Schematic and parts book for Electrolux EL7000A, EL7025A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | BOTTOM PART | 1130900-01 | Not Available |
| 2 |  | Dirt Cup, Gray EL7020A Part Number: 1130901-02 for Eureka | 113090102 | $62.74Read more |
| 3 | Not Available | MOTOR HOUSING | 1130902-01 | Not Available |
| 4 | Not Available | SEALING - MOTOR | 1130903-02 | Not Available |
| 5 | Not Available | MOTOR COVER - | 1130904-01 | Not Available |
| 6 | Not Available | SUSPENSION - REAR | 1130909-01 | Not Available |
| 7 | Not Available | ABSORBENT - MOTORHOUSE | 1130910-01 | Not Available |
| 8 | Not Available | HOLDER - FILTER | 1130911-01 | Not Available |
| 9 | Not Available | NO FILTER SAFETY | 1130912-01 | Not Available |
| 10 | Not Available | NO BAG SAFETY | 1130914-01 | Not Available |
| 11 | Not Available | BRACKET - NOZZLE | 1130916-01 | Not Available |
| 12 | No Image | WHEEL, REAR EL6988 EL6989 Part Number: 1130608-03 for Eureka | 113060803 | $31.25Read more |
| 13 | Not Available | COVER - HOSE CONNECT | 1130919-01 | Not Available |
| 14 | Not Available | RING - HOSE CONNECTION | 1130920-01 | Not Available |
| 15 | Not Available | GROMMET | 1130923-01 | Not Available |
| 17 | Not Available | SLEEVE - HOSE CONNECTION | 1130927-01 | Not Available |
| 18 | Not Available | GROMMET - FRONT | 1130928-01 | Not Available |
| 19 | Not Available | FILTER - PERMANENT | 1130929-01 | Not Available |
| 20 | Not Available | HOLDER - BAG | 1130930-01 | Not Available |
| 21 | Not Available | COVER - REAR SATINE | 1130934-09 | Not Available |
| 22 | Not Available | DIFFUSOR - COMPLETE | 1130935-02 | Not Available |
| 24 | Not Available | DIFFUSOR - COMPLETE | 1130937-02 | Not Available |
| 25 | No Image | DISPLAY, LEVEL 4 EL7020A Part Number: 1130938-03 for Eureka | 113093803 | $18.77Read more |
| 26 | Not Available | FILTER - O2 NON | 1130939-01 | Not Available |
| 27 | No Image | HANDLE, EL7020 Part Number: 1130940-01 for Eureka | 113094001 | $87.89Read more |
| 28 | Not Available | GRIP - HANDLE | 1130941-01 | Not Available |
| 29 | Not Available | HANDLE PIN PACKAGE | 63159 | Not Available |
| 33 | No Image | PEDAL, CORD RELEASE EL7020 Part Number: 1130946-01 for Eureka | 113094601 | $4.73Read more |
| 34 | Not Available | LIGHT CONDUCTOR | 1130949-02 | Not Available |
| 35 | Not Available | REFLECTOR | 1130950-02 | Not Available |
| 36 | Not Available | CABLE - MOTOR TERMO | 1130969-01 | Not Available |
| 38 | Not Available | CABLE - POWER OUTLET | 1130958-01 | Not Available |
| 40 | Not Available | COVER & GRAPHICS | 1130967-16 | Not Available |
| 45 | Not Available | MOTOR ASSY - PACKAGED | 63160 | Not Available |
| 46 | Not Available | SEALING | 115857-05 | Not Available |
| 47 | Not Available | HOSE - COOLING | 117990-15 | Not Available |
| 48 | Not Available | HOSE - COOLING | 117990-12 | Not Available |
| 49 | Not Available | HOSE - COOLING | 117990-16 | Not Available |
| 50 | Not Available | HOSE - COOLING | 117990-14 | Not Available |
| 51 | Not Available | HOSE - COOLING | 117990-13 | Not Available |
| 55 | Not Available | SPRING PACKAGE | 63157 | Not Available |
| 57 | Not Available | SPRING PACKAGE | 63158 | Not Available |
| 58 | Not Available | SEAL | 1130289-01 | Not Available |
| 59 | Not Available | CORD WINDER CPL | 1128341-41 | Not Available |
| 60 | No Image | WHEEL, REAR EL6988 EL6989 Part Number: 1130608-03 for Eureka | 113060803 | $31.25Read more |
| 61 | No Image | COVER, REAR WHEEL EL6988 Part Number: 1130614-03 for Eureka | 113061403 | $21.60Read more |
| 62 | Not Available | WHEEL SUPPORT | 1096042-03 | Not Available |
| 63 | Not Available | FRONT WHEEL CPL. | 1129038-01 | Not Available |
| 65 | Not Available | SPRING PACKAGE | 63147 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HOSE - SUMO ACTIVE Hose included. | 1131404-02 | Not Available |
| 2 | Not Available | DUSTING BRUSH - PACKAGED | 54505-5 | Not Available |
| 3 | Not Available | NOZZLE - CREVICE | 1131407-01 | Not Available |
| 4 | Not Available | NOZZLE - SUMO ACTIVE | 1131400-02 | Not Available |
| 6 | Not Available | TUBE - SUMO ACTIVE | 1131402-02 | Not Available |
| 7 | Not Available | NOZZLE - FURNITURE | 75985 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | Not Available | NOZZLE - SUMO ACTIVE Sold complete. | 1131400-02 | Not Available |
