Schematic and parts book for Electrolux EL6985A . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE CPL. | 1130550-01 | Not Available |
| 2 | Not Available | PIN - HANDLE | 1130511-02 | Not Available |
| 3 | Not Available | LID - FILTER | 1130509-00 | Not Available |
| 4 | Not Available | ABSORBENT - FILTER LID | 1130529-01 | Not Available |
| 5 | Not Available | HEPA FILTERS | EL012 | Not Available |
| 6 | Not Available | SEAL | 1130289-01 | Not Available |
| 7 | Not Available | SLIDER | 1130512-01 | Not Available |
| 8 | Not Available | DISPLAY | 1130515-15 | Not Available |
| 9 | Not Available | PCB | 1131175-01 | Not Available |
| 10 | Not Available | PEDAL - ON/OFF | 1130514-12 | Not Available |
| 11 | Not Available | INDICATOR CPL. | 7966-02 | Not Available |
| 11 | Not Available | PEDAL - CORD WINDER | 1130513-05 | Not Available |
| 12 | No Image | USE E-1050326-03 ON/OFF EL6985A Part Number: 1050326-02 for Eureka | 105032602 | $12.83Read more |
| 13 | Not Available | SPRING - PKGD Pkg of | 61403-1 | Not Available |
| 14 | Not Available | HOUSING - MOTOR | 1130502-02 | Not Available |
| 15 | Not Available | ABSORBENT | 1130521-01 | Not Available |
| 16 | Not Available | SUPPORT - MOTOR | 1050808-01 | Not Available |
| 17 | Not Available | HOOD - MOTOR | 1130517-02 | Not Available |
| 18 | Not Available | SEAL - MOTOR | 1130516-01 | Not Available |
| 19 | Not Available | LID - CATCH | 1130527-12 | Not Available |
| 20 | Not Available | FRONT & REAR COVER CPL. | 1130551-02 | Not Available |
| 21 | Not Available | FLAP SPRING - PKGD Pkg of | 61415-1 | Not Available |
| 22 | Not Available | DEVICE - SAFETY | 1130523-01 | Not Available |
| 24 | Not Available | HOLDER - DUST BAG | 1130522-01 | Not Available |
| 25 | Not Available | FILTER - MOTOR | 1130535-01 | Not Available |
| 26 | Not Available | HOLDER - MOTOR FILTER | 1130538-01 | Not Available |
| 27 | Not Available | SEAL | 115857-04 | Not Available |
| 28 | Not Available | MODULE - DUST BAG | 1130500-02 | Not Available |
| 29 | Not Available | WHEEL - REAR | 1130506-01 | Not Available |
| 30 | Not Available | BOTTOM PART CPL. | 1130548-12 | Not Available |
| 31 | Not Available | HOLDER - WHEEL | 1096042-03 | Not Available |
| 32 | Not Available | FRONT WHEEL CPL. | 1129038-01 | Not Available |
| 33 | Not Available | CORDWINDER CPL. | 1128341-30 | Not Available |
| 34 | Not Available | AREA - CABLE RECESS | 1130526-06 | Not Available |
| 35 | Not Available | ELECTROLUX SCREW PACKAGE | 62109-2 | Not Available |
| 36 | Not Available | SUPPORT - MOTOR | 1129023-01 | Not Available |
| 37 | Not Available | MOTOR ASSEMBLY - CARTONED | 60650-3 | Not Available |
| # | Part image | Description | SKU | Price |
| 1 | No Image | Side broom cover right, TW050-W43-U | 39843 | $102.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | Not Available | Belt for Turbo Nozzle | 2193423-01 | Not Available |
| 2 | No Image | Side broom cover left, TW050-W43-U | 39842 | $102.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 2 | No Image | Star knob, Upper Handle, TW050-W43-U | 39841 | $4.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 3 | No Image | Left Arm, Side Broom, TW050-W43-U | 39845 | $195.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 4 | No Image | Bumpers, Side Broom, TW050-W43-U | 39846 | $19.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 5 |  | Fastening plate, Side Broom, TW050-W43-U | 39844 | $3.99Read more |
| 6 | No Image | Bowden cable holder, TW050-W43-U | 39840 | $1.99Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 8 | Not Available | S BAG CLASSIC | EL200B | Not Available |
