Schematic and parts book for Bissell 3522;3522-1;3522-4;3522-5;3522-6;3545;3545-1;3545-2;3545-5;3545-q . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
Popular Supplies
| # | Part image | Description | SKU | Price |
| XX |  | WHEELERING8975 CLEANVW REPL Bissell repair part number: 2032548 | 2032548 | $3.44Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 1 | Not Available | Handle Ass'y 3522 3522-1/5/6 | 203-1098 | Not Available |
| 1 | Not Available | Handle Ass'y 3522-4 (Order B-203-1098) | NLA | Not Available |
| 1 | Not Available | Handle Ass'y 3545 3522-4 3545 3545-1/2/3/5/Q | 203-1001 | Not Available |
| 1 | Not Available | Handle Ass'y 3545-1/Q | 203-1000 | Not Available |
| 1 | Not Available | Handle Ass'y 3545-2 3522 3522-1/4/5/6 3545-2 | 203-1258 | Not Available |
| 1 | Not Available | Handle Ass'y 3545-3 3545-5 | 203-1002 | Not Available |
| 2 | Not Available | Handle Front (Order Key 1) 3545 3545-1/3/5/Q | N/A | Not Available |
| 3 | Not Available | Hose Hanger | 203-1028 | Not Available |
| 4 | Not Available | Handle Back 3545 3545-1 3545-5 3522 3545 3545-1/2/Q | 203-1029 | Not Available |
| 5 | Not Available | Top Panel | NLA | Not Available |
| 6 | Not Available | Bag Door 3522 3545-3 3545-5 | 203-1087 | Not Available |
| 6 | Not Available | Bag Door 3522-1/5/6 | 203-1247 | Not Available |
| 6 | Not Available | Bag Door 3522-4 (Order B-203-1087) | NLA | Not Available |
| 6 | Not Available | Bag Door 3545 | 203-1005 | Not Available |
| 6 | Not Available | Bag Door 3545-1/Q 3545 3545-1/3/5/Q | 203-1004 | Not Available |
| 6 | Not Available | Bag Door 3545-2 | 203-1259 | Not Available |
| 6 | Not Available | Bag Door 3545-3 3545-5 | 203-1006 | Not Available |
| 7 | Not Available | Bulb 20 Watt 3545 3545-1/3/5/Q | 203-1007 | Not Available |
| 8 | Not Available | Light Lens | 203-1008 | Not Available |
| 9 | Not Available | Wire Cap 3522 3522-1/4/5/6 3545-2 | 203-1106 | Not Available |
| 9 | Not Available | Wire Cap 3545 3545-1/3/5/Q | 203-1037 | Not Available |
| 10 | Not Available | Secondary Filter Grill 3545 3545-1/3/5/Q | 203-1014 | Not Available |
| 11 | Not Available | Secondary Filter 3522 3522-1/4/5/6 3545-2 | 203-1089 | Not Available |
| 11 |  | SECONDARY FILTER, POWERGLIDE 3545 Part Number: 203-1013 for Bissell | 2031013 | $3.90Read more |
| 12 | Not Available | Main Body | NLA | Not Available |
| 13 |  | CORD RELEASE 3545 REPL Bissell repair part number: 2031018 | 2031018 | $3.42Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 14 | | SWITCH ROCKER 3545 REPL Bissell repair part number: 2031035 | 2031035 | $11.39Read more |
| 15 | Not Available | Power Cord 3522 3522-1/4/5/6 22' | 203-1105 | Not Available |
| 15 | Not Available | Power Cord 3545 25' | 203-1024 | Not Available |
| 15 | No Image | CORD, 30' 3545-1/2/Q Part Number: 203-1066 for Bissell | 2031066 | $32.35Read more |
| 15 | Not Available | Power Cord 3545-3 3545-5 35' | 203-1067 | Not Available |
| 16 |  | FILTER HEPA STYLE 7916 Bissell repair part number: 32076 | 32076 | $18.82Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 16 |  | Bissell HEPA Filter Designed to Fit Style 9 HEPA Filter Part # 32076 | BR18005 | $9.52Add to cart |
