Schematic and parts book for Bissell 47A2, 80R4 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| XX |  | Nozzle Gasket Bissell repair part number: 1600103 | 1600103 | $3.27Read more |
| XX | | Cord Bissell repair part number: 1600110 | 1600110 | $25.70Add to cart Special order: ships in 2 to 4 weeks |
| XX |  | Brush Parts Repair Kit | 2036820 | $11.66Add to cart Special order: ships in 2 to 4 weeks |
| XX | | Screw Pack DeepClean Premier Handle Tool Holder Bissell repair part number: 1600078 | 1600078 | $2.97Add to cart Special order: ships in 2 to 4 weeks |
| XX |  | Bissell 3in Attachment Tool Tough Stain Black or green | 2036651 | $22.40Add to cart Special order: ships in 2 to 4 weeks |
| XX |  | Tool Spraying Crevice Bissell repair part number: 2036655 | 2036655 | $14.87Add to cart Special order: ships in 2 to 4 weeks |
| XX | Not Available | Deep Reach Pet Tool | 2037412 | Not Available |
| XX | Not Available | Bare Floor Tool | 1600208 | Not Available |
| XX |  | Bissell Turbo Tool Brush for Vacuum Cleaners 2036652 | 2036652 | $57.42Add to cart Special order: ships in 2 to 4 weeks |
| XX |  | Bissell 6in Upholstery Tool for Stairs - Compatible with Most Bissell Shampooers | 2036654 | $29.62Add to cart Special order: ships in 2 to 4 weeks |
| XX | Not Available | Measuring Cup | 1600209 | Not Available |
| 1 | | Tank Handle DeepClean Premier Bissell repair part number: 1600086 | 1600086 | $3.42Add to cart Special order: ships in 2 to 4 weeks |
| 2 | Not Available | Tank Lid Assy - Passion Purple (17N4V 17N45 36Z9) | 1600090 | Not Available |
| 2 | Not Available | Tank Lid Assy - Blackberry Purple (47A2 47A22) | 1600087 | Not Available |
| 2 | Not Available | Tank Lid Assy - Fablue (80R4) | 1600088 | Not Available |
| 2 | Not Available | Tank Lid Assy - Red Berends (47A2T) | 1600089 | Not Available |
| 2 | Not Available | Tank Lid Assy - Grasshopper (17N4 17N4P) | 1600091 | Not Available |
| 2 |  | Tank Lid AssyStealth Gray PH Premier Bissell repair part number: 1602890 | 1602890 | $51.19Add to cart Special order: ships in 2 to 4 weeks |
| 2 | No Image | Compatible alternateBiissell tank lid assembly More Product Details | WP10758 | $51.19Add to cart Special order: ships in 2 to 4 weeks |
| 3 | | NO LONGER AVAILABLE Tank Nozzle Gasket DeepClean Premier Bissell repair part number: 1600095 | 1600095 | $3.27Read more |
| 4 |  | Tank Latches 2 pack DeepClean Premier Bissell repair part number: 1600096 | 1600096 | $3.42Add to cart Special order: ships in 2 to 4 weeks |
| 5 | | Float Door Bissell repair part number: 1602670 | 1602670 | $3.27Read more |
| 6 |  | NLA Tank Cap Insert Assy DeepClean Premier Bissell repair part number: 1600097 | 1600097 | $5.51Read more |
| 7 |  | NO LONGER AVAILABLE Tank Bladder DeepClean Premier Bissell repair part number: 1600093 | 1600093 | $18.04Read more |
| 8 |  | NO LONGER AVAILABLE Tank Bottom Assy DeepClean Premier Bissell repair part number: 1600092 | 1600092 | $64.26Read more |
| 9 | Not Available | Upper Handle Assy - Sugar Cookie | 1600128 | Not Available |
| 9 | Not Available | Upper Handle Assy - Red Berends (47A21) | 1602891 | Not Available |
| 10 |  | NO LONGER AVAILABLE Upper Hose Cord Wrap DeepClean Premier Bissell repair part number: 1600079 | 1600079 | $16.53Read more |
