Schematic and parts book for Bissell 6489 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Hose w/Handle | 203-1792 | Not Available |
| 2 | Not Available | Dust Tank - Pantone280U | 203-1783 | Not Available |
| 2 | Not Available | Dust Tank - Wildfire Red | 203-1784 | Not Available |
| 3 | Not Available | Bottom Lid - Dust Tank - Pantone280U | 203-1780 | Not Available |
| 3 | Not Available | Bottom Lid - Dust Tank - Wildfire Red | 203-1781 | Not Available |
| 4 | Not Available | Dirt Bin Filter Screen | 203-1771 | Not Available |
| 5 | Not Available | Dirt Bin Filter & Base | 203-1772 | Not Available |
| 6 | Not Available | Switch & Cover | 203-1793 | Not Available |
| 7 | Not Available | Pre Motor Filter XX User's Guide | 203-1534 | Not Available |
| 8 | Not Available | Motor w/Gaskets | 203-1775 | Not Available |
| 9 | Not Available | Post Motor Filter | 203-1786 | Not Available |
| 10 | Not Available | Small Wheel Assembly | 203-1779 | Not Available |
| 11 | Not Available | Extension Wands (2 pk) | 203-1538 | Not Available |
| 12 | No Image | CORD REEL, 6489 ZING BAGLESS Part Number: 203-1777 for Bissell | 2031777 | $36.54Read more |
| 13 | Not Available | Post Motor Filter Door | 203-1778 | Not Available |
| 14 | Not Available | Floor Nozzle | 203-1773 | Not Available |
| 15 | Not Available | Combo Crevice Tool/Dusting Brush | 203-1539 | Not Available |