| 17 |  | Filter Post Motor Bagless Repl | 2031009 | $3.44Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 |  | Grille Back Powerforce Replacement | 2031088 | $6.11Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 18 | Not Available | Exhaust Filter Grill 3545 3545-1/3/5/Q | 203-1011 | Not Available |
| 19 | Not Available | Motor Cover | NLA | Not Available |
| 20 | Not Available | Thermal Protector 3522 3522-1/4/5/6 | 203-1108 | Not Available |
| 20 | No Image | HARNESS, WIRING THERMAL 3591 Part Number: 203-1034 for Bissell | 2031034 | $10.68Read more |
| 21 | Not Available | Handle Release Pedal | 203-1044 | Not Available |
| 21 | Not Available | Handle Release Pedal 3545-2 | 203-0052 | Not Available |
| 22 | | BRUSH NECK POWERFORCE REPL Bissell repair part number: 2031112 | 2031112 | $3.42Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 22 | Not Available | Right Nozzle Clamp | 203-1040 | Not Available |
| 23 | | BRUSH NECK POWERFORCE REPL Bissell repair part number: 2031112 | 2031112 | $3.42Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | Not Available | Left Nozzle Clamp 3545 3545-1/2/3/5/Q | 203-1039 | Not Available |
| 24 | Not Available | Nozzle Housing 3522 3522-1/5/6 | 203-1113 | Not Available |
| 24 | Not Available | Nozzle Housing 3522-4 (Order B-203-1113) | NLA | Not Available |
| 24 | Not Available | Nozzle Housing 3545 | NLA | Not Available |
| 24 | Not Available | Nozzle Housing 3545-1/2/Q | NLA | Not Available |
| 24 | Not Available | Nozzle Housing 3545-3 3545-5 | NLA | Not Available |
| 25 | Not Available | Rear Wheel 3522 | 203-1111 | Not Available |
| 25 | Not Available | Rear Wheel 3545 3545-1/3/5/Q SECURED BY A HUBCAP THE | 203-1043 | Not Available |
| 25 | Not Available | Rear Wheel 3545-2 FOLLOWING PARTs MUST BE | 203-2037 | Not Available |
| 25A |  | Rear Wheel 35221 Repl | 2032070 | $7.44Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 26 | No Image | CAP, WHEEL BAGLESS Part Number: 203-1045 for Bissell | 2031045 | $4.29Read more |
| 26 | Not Available | Wheel Cap 3545-2 NEW sTYLE WHEEL: B-203-1110 | 203-2065 | Not Available |
| 27 | Not Available | Front Wheel 3522 3522-1/5/6 | 203-2556 | Not Available |
| 27 | Not Available | Front Wheel Assembly | 203-1015 | Not Available |
| 28 |  | Bissell KNOB POWERFORCE REPL Part Number: 2031095 | 2031095 | $13.24Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 28 | Not Available | Height Adjustment Knob | 203-1042 | Not Available |
| 29 | Not Available | Paper Bag Style 7 Envirofresh 3 Pk | 30861 | Not Available |
| 29 | Not Available | Paper Bag Style 7 Filtrete 2 Pk | NLA | Not Available |
| 29 |  | Paper Bag, BigGreen Commercial BGU1451T 10Pk Part Number: U1451-PK10 for Bissell | U1451PK10 | $43.42Read more |
| 30 |  | Case Drum Assy Powerfrc Repl | 2031110 | $25.92Read more |
| 30 | Not Available | Nozzle lntake Ass'y | 203-1046 | Not Available |
| 30 | Not Available | Nozzle Intake Ass'y 3545-2 | 203-2039 | Not Available |
| 31 | Not Available | Brushroll Ass'y 3522 3522-1/4/5/6 | 203-1016 | Not Available |
| 31 | Not Available | Brushroll Ass'y 3545-2 | 203-2013 | Not Available |
| 32 | Not Available | Bottom Plate 3522 3522-1/4/5/6 | 203-1091 | Not Available |
