | SEALING | 115857-05 | Not Available |
| 47 | Not Available | HOSE - COOLING 100 MM EPD | 117990-15 | Not Available |
| 48 | Not Available | HOSE - COOLING 115 MM EPD | 117990-12 | Not Available |
| 49 | Not Available | HOSE - COOLING 135 MM EPD | 117990-16 | Not Available |
| 50 | Not Available | HOSE - COOLING 80 MM EPDM | 117990-14 | Not Available |
| 51 | Not Available | HOSE - COOLING 65 MM EPDM | 117990-13 | Not Available |
| 54 | Not Available | MODULE - BAG/FILTER UL | 1180111-01 | Not Available |
| 55 | Not Available | SPRING PACKAGE 10 in package. | 63157 | Not Available |
| 57 | Not Available | SPRING PACKAGE 10 in package. | 63158 | Not Available |
| 58 | Not Available | SEAL | 1130289-01 | Not Available |
| 59 | Not Available | CORD WINDER CPL UL RIGHT | 1128341-41 | Not Available |
| 60 | No Image | WHEEL, REAR EL6988 EL6989 Part Number: 1130608-03 for Eureka | 113060803 | $31.25Read more |
| 61 | No Image | COVER, REAR WHEEL EL6988 Part Number: 1130614-03 for Eureka | 113061403 | $21.60Read more |
| 62 | Not Available | WHEEL SUPPORT | 1096042-03 | Not Available |
| 63 | Not Available | FRONT WHEEL CPL. | 1129038-01 | Not Available |
| 65 | Not Available | SPRING PACKAGE 10 in package. | 63147 | Not Available |
| # | Part image | Description | SKU | Price |
| XX | Not Available | ELECTROLUX POWER HEAD | EL6A | Not Available |
| 1 | Not Available | HOOD ASSEMBLY (ELECTROLUX | NUE-017-2 | Not Available |
| 2 | No Image | SCREW, EL4300A Part Number: 63399-1 for Eureka | 633991 | $2.20Read more |
| 3 | Not Available | PCB FIX BRACKET | NUE-149-119N | Not Available |
| 4 | Not Available | HANDLE RELEASE PEDAL | 78190 | Not Available |
| 5 | Not Available | HEIGHT ADJUSTMENT PEDAL | 78188 | Not Available |
| 6 | Not Available | UNIT MAIN PCB ASSEMBLY | NUE-012A | Not Available |
| 7 | Not Available | INSERT - PEDAL | NUE-206 | Not Available |
| 8 | Not Available | T-JOINT SEALING FLET | NUE-408 | Not Available |
| 9 | Not Available | SPRINT FOR PIVOT ARM | NUE-208 | Not Available |
| 10 | Not Available | REAR WHEEL ASSEMBLY | NUE-014 | Not Available |
| 11 |  | Ring, Retaining Wheels EL6988/EL7020/EL7070/EL4300 Part Number: 54432-2 for Eureka | 544322 | $4.33Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 12 | Not Available | BASE | NUE-101-366N | Not Available |
| 13 | Not Available | HEADLIGHT PCB ASSEMBLY | NUE-010 | Not Available |
| 14 | Not Available | LED FIX COVER | NUE-150-392P | Not Available |
| 15 | Not Available | FRONT AXLE ASSEMBLY | NUE-004 | Not Available |
| 16 | Not Available | FILTER WASHER - LOWER | NUE-407 | Not Available |
| 17 | Not Available | BRUSH ROLL ASSEMBLY | NUE-005 | Not Available |
| 18 | Not Available | POLY V5 BELT | NUE-401 | Not Available |
| 19 | Not Available | SOLE PLATE | NUE-131-366N | Not Available |
| 20 | Not Available | SCREW PACKAGE | 63399-2 | Not Available |
| 21 | Not Available | ACTUATOR ASSEMBLY | NUE-007 | Not Available |
| 22 | Not Available | HEIGHT INDICATOR ASSEMBLY | NUE-011 | Not Available |
| 23 | Not Available | SCREW PACKAGE | 63399-3 | Not Available |
| 24 | Not Available | OVERLOAD INDICATOR PCB AS | NUE-013 | Not Available |
| 25 | Not Available | FOAM PAD | NUE-411 | Not Available |
| 26 | Not Available | SPRING PLATE | NUE-219 | Not Available |
| 27 | Not Available | AIR CHANNEL COVER | NUE-103-119N | Not Available |
| 28 | Not Available | MOTOR COVER | NUE-107-119N | Not Available |
| 29 | Not Available | VENT FOAM FOR MOTOR | NUE-413 | Not Available |
| 30 | Not Available | MOTOR ASSEMBLY | NUE-006 | Not Available |
| 31 | Not Available | COUPLING ASSEMBLY | NUE-003 | Not Available |
| # | Part image | Description | SKU | Price |
| XX | Not Available | Owners guide | 75975A | Not Available |
| XX | Not Available | Sumo Adapter | 045027-355N | Not Available |
| 1 | Not Available | SWIVEL HOSE ASSY - CARTON | 61054-3 | Not Available |
| 2 | Not Available | FLOOR & WALL BRUSH ASSEMB Not available. | 75973-1 | Not Available |
| 3 | Not Available | NOZZLE - FURNITURE | 75985 | Not Available |
| 4 | Not Available | NOZZLE - CREVICE | 76250 | Not Available |
| 5 | Not Available | NOZZLE - DUSTING BRUSH | 75986 | Not Available |
| 6 | Not Available | S BAG CLASSIC | EL200B | Not Available |
| 7 | Not Available | TELESCOPIC WAND ASSY. | 75979-1 | Not Available |