| 11 | | Tool clip Bissell repair part number: 1601849 | 1601849 | $3.44Add to cart Special order: ships in 2 to 4 weeks |
| 12 | | Lower Hose Cord Wrap DeepClean Premier Bissell repair part number: 1600080 | 1600080 | $12.35Add to cart Special order: ships in 2 to 4 weeks |
| 13 | | PowerSwitch Assy Deep Clean Premier Bissell repair part number: 1600085 | 1600085 | $6.78Add to cart Special order: ships in 2 to 4 weeks |
| 14 | | NO LONGER AVAILABLE Hose Assy Bissell repair part number: 1600111 | 1600111 | $29.43Read more |
| 15 | | Detent Assy with spring Bissell repair part number: 1600108 | 1600108 | $7.30Add to cart Special order: ships in 2 to 4 weeks |
| 16 |  | Wheel Kit 2 wheels ering axles etc Bissell repair part number: 1600109 | 1600109 | $14.08Add to cart Special order: ships in 2 to 4 weeks |
| 17 |  | NO LONGER AVAILABLE Bissell nozzle assembly is designed to fit 17N4 Deep Clean Pet, 47A2 and 80R4... | 1600098 | $43.99Read more |
| 18 | | Spray Tip w Tubing Bissell repair part number: 1600101 | 1600101 | $7.30Add to cart Special order: ships in 2 to 4 weeks |
| 19 |  | Bissell Cord Side Belt | 2036804 | $8.79Add to cart |
| 20 |  | Swivel Arm Set Bissell repair part number: 1600106 | 1600106 | $8.35Read more |
| 21 |  | Brush Roll Black bristle Bissell repair part number: 1600104 | 1600104 | $19.14Read more |
| 22 |  | Small Bissell Belt 1602669 for models 80R4 and 47A2 | 1602669 | $5.99Add to cart |
| 23 | | Access Cover Assy Bissell repair part number: 1600116 | 1600116 | $27.11Add to cart Special order: ships in 2 to 4 weeks |
| 24 |  | Pump Assy w Autoload Bissell repair part number: 1600114 | 1600114 | $34.13Add to cart Special order: ships in 2 to 4 weeks |
| 25 | | Brush Motor Cover Bissell repair part number: 1600113 | 1600113 | $6.32Add to cart Special order: ships in 2 to 4 weeks |
| 26 |  | NO LONGER AVAILABLE BRUSH MOTOR ASSY Bissell repair part number: 2036757 | 2036757 | $36.30Read more |
| 26 |  | Available ReconditionedCertified Reconditioned BRUSH MOTOR ASSY Bissell repair part number: 2036757 More Product Details | 2036757R | $69.99Add to cart |
| 27 |  | Pcba P356 | 1607388 | $26.89Add to cart Special order: ships in 2 to 4 weeks |
| 28 |  | Solenoid Valve | 1600117 | $22.00Add to cart Special order: ships in 2 to 4 weeks |
| 29 | | Microswitch Foot Bissell repair part number: 1600118 | 1600118 | $6.27Read more |
| 30 | | Vac Motor | 1600112 | $47.25Add to cart Special order: ships in 2 to 4 weeks |
| 31 | | Diverter Assy Bissell repair part number: 1600107 | 1600107 | $18.69Add to cart Special order: ships in 2 to 4 weeks |
| 32 | | Rear Cover Bissell repair part number: 1600119 | 1600119 | $26.70Add to cart Special order: ships in 2 to 4 weeks |
| 33 | | Motor Duct w Lint Screen Bissell repair part number: 1600120 | 1600120 | $9.92Add to cart Special order: ships in 2 to 4 weeks |
| 34 |  | Tool Stain Trapper | 1600057 | $58.36Add to cart Special order: ships in 2 to 4 weeks |
| 35 | | STAIN TRAPPER TOOL TANK Bissell repair part number: 1600058 | 1600058 | $8.27Add to cart Special order: ships in 2 to 4 weeks |
| 36 |  | NO LONGER AVAILABLE STAIN TRAPPER TOOL NOZZLE Bissell repair part number: 1600059 | 1600059 | $6.17Read more |
