Schematic and parts book for Bissell 3120, 3130, 31305, 31306 Easy Vac. Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| xx | Not Available | Drive Belt | 203-7034 | Not Available |
| xx | Not Available | User's Guide | 010-0292 | Not Available |
| 1 |  | Handle, Marina Blue Looped Easy Vac 3120/3130 Part Number: 203-7047 for Bissell | 2037047 | $14.63Read more |
| 2 | Not Available | Stretch Hose | 203-7020 | Not Available |
| 3 | Not Available | Upholstery Brush | 203-7033 | Not Available |
| 4 | Not Available | Foot Hose | 203-7046 | Not Available |
| 5 | Not Available | Primary Separator w/Gasket - Marina Blue | 203-7024 | Not Available |
| 6 | Not Available | Easy Empty Dirt Cup | 203-7021 | Not Available |
| 7 | Not Available | Inner and Outer Circular Filters | 203-7023 | Not Available |
| 8 | Not Available | Lower Tank | 203-7022 | Not Available |
| 9 | Not Available | Crevice Tool | 203-7032 | Not Available |
| 11 |  | WRAP, UPPER CORD QUICK RELEASE Part Number: 203-7035 for Bissell | 2037035 | $2.29Read more |
| 12 |  | SWITCH, INTERNAL POWER 3120 3130 EASY VAC Part Number: 203-7045 for Bissell | 2037045 | $3.33Read more |
| 13 | Not Available | Rear Wheel | 203-7037 | Not Available |
| 14 |  | CLAMP,:( LEFT & RIGHT PIVOT 3120 3130 EASY VAC Part Number: 203-7042 for Bissell | 2037042 | $3.50Read more |
| 15 | Not Available | Detent Lever | 203-7043 | Not Available |
| 16 | Not Available | Power Switch Pedal | 203-7044 | Not Available |
| 17 | Not Available | Floor Brush | 203-7029 | Not Available |
| 18 | Not Available | Nozzle Grd. w/Sqege & Frt. Whls | 203-7028 | Not Available |
| 19 | No Image | MOTOR, FITS EASYVAC 3120 & 3130 Part Number: 203-7039 for Bissell | 2037039 | $47.40Read more |
| 20 | Not Available | Roller Lifter Assy. | 203-7030 | Not Available |
| 21 | Not Available | Pre-Motor Filter | 203-7031 | Not Available |
