Schematic and parts book for Dust Care VC-9009E . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | No Image | CASTER, FRONT SWIVEL WHEEL FOR DCC9009 Part Number: VC9009-1-1 for Dust Care | VC900911 | $1.75Read more |
| 2 | Not Available | Bottom | VC9009-1-2 | Not Available |
| 3 | Not Available | Bottom Seal Bar | VC9009-1-3 | Not Available |
| 4 | No Image | WHEEL, BIG REAR FOR DCC9009 Part Number: VC9009-1-4 for Dust Care | VC900914 | $5.50Read more |
| 5 | No Image | HUB CAP LARGE FOR DCC9009 Part Number: VC9009-1-5 for Dust Care | VC900915 | $4.29Read more |
| 6 | No Image | RING, MOTOR SEAL DCC9009 Part Number: VC9009-1-6 for Dust Care | VC900916 | $3.44Read more |
| 7 | No Image | SHROUD, LOWER MOTOR DCC9009 Part Number: VC9009-1-7 for Dust Care | VC900917 | $6.57Read more |
| 8 |  | MOTOR, DCC9009 Part Number: VC9009-1-8 for Dust Care | VC900918 | $66.14Read more |
| 9 | No Image | MOUNT, MOTOR FRONT DCC9009 Part Number: VC9009-1-9 for Dust Care | VC900919 | $3.26Read more |
| 10 | Not Available | Anti-Shake Ring | VC9009-1-10 | Not Available |
| 11 | No Image | SHROUD, UPPER MOTOR DCC9009 Part Number: VC9009-1-11 for Dust Care | VC9009111 | $5.89Read more |
| 12 | No Image | SENSOR, MOTOR DCC9009 Part Number: VC9009-1-12 for Dust Care | VC9009112 | $6.43Read more |
| 13 | Not Available | Cord Out Window | VC9009-1-13 | Not Available |
| 14 | Not Available | Cord Reel Assembly | VC9009-1-14 | Not Available |
| 15 |  | FILTER, EXHAUST :( DCC9009 WHITE Part Number: VC9009-1-15 for Dust Care | VC9009115 | $4.11Read more |
| 16 | Not Available | Exhaust Filter Seal | VC9009-1-16 | Not Available |
| 17 | Not Available | Reel Part | VC9009-1-17 | Not Available |
| 18 | Not Available | PCB | VC9009-1-18 | Not Available |
| 19 | Not Available | Rear Cover | VC9009-1-19 | Not Available |
| 20 | Not Available | Upholstery Nozzle | VC9009-1-20 | Not Available |
| 21 | No Image | FLOOR BRUSH, DCC9009 Part Number: VC9009-1-21 for Dust Care | VC9009121 | $26.97Read more |
| 22 | Not Available | Switch Cover | VC9009-1-22 | Not Available |
| 23 | No Image | CONTROL, VARIABLE SPEED DCC9009 Part Number: VC9009-1-23 for Dust Care | VC9009123 | $4.08Read more |
| 24 | Not Available | Hose Assembly | VC9009-1-24 | Not Available |
| 25 | Not Available | Telescoping Wand | VC9009-1-25 | Not Available |
| 26 |  | CREVICE TOOL, DCC9009 Part Number: VC9009-1-26 for Dust Care | VC9009126 | $3.78Read more |
| 27 | Not Available | Dusting Brush | VC9009-1-27 | Not Available |
| 28 | Not Available | Tool Cover | VC9009-1-28 | Not Available |
| 29 | Not Available | Suction Rim | VC9009-1-29 | Not Available |
| 30 | Not Available | Tool Door Latch | VC9009-1-30 | Not Available |
| 31 | Not Available | Bag Door Housing | VC9009-1-31 | Not Available |
| 32 | Not Available | Bag Door Latch | VC9009-1-32 | Not Available |
| 33 | No Image | DCC9009 HANDLE SUPPORT Part Number: VC9009-1-33 for Dust Care | VC9009133 | $2.26Read more |
| 34 | Not Available | Exhaust Filter Frame | VC9009-1-34 | Not Available |
| 35 | Not Available | Dust Bag - 5 Pack | VC9009-1-35 | Not Available |
| 36 | Not Available | Dust Bag Handle | VC9009-1-36 | Not Available |
| 37 | Not Available | Lock Plate for Bag Holder | VC9009-1-37 | Not Available |
| 38 | Not Available | Bag Holder | VC9009-1-38 | Not Available |
| 39 | Not Available | Handle Stopper | VC9009-1-39 | Not Available |
| 40 |  | FILTER, SECONDARY FOAM DCC9009 DC-9009 Part Number: VC9009-1-40 for Dust Care | VC9009140 | $2.29Read more |
| 41 | Not Available | Small Door | VC9009-1-41 | Not Available |