| 32 | Not Available | Bottom Plate 3545 3545-1/3/5/Q | 203-1017 | Not Available |
| 32 | Not Available | Bottom Plate 3545-2 | 203-2036 | Not Available |
| 33 |  | Bissell 7, 9, 10, 12 Belt 2pk Aftermarket | BR-1008 | $9.99Add to cart |
| 33 |  | Compatible alternateBissell Belt 2PK 7 9 10 belt More Product Details | 011120320749 | $6.00Add to cart |
| 33 |  | Compatible alternateBelt, Style 10 Flat Each 088650/088750/088300 Part Number: 1860140600 for Royal More Product Details | 1860140600 | $6.00Add to cart Special order — allow 2-4 weeks. |
| 33 | No Image | Compatible alternateBelt Style 7910 More Product Details | 2031093 | $7.13Add to cart Special order — allow 2-4 weeks. |
| 33 |  | Compatible alternateBelt, Style UB11 216.37030700 Upright More Product Details | 81313207 | $6.00Add to cart Special order — allow 2-4 weeks. |
| 33 | | Bissell 7, 9, 10, 12 Belt 2pk Aftermarket | BR-1008 | $9.99Add to cart |
| 34 | Not Available | Motor Case Gasket | 203-1058 | Not Available |
| 35 | Not Available | Motor Case 3545 3545-1/3/5/Q | 203-1057 | Not Available |
| 36 | Not Available | Motor Gasket 3522 3522-1/4/5/6 | 203-1107 | Not Available |
| 36 | Not Available | Motor Gasket 3545 3545-1/3/5/Q | 203-1060 | Not Available |
| 36 | Not Available | Motor Gasket 3545-2 | 203-1218 | Not Available |
| 37 | Not Available | Motor Ass'y 3522 3522-1/4/6 | 203-1100 | Not Available |
| 37 | Not Available | Motor Ass'y 3522-5 | 203-2211 | Not Available |
| 37 | Not Available | Motor Ass'y 3545 3545-1/3/5/Q | 203-1052 | Not Available |
| 37 | Not Available | Motor Ass'y 3545-2 | 203-1214 | Not Available |
| 38 | Not Available | Motor Support 3522 3522-1/4/5/6 | 203-1101 | Not Available |
| 38 | Not Available | Motor Support 3545 3545-1/3/5/Q | 203-1054 | Not Available |
| 38 | Not Available | Motor Support 3545-2 | 203-1217 | Not Available |
| 39 | Not Available | Motor Cushion 3522 3522-1/4/5/6 | 203-1102 | Not Available |
| 39 | No Image | CUSHION, SMALL MOTOR 8990 Part Number: 203-1061 for Bissell | 2031061 | $2.92Read more |
| 39 | Not Available | Motor Cushion 3545-2 | 203-1107 | Not Available |
| 40 | Not Available | Hose Ass'y 3522 3522-1/4/5/6 | 203-1097 | Not Available |
| 40 | Not Available | Hose Ass'y 3545 3545-1/Q | 203-1019 | Not Available |
| 40 | Not Available | Hose Ass'y 3545-2 | 203-1261 | Not Available |
| 40 | Not Available | Hose Ass'y 3545-3 3545-5 | NLA | Not Available |
| 41 | Not Available | Crevice Tool | 203-1063 | Not Available |
| 42 |  | Wand, 3545 92L3P 6594 Part Number: 203-1022 for Bissell | 2031022 | $6.83Read more |
| 43 | Not Available | Combination Tool 3522 3522-1/4/5/6 | 203-1099 | Not Available |
| 43 | Not Available | Combination Tool 3545 3545-1/3/5/Q | 203-1023 | Not Available |
| 43 | Not Available | Combination Tool 3545-2 | 203-1228 | Not Available |
| 44 | Not Available | Bumper 3522 3522-1/5/6 | 203-1114 | Not Available |
| 45 | | WHEELERING8975 CLEANVW REPL Bissell repair part number: 2032548 | 2032548 | $3.44Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 46 |  | WHEELSHAFT8975 CLEANVW REPL Bissell repair part number: 2032547 | 2032547 | $5.15Add to cart Product is special order please allow 2-4 weeks for delivery. |
