Schematic and parts book for cirrus C-CR119 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | EXTRACTOR | C-CR119 | Not Available |
| 1 | Not Available | Rear wheel | C-71048 | Not Available |
| 2 | Not Available | Rear wheel axle | C-71050 | Not Available |
| 3 | Not Available | Rear lower handle | C-70028 | Not Available |
| 5 | Not Available | Solution tank holder | C-75112 | Not Available |
| 8 | Not Available | Knobornament ringcam | C-75110 | Not Available |
| 9 | Not Available | Shroud knob | C-75108 | Not Available |
| 10 | Not Available | Cam Knob | C-75109 | Not Available |
| 30 | Not Available | Screw | C-77094 | Not Available |
| 31 | Not Available | Pedal | C-75116 | Not Available |
| 32 | Not Available | Handle release pedal | C-75114 | Not Available |
| 40 | Not Available | Plug button | C-77095 | Not Available |
| 47 | Not Available | Valve cap seal | C-75126 | Not Available |
| 48 | Not Available | Cup solution tank | C-75128 | Not Available |
| 49 | Not Available | Solution tank | C-75130 | Not Available |
| 56 | Not Available | Timing belt | C-10090 | Not Available |
| 57 | Not Available | Gear agitator motor | C-61008 | Not Available |
| 58 | Not Available | Seal agitator motor shaft | C-61010 | Not Available |
| 59 | Not Available | Agitator motor | C-60040 | Not Available |
| 60 | Not Available | Insulator agitator motor lead | C-61012 | Not Available |
| 61 | Not Available | Fan agitator motor | C-28500 | Not Available |
| 75 | Not Available | Floor nozzle front | C-72015 | Not Available |
| 76 | Not Available | Floor nozzle back | C-72020 | Not Available |
| 78 | Not Available | Tube cover | C-75122 | Not Available |
| 81 | Not Available | Tube discharge | C-73460 | Not Available |
| 90 | Not Available | Transformer | C-75132 | Not Available |
| 91 | Not Available | Upper cover-floor brush | C-55100 | Not Available |
| 106 | Not Available | Nozzle tube upper cover | C-72010 | Not Available |
| 112 | Not Available | Accessories holder | C-52012 | Not Available |
| 113 | Not Available | Cord hook | C-32030 | Not Available |
| 114 | Not Available | Upper cord base | C-32033 | Not Available |
| 115 | Not Available | Cord base fixture | C-32035 | Not Available |
| 118 | Not Available | Handle right cover | C-70527 | Not Available |
| 119 | Not Available | Trigger | C-52010 | Not Available |
| 121 | Not Available | Shank | C-75118 | Not Available |
| 122 | Not Available | Handle left cover | C-70525 | Not Available |
| 128 | Not Available | Valve solution tank w/cap | C-62075 | Not Available |
| 129 | Not Available | Brushroll assembly | C-20020 | Not Available |
| 130 | Not Available | Recovery tank assembly | C-75120 | Not Available |
