Schematic and parts book for Bissell 11X4 . Repairs should be done by trained technicians. Vacuums R Us & Sewing Too provides vacuum cleaner and carpet cleaner parts and accessories for vacuum cleaner repair purposes. We are committed to delivering high-quality components, but it is important to note that all appliance repairs involve risks, and we cannot guarantee the outcome of your repair. When using our vacuum parts for repairs, you accept the terms and conditions HERE
| # | Part image | Description | SKU | Price |
| XX | Not Available | Paper Bag (10 pack) | 203-7744 | Not Available |
| XX | Not Available | Cable Cord USA (Yellow) | 203-7767 | Not Available |
| XX | Not Available | Latch Break (Black) | 203-7779 | Not Available |
| XX | No Image | CLIP, HOSE W/LIP BG11 BLACK Part Number: 203-1661 for Bissell | 2031661 | $2.94Read more |
| XX | No Image | CUFF, HOSE 32MM BG11 BLACK Part Number: 203-1662 for Bissell | 2031662 | $5.50Read more |
| XX | No Image | COUPLING, HOSE W/OUT SEAL BLACK BG11 Part Number: 203-1663 for Bissell | 2031663 | $3.26Read more |
| XX | No Image | RING, METAL 30MM DIAMETER BG11 Part Number: 203-1665 for Bissell | 2031665 | $4.69Read more |
| XX |  | RECEPTICLE, 3 WIRE CSA BG11 Part Number: 203-1666 for Bissell | 2031666 | $16.68Read more |
| XX | Not Available | Seal Front Door | 203-1667 | Not Available |
| XX | No Image | SCREW, SHORT LEFT SIDE BG11 Part Number: 203-1670 for Bissell | 2031670 | $2.65Read more |
| XX | Not Available | Bearing Bus Long | 203-1671 | Not Available |
| XX | No Image | PLATE, FRONT FIXING PLATE BG11 Part Number: 203-1672 for Bissell | 2031672 | $1.06Read more |
| XX | No Image | SCREW, THUMB W/2 WASHERS BG11 Part Number: 203-7774 for Bissell | 2037774 | $9.61Read more |
| XX | No Image | PEDAL, SWITCH BG11 Part Number: 203-7778 for Bissell | 2037778 | $14.92Read more |
| XX | No Image | RESTRAIN, DOOR GREEN BG11 Part Number: 203-7780 for Bissell | 2037780 | $7.30Read more |
| XX | Not Available | Locking Pedal Assembly (Yellow) | 203-7777 | Not Available |
| XX | No Image | CASTER, REAR W/BEARING UP BG11 Part Number: 203-1673 for Bissell | 2031673 | $22.04Read more |
| XX | No Image | SHAFT, REAR REAR 7.95MM BG11 Part Number: 203-1674 for Bissell | 2031674 | $9.82Read more |
| XX | Not Available | Brush Motor | 203-1675 | Not Available |
| XX | No Image | DRIVER, BRUSH BG11 Part Number: 203-1676 for Bissell | 2031676 | $3.97Read more |
| 1 | Not Available | Metal Telescoping Extension Wand | 203-7762 | Not Available |
| 2 | Not Available | Hose End | 203-1664 | Not Available |
| 3 | Not Available | Hose Assembly (Black) | 203-7764 | Not Available |
| 4 | Not Available | Handle Assembly | 203-7763 | Not Available |
| 5 | No Image | HANDLE, LEFT & RIGHT BG11 BLACK Part Number: 203-1660 for Bissell | 2031660 | $20.38Read more |
| 6 | No Image | CREVICE TOOL, BG78/BG11 Part Number: 203-7760 for Bissell | 2037760 | $4.37Read more |
| 7 | Not Available | Dusting Brush | 203-7761 | Not Available |
| 8 | No Image | UPHOLSTERY TOOL, BG78/ BG11 Part Number: 203-7860 for Bissell | 2037860 | $10.45Read more |
| 9 | No Image | RESTRAIN, CORD BG78/BG15/BG11 Part Number: 203-7784 for Bissell | 2037784 | $4.20Read more |
| 10 | Not Available | Power Switch (Green) | 203-7821 | Not Available |
| 11 | No Image | LOCK, DOOR BG11 Part Number: 203-1669 for Bissell | 2031669 | $1.99Read more |
| 12 | Not Available | Front Door Assembly (Green) | 203-7776 | Not Available |
| 13 |  | Filter, 11X4 BG11 Above Motor W/ Frame Round Comm Part Number: 203-7769 for Bissell | 2037769 | $6.85Read more |
| 14 | No Image | HOOK, CORD SWIVEL BG11 Part Number: 203-7775 for Bissell | 2037775 | $1.87Read more |
| 15 | No Image | MOTOR, 1 STAGE BG11 Part Number: 203-7765 for Bissell | 2037765 | $151.46Read more |
| 16 | Not Available | Locking Pedal (Yellow) | 203-1668 | Not Available |
| 17 | No Image | HOUSING, NOZZLE GREEN BG11 Part Number: 203-7773 for Bissell | 2037773 | $328.38Read more |
| 18 | Not Available | Wheel Assembly | 203-7768 | Not Available |
| 19 | No Image | SCREWS, BOTTOM PLATE BG11 Part Number: 203-7770 for Bissell | 2037770 | $0.82Read more |
| 20 | No Image | Motor, BG11/11X4 Nozzle Motor Geared 2 Motor Unit Part Number: 203-7766 for Bissell | 2037766 | $89.84Read more |
| 21 | Not Available | Belt | 203-7771 | Not Available |
| 22 | Not Available | Circuit Board | 203-7772 | Not Available |
| 23 | Not Available | Brush Strip Pack | 203-7758 | Not Available |
| 24 | Not Available | Roller Support Right (Open) | 203-1678 | Not Available |
| 25 | Not Available | Roller Support Left (Closed) | 203-1677 | Not Available |
| 26 |  | Brushroll, W/Brush Strip & End Cap BGUPRO18T Part Number: 203-7745 for Bissell | 2037745 | $163.13Read more |
