Schematic and parts book for Bissell 3560 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 1 | Not Available | Paper Bag Style 6 HEPA 3 Pk | 32052 | Not Available |
| 2 | Not Available | Cloth Bag Ass'y (Inc. Key #3) | 714-0237 | Not Available |
| 3 | Not Available | Bag Clip | NLA | Not Available |
| 4 | Not Available | Switch Open Grip | 210-8828 | Not Available |
| 5 | Not Available | Closed Grip Ass'y | NLA | Not Available |
| 6 | Not Available | Cord Hook | NLA | Not Available |
| 7 | Not Available | Power Cord | NLA | Not Available |
| 8 | Not Available | Right Open Grip | NLA | Not Available |
| 9 | Not Available | Left Open Grip | NLA | Not Available |
| 10 | Not Available | Upper Handle Tube | NLA | Not Available |
| 11 | Not Available | Power Connector | NLA | Not Available |
| 12 | Not Available | Cable Clamp | NLA | Not Available |
| 13 | No Image | HANDLE NUT, PLUS UPRIGHT Part Number: 880-5006 for Bissell | 8805006 | $0.27Read more |
| 14 | Not Available | Handle Connector Seal | NLA | Not Available |
| 15 | Not Available | Screw | 880-7024 | Not Available |
| 16 | Not Available | Screw | NLA | Not Available |
| 17 | Not Available | Handle Connector Ass'y (Inc. Key #14) Items Not Ill ustrated | 013-2056 | Not Available |
| 18 | Not Available | Dust Tube NLA Users Guide | NLA | Not Available |
| 19 | Not Available | Yoke NLA Wheel | NLA | Not Available |
| 20 | Not Available | Receptacle NLA Axle | 010-7320 | Not Available |
| 21 | Not Available | Filter Cover | NLA | Not Available |
| 22 | Not Available | Exhaust Filter Style 6 Filtrete 2 Pk | 32054 | Not Available |
| 23 | Not Available | Rear Wheel | 010-3920 | Not Available |
| 24 | Not Available | Motor Ass'y (Inc. Key #20 23 25 26) | 013-2057 | Not Available |
| 25 | Not Available | Headlight Bulb | HR-3500 | Not Available |
| 26 | Not Available | Lens | 013-3929 | Not Available |
| 27 | Not Available | Collar | 013-3935 | Not Available |
| 28 | Not Available | Bag Retainer Spring | 010-8455 | Not Available |
| 29 | Not Available | Right Bushing | 013-3937 | Not Available |
| 30 | Not Available | Screw | 880-7030 | Not Available |
| 31 | Not Available | Nozzle Housing Ass'y | NLA | Not Available |
| 32 | Not Available | Left Bushing | NLA | Not Available |
| 33 | Not Available | Brushroll Ass'y With Oblong Ends | 014-1166 | Not Available |
| 33 | Not Available | Brushroll Ass"y With Round Ends | 210-1131 | Not Available |
| 34 | Not Available | Belt Style 6 Flat 2 Pk | 32053 | Not Available |
| 35 | Not Available | Furniture Guard | NLA | Not Available |
| 36 | Not Available | Nozzle Cover Upper & Lower W/Wheels | NLA | Not Available |
| 37 | Not Available | Wiper Blade | NLA | Not Available |
| 38 | Not Available | Detent Spring | 010-1602 | Not Available |
