Schematic and parts book for Dirt devil 08230 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| 1 | Not Available | RIGHT END CAP BODY | 1232121300 | Not Available |
| 2 | Not Available | SWING DOOR HOSE | 1232140600 | Not Available |
| 3 | Not Available | SWITCH COVER | 1232170600 | Not Available |
| 4 | Not Available | SWITCH W/LEADS double tab | 1232187000 | Not Available |
| 4 | Not Available | SWITCH W/LEADS single tab | 1232182000 | Not Available |
| 5 | Not Available | MOTOR | 1232200000 | Not Available |
| 6 | Not Available | FAN | 1232213000 | Not Available |
| 7 | Not Available | REAR MOTOR GROMMET | 1232216000 | Not Available |
| 8 | Not Available | SHAFT EXT. | 1232221000 | Not Available |
| 9 | Not Available | FAN HOUSING SHROUD | 1232233600 | Not Available |
| 10 |  | Dirt Devil Belt-royal Dirt Devil 501/503 Hand Vac 2pkstyle #1 | 3157260001 | $12.96Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 10 |  | Compatible alternateRoyal Dirt Devil Belt, Hand Vacuum Prince and Dirt Devil Style 1 (Pack of 2) More Product Details | RO157260P | $12.96Add to cart Special order — allow 2-4 weeks. |
| 11 | Not Available | CREVICE TOOL | 1232330300 | Not Available |
| 12 | Not Available | TYPE G BAG / 3 PACK | 3010347001 | Not Available |
| 13 |  | Screw, :( Handle - Machine 6200 Series Part Number: 1503819000 for Royal | 1503819000 | $0.41Read more |
| 14 | Not Available | CORD 25' | 1999025600 | Not Available |
| 15 | Not Available | BODY ASSY | 2232111300 | Not Available |
| 16 | Not Available | HOSE ASSY | 2232154600 | Not Available |
| 17 | Not Available | CLOTH BAG | 2232260300 | Not Available |
| 18 |  | Brush Roll-Dirt Devil - 08230 - Hand Vac For: dirt devil | 2232420000 | $28.01Read more |
| 19 | Not Available | NOZZLE PLUG ASSY | 1232321300 | Not Available |
| 20 | Not Available | NOZZLE DOOR | 1232341300 | Not Available |
