Schematic and parts book for Bissell 3554 Lift Off. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| xx | Not Available | CORD WRAP | NLA | Not Available |
| xx | Not Available | CORD WRAP BRACKET | NLA | Not Available |
| xx | Not Available | USER'S GUIDE | 010-5739 | Not Available |
| 1 | Not Available | CREVICE TOOL | 210-9157 | Not Available |
| 2 | Not Available | WAND (SINGLE) | 210-9664 | Not Available |
| 3 | Not Available | DUSTING BRUSH | 210-1162 | Not Available |
| 4 | Not Available | UPHOLSTERY TOOL | 210-9179 | Not Available |
| 5 | Not Available | HANDLE - PLUM | 014-3820 | Not Available |
| 5 | Not Available | HANDLE - BLACK | 014-3822 | Not Available |
| 6 | Not Available | HANDLE GRIP | NLA | Not Available |
| 7 | Not Available | BACK SUPPORT - PLUM | 014-3803 | Not Available |
| 7 | Not Available | BACK SUPPORT - BLACK | 014-3823 | Not Available |
| 8 | Not Available | LATCH SPRING | 010-8434 | Not Available |
| 9 | Not Available | LATCH HOUSING | 013-3813 | Not Available |
| 10 | Not Available | LATCH SLIDE | 013-3812 | Not Available |
| 11 | Not Available | HANDLE COVER | NLA | Not Available |
| 12 |  | SWITCH ROCKER RED REPL Bissell repair part number: 5559125 | 5559125 | $3.27Read more |
| 13 | Not Available | POD DOOR | NLA | Not Available |
| 14 | Not Available | POD DOOR GASKET | NLA | Not Available |
| 15 | Not Available | FILTER BAG | NLA | Not Available |
| 16 | Not Available | POD RECEPTACLE | 010-7348 | Not Available |
| 17 | Not Available | POD HOUSING | 014-3811 | Not Available |
| 18 | Not Available | FLEX HOSE | 010-4701 | Not Available |
| 19 | Not Available | HANDLE TUBE | 010-9474 | Not Available |
| 20 | Not Available | BASE RECEPTACLE | 010-7349 | Not Available |
| 21 | Not Available | TRANSITION GASKET | NLA | Not Available |
| 22 | Not Available | NUT | 280-5006 | Not Available |
| 23 | Not Available | BRACKET ASSY | 014-3805 | Not Available |
| 24 | Not Available | REAR WHEEL | 010-9770 | Not Available |
| 25 | Not Available | FOOT PEDAL | 210-3052 | Not Available |
| 26 | Not Available | FOOT COVER - PLUM | 014-3806 | Not Available |
| 26 | Not Available | FOOT COVER - BLACK | NLA | Not Available |
| 27 | Not Available | LENS | 013-3807 | Not Available |
| 28 | Not Available | FILTER - 3M | 210-3541 | Not Available |
| 29 | Not Available | PRE MOTOR FILTER | 210-3296 | Not Available |
| 30 | Not Available | FILTER CAGE | NLA | Not Available |
| 31 | Not Available | MOTOR SEAL | NLA | Not Available |
| 32 | Not Available | VACUUM MOTOR | 010-6029 | Not Available |
| 33 | Not Available | GASKET | NLA | Not Available |
| 34 | Not Available | GASKET SUPPORT | NLA | Not Available |
| 35 | Not Available | BUMPER | NLA | Not Available |
| 36 | Not Available | BRUSH MOTOR | 010-6028 | Not Available |
| 37 | Not Available | BULB | 555-9069 | Not Available |
| 38 | Not Available | BULB HOLDER | 010-4603 | Not Available |
| 39 | Not Available | BRUSH SWITCH | 555-9148 | Not Available |
| 40 | Not Available | DUCT COVER | NLA | Not Available |
| 41 | Not Available | CORD | 010-3031 | Not Available |
| 42 | Not Available | MOTOR HOUSING | NLA | Not Available |
| 43 | Not Available | BASE ASSY | NLA | Not Available |
| 44 | Not Available | BELT GUIDE | NLA | Not Available |
| 45 | Not Available | BRUSH | NLA | Not Available |
| 46 | Not Available | BELT | 555-9017 | Not Available |
| 47 | Not Available | ACCESS PLATE | 213-3173 | Not Available |
