Schematic and parts book for Bissell 35129 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 01 | Not Available | BAG FILTER 1PLY STYLE20PP REPL | 210-0204 | Not Available |
| 03 | Not Available | CORD LATCH | 213-5506 | Not Available |
| 05 | Not Available | DIRT TUBESBW/FM GSK/LBL REPL | 214-9419 | Not Available |
| 07 | Not Available | BAG-SOFT-OPP-BLUE 1- PACK REPL | 210-0218 | Not Available |
| 07 | Not Available | CORDSET W/HEYCO REPL | 210-2834 | Not Available |
| 11 | Not Available | CORDSET W/STRN RLF OPP NEWREPL | 210-2860 | Not Available |
| 13 |  | SWITCH ROCKER RED REPL Bissell repair part number: 5559125 | 5559125 | $3.27Read more |
| 14 | Not Available | KIT-SCREWS/NUTS/BOLT! | 280-5040 | Not Available |
| 15 | Not Available | SCREW #10-32 X | 380-7210 | Not Available |
| 19 | Not Available | MOTOR 10AMP -W/O BULB REPL | 214-5957 | Not Available |
| 20 | Not Available | BULB-GE T5/921 12.8V | 555-9069 | Not Available |
| 21 | Not Available | RING-MTR | 555-9192 | Not Available |
| 22 |  | Knob for Singer Sb/Hb Series For: fragrance fresh | 2035100 | $1.20Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 23 | Not Available | PEDAL-HNDL | 555-9196 | Not Available |
| 24 | No Image | STRAP, MOTOR 35351 Part Number: 213-1115 for Bissell | 2131115 | $0.87Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 25 | Not Available | SPRG-INT SLIDE/PUSH IN | 210-8421 | Not Available |
| 26 | Not Available | CHASSIS W/REAR WHL&PEDAL12REPL | 215-0408 | Not Available |
| 30 | Not Available | BELT SDB 4/20 5287 1-PK | 210-0600 | Not Available |
| 31 | Not Available | BRUSH ASSM REPL | 210-1009 | Not Available |
| 32 | Not Available | WHEEL ASSM FRNT REPL | 214-9700 | Not Available |
| 33 | No Image | BOTTOM PLATE, SB/HB UPRT 12" Part Number: 555-9266 for Singer | 5559266 | $4.97Read more |
| 34 | Not Available | HOSEBLACK-W/RING | 210-5005 | Not Available |
| 35 | Not Available | REPLACEMENT WAND | 210-9102 | Not Available |
| 36 | Not Available | UPHTOOLW/BR BLK REPL | 210-9104 | Not Available |
| 37 | No Image | CREVICE TOOL, SB & HB SERIES UPRIGHTS Part Number: 210-9103 for Singer | 2109103 | $8.89Read more |
| 38 | Not Available | UPHTOOLW/BR BLK REPL | 210-9104 | Not Available |
| 40 | Not Available | LENS | 713-5510 | Not Available |
| 41 | Not Available | BUMPER-12" OPP REPL | 213-0306 | Not Available |
| 42 | Not Available | FAN MTR- DRILLED OPP | 555-9016 | Not Available |
| 43 | Not Available | USER GUIDE EC 3105818 *RBO | 310-5849 | Not Available |
