Schematic and parts book for Dust Care DCC-658 Evolution Lite. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 |  | Bottom Plate, Plastic Evolution Cirrus Lite 658 Part Number: DCC658-1 for Evolution | DCC6581 | $32.35Read more |
| 2 | Not Available | Brush Strip on Bottom Plate | DCC658-2 | Not Available |
| 3 | Not Available | Brush Strip Holder | DCC658-3 | Not Available |
| 4 | Not Available | Bumper Block | DCC658-4 | Not Available |
| 5 |  | BUMPER, NOZZLE EVOLUTION CIRRUS LITE CR658 658 Part Number: DCC658-5 for Evolution | DCC6585 | $3.50Read more |
| 6 | Not Available | Brush Roll with Bearings | DCC658-6 | Not Available |
| 7 | No Image | BAR, FIX STEEL BOARD EVOLUTION CIRRUS LITE 658 Part Number: DCC658-7 for Evolution | DCC6587 | $0.97Read more |
| 8 | Not Available | Nozzle Housing | DCC658-8 | Not Available |
| 9 | Not Available | Dirt Tube | DCC658-9 | Not Available |
| 10 | Not Available | Motor Dirt Tube | DCC658-10 | Not Available |
| 11 | Not Available | Exhaust HEPA Filter | DCC658-11 | Not Available |
| 12 | Not Available | Holder for Intake Filter | DCC658-12 | Not Available |
| 13 | Not Available | Dust Bag Indicator | DCC658-13 | Not Available |
| 14 | Not Available | Dust Bag Door | DCC658-14 | Not Available |
| 15 | Not Available | Panel on Bag Door | DCC658-15 | Not Available |
| 16 | Not Available | Cover for Wire Harness | DCC658-16 | Not Available |
| 17 | Not Available | Seal for Dust Bag Compartment | DCC658-17 | Not Available |
| 18 | Not Available | Intake Filter | DCC658-18 | Not Available |
| 19 | Not Available | Holder of Bag Door Lock | DCC658-19 | Not Available |
| 20 | Not Available | Spring of Bag Door Lock | DCC658-20 | Not Available |
| 21 | Not Available | Lock for Bag Door | DCC658-21 | Not Available |
| 22 | Not Available | Paper Bag | DCC658-22 | Not Available |
| 23 | Not Available | Paper Bag Holder | DCC658-23 | Not Available |
| 24 | Not Available | Cover for Switch Housing | DCC658-24 | Not Available |
| 25 | Not Available | Support Frame for Dust Bag Holder | DCC658-25 | Not Available |
| 26 | Not Available | Bag Door Latch Assembly | DCC658-26 | Not Available |
| 27 | Not Available | Fix Block for Handle | DCC658-27 | Not Available |
| 28 | Not Available | Fix Block for Power Cord | DCC658-28 | Not Available |
| 29 | Not Available | On/Off Switch | DCC658-29 | Not Available |
| 30 | Not Available | Handle Grip | DCC658-30 | Not Available |
| 31 | Not Available | Upper Cord Hook | DCC658-31 | Not Available |
| 32 | Not Available | Upper Cord Hook Spring | DCC658-32 | Not Available |
| 33 | Not Available | Base of Cord Hook | DCC658-33 | Not Available |
| 34 | Not Available | Lower Cord Hook | DCC658-34 | Not Available |
| 35 | Not Available | Dust Compartment | DCC658-35 | Not Available |
| 36 | Not Available | Crevice Tool Holder | DCC658-36 | Not Available |
| 37 | Not Available | Upper Hose Hook | DCC658-37 | Not Available |
| 38 | Not Available | Handle Screw | DCC658-38 | Not Available |
| 39 | Not Available | Small Sealing Block for Internal Wire | DCC658-39 | Not Available |
| 40 | Not Available | Hose Access Door | DCC658-40 | Not Available |
| 41 |  | Hose, Evolution Cirrus Lite CR658 Part Number: DCC658-41 for Evolution | DCC65841 | $25.52Read more |
| 42 |  | HOLDER, CREVICE TOOL LOWER EVOLUTION CIRRUS LITE Part Number: DCC658-42 for Evolution | DCC65842 | $2.09Read more |
| 43 | Not Available | Lower Hose Hook | DCC658-43 | Not Available |
| 44 | Not Available | Big Sealing Block for Internal Wire | DCC658-44 | Not Available |
| 45 | Not Available | Exhaust Filter | DCC658-45 | Not Available |
| 46 | Not Available | Motor Cover | DCC658-46 | Not Available |
| 47 | Not Available | Rear Wheel | DCC658-47 | Not Available |
| 48 | Not Available | Motor Seal - Fits on Motor | DCC658-48 | Not Available |
| 49 | Not Available | Rear Wheel Axle | DCC658-49 | Not Available |
| 50 | No Image | EVO LITE REAR WHEEL CLIP Part Number: DCC658-50 for Evolution | DCC65850 | $0.88Read more |
| 51 | No Image | MOTOR, MAIN EVOLUTION & CIRRUS LITE CR658 658 Part Number: DCC658-51 for Evolution | DCC65851 | $43.44Read more |
| 52 | Not Available | Motor Bumper | DCC658-52 | Not Available |
| 53 | Not Available | Support Block for Motor Bumper | DCC658-53 | Not Available |
| 54 | Not Available | Lower Main Housing - Motor Cover | DCC658-54 | Not Available |
| 55 | Not Available | Right Nozzle support Bracket | DCC658-55 | Not Available |
| 56 | Not Available | Left Nozzle Support Bracket | DCC658-56 | Not Available |
| 57 | Not Available | Rug/Floor Level | DCC658-57 | Not Available |
| 58 | Not Available | Handle Release Pedal | DCC658-58 | Not Available |
| 59 | Not Available | Release Pedal Shaft | DCC658-59 | Not Available |
| 60 | Not Available | Handle Release Pedal Spring | DCC658-60 | Not Available |
| 61 | Not Available | Holder for Release Pedal | DCC658-61 | Not Available |
| 62 | Not Available | Belt Guide | DCC658-62 | Not Available |
| 63 | Not Available | Belt | DCC658-63 | Not Available |
| 64 | Not Available | Belt Cover Plate | DCC658-64 | Not Available |
| 65 | Not Available | Brush Strip and Bottom Plate Holder | DCC658-65 | Not Available |
| 66 | Not Available | Left Release Latch for Bottom Plate | DCC658-66 | Not Available |
| 67 | Not Available | Right Release Latch for Bottom Plate | DCC658-67 | Not Available |
| 68 | Not Available | Screw for Bumper Block | DCC658-68 | Not Available |
| 69 | Not Available | Front Wheel Axle | DCC658-69 | Not Available |
| 70 | No Image | WHEELS, FRONT EVOLUTION LITE DCC658 Part Number: DCC658-70 for Evolution | DCC65870 | $2.35Read more |
| 71 | No Image | CREVICE TOOL, LONG EVOLUTION CIRRUS LITE CR658 658 Part Number: DCC658-71 for Evolution | DCC65871 | $4.72Read more |
| 72 | No Image | Cord, 30' Black Power Evolution DCC-358 Upright Part Number: DCC658-72 for Evolution | DCC65872 | $43.79Read more |
| 73 | Not Available | Internal Wires | DCC658-73 | Not Available |
