Schematic and parts book for Bissell 3510W Power Partner. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| 04 | Not Available | BUMPER-12" OPP REPL | 213-0306 | Not Available |
| 05 | Not Available | PEDAL-HNDL | 555-9196 | Not Available |
| 07 | No Image | STRAP, MOTOR 35351 Part Number: 213-1115 for Bissell | 2131115 | $0.87Add to cart Product is special order please allow 2-4 weeks for delivery. |
| 09 | Not Available | MOTOR-OPP SUB 3105913 M/*RBO | 014-5950 | Not Available |
| 11 | Not Available | RING-MTR | 555-9192 | Not Available |
| 14 | Not Available | SPRG-INT SLIDE/PUSH IN | 210-8421 | Not Available |
| 15 | Not Available | CHASSIS W/REAR WHL&PEDAL12REPL | 215-0408 | Not Available |
| 19 | Not Available | BELT SDB 4/20 5287 1-PK | 210-0600 | Not Available |
| 20 | Not Available | BRUSH ASSM REPL | 210-1009 | Not Available |
| 21 | Not Available | WHEEL ASSM FRNT REPL | 214-9700 | Not Available |
| 24 | Not Available | CORD LATCH | 213-5506 | Not Available |
| 26 |  | SWITCH ROCKER RED REPL Bissell repair part number: 5559125 | 5559125 | $3.27Read more |
| 29 | No Image | CORD, W/STRAIN RELIEF 3510W Part Number: 214-2837 for Bissell | 2142837 | $15.11Read more |
| 33 | Not Available | DIRT TUBESBW/FM GSK/LBL REPL | 214-9419 | Not Available |
| 34 | Not Available | BAG FILTER 1PLY STYLE2OPP REPL | 210-0204 | Not Available |
| 35 | Not Available | SCREW #10-32 X | 380-7210 | Not Available |
| 36 | Not Available | KIT-SCREWS/NUTS/BOLTS | 280-5040 | Not Available |
| 37 | Not Available | BAG-SOFT-OPP-BLUE 1- PACK REPL | 210-0218 | Not Available |
