Schematic and parts book for Bissell 5288 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | HANDLE ASSY | 203-6917 | Not Available |
| 2 |  | TANK, SOLUTION W/CAP AND INSERT Part Number: 203-6918 for Bissell | 2036918 | $10.01Read more |
| 3 | Not Available | CAP & INSERT ASSY | 203-6919 | Not Available |
| 4 | Not Available | COLLECTION TANK LID | 203-6922 | Not Available |
| 5 |  | Filter, Dirt Cup W/ Frame Flip-Ease Stick 5288 Part Number: 203-6924 for Bissell | 2036924 | $6.07Read more |
| 6 | Not Available | COLLECTION TANK | 203-6920 | Not Available |
| 7 | Not Available | FOOT ASSY | 203-6923 | Not Available |
| 8 | Not Available | CHARGER | 203-6926 | Not Available |
| 9 |  | PAD, MICRO FIBER FLIP-IT Part Number: 203-6912 for Bissell | 2036912 | $8.41Read more |
